GE IC693MDL930D Product Specification
Product Overview
The GE IC693MDL930D is a 16-point discrete output module designed for GE’s Series 90-30 PLC systems. It serves as a critical link between the PLC’s central processing unit (CPU) and external industrial devices, converting digital control signals from the CPU into electrical outputs that operate equipment like motors, valves, and lights. This function makes it essential for automating processes in various industrial settings.
The GE IC693MDL930D supports 24 VDC output, with each channel capable of handling up to 0.5 amps of current. It is fully compatible with Series 90-30 CPUs such as the IC693CPU350 and fits into Series 90-30 racks like the IC693CHS391M (10-slot) and IC693CHS398H (16-slot). This compatibility allows it to integrate seamlessly into existing systems, whether for new installations or upgrades.
The GE IC693MDL930D is built to withstand tough industrial conditions. It operates in temperatures ranging from 0°C to 60°C and can handle humidity levels between 5% and 95% without condensation. Its compact design (110 mm × 80 mm × 40 mm) and lightweight structure (0.4 kg) make it easy to install in tight control cabinets. Front-panel LEDs show the status of each output channel, letting technicians quickly check if a channel is active or if there’s a fault. Whether in factories, power plants, or water treatment facilities, the GE IC693MDL930D provides reliable control over external devices, ensuring automation systems run smoothly.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693MDL930D |
| Manufacturer | General Electric (GE) |
| Product Type | 16-Point Discrete Output Module |
| Series | Series 90-30 |
| Number of Channels | 16 (isolated in 2 groups of 8) |
| Output Voltage | 24 VDC |
| Max Current per Channel | 0.5 A |
| Total Max Current | 4 A |
| Physical Dimensions | 110 mm (L) × 80 mm (W) × 40 mm (H) [4.33″ × 3.15″ × 1.57″] |
| Weight | 0.4 kg (0.88 lb) |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5–95% non-condensing |
| Isolation | 250 VAC (channel groups to logic) |
| Mounting Type | Series 90-30 rack mount (fits IC693CHS391M, IC693CHS398H) |
| Certifications | CE, UL 508 |
IC693MDL930D
IC693MDL930D
Main Features and Advantages
16-point capacity: The GE IC693MDL930D offers 16 output channels, allowing it to control multiple devices from a single module. This reduces the number of modules needed in a rack, saving space in control cabinets and simplifying system design.
Reliable output performance: Each channel of the GE IC693MDL930D delivers 24 VDC at up to 0.5 A, making it suitable for powering common industrial devices like solenoid valves and small motors. The module’s design ensures stable output even in environments with electrical noise, preventing unexpected device shutdowns.
Isolated channel groups: The GE IC693MDL930D divides its 16 channels into 2 isolated groups of 8. This isolation protects the module and connected devices from voltage spikes or ground loops that can occur when multiple devices operate on different electrical circuits.
Easy integration: The GE IC693MDL930D fits directly into Series 90-30 racks without needing extra wiring beyond the rack’s backplane. It works with all Series 90-30 CPUs, so users can add it to new systems or upgrade older ones without replacing other components.
Clear status monitoring: Front-panel LEDs on the GE IC693MDL930D light up when a channel is active, making it easy to see which devices are operating at a glance. This helps technicians quickly identify issues, such as a failed channel or device, reducing troubleshooting time.
Related Products
- GE IC693CPU350: A Series 90-30 CPU that sends control signals to the GE IC693MDL930D to operate external devices.
- GE IC693CHS391M: A 10-slot rack that houses the GE IC693MDL930D and other Series 90-30 modules, providing mechanical support and backplane connections.
- GE IC693PWR330: A power supply module that delivers 24 VDC to the GE IC693MDL930D and other modules in the rack, ensuring stable operation.
- GE IC693MDL241K: A 16-point discrete input module that works with the GE IC693MDL930D in a system, sending sensor data to the CPU while the GE IC693MDL930D controls devices.
- GE IC693BEM331M: A communication module that connects the PLC system to external networks, allowing remote monitoring of the GE IC693MDL930D’s output status.
- GE IC693CMM311: A Modbus communication module that enables the CPU to share data about the GE IC693MDL930D’s operation with HMIs or SCADA systems.
Installation and Maintenance
Pre-installation preparations: Before installing the GE IC693MDL930D, turn off power to the Series 90-30 rack. Make sure the rack is properly grounded to avoid damage from static electricity. Check that the rack is compatible—most Series 90-30 racks like the IC693CHS391M work. Align the module with an empty slot in the rack. Slide it in until it locks into place. Ensure the module’s backplane connector fully seats in the rack to guarantee proper communication with the CPU.
Maintenance suggestions: Check the GE IC693MDL930D monthly. Look at the front-panel LEDs to confirm they light up when channels are active. Clean dust from the module with compressed air to prevent overheating. Every three months, check the connections between the module and external devices. Tighten any loose wires to ensure good electrical contact. If a channel stops working, swap the module with a spare to see if the issue is with the module or the connected device. IC693MDL930D
IC693MDL930D
Application Areas
In manufacturing: Factories use the GE IC693MDL930D to control equipment on assembly lines. For example, it operates conveyor belt motors, robotic arm actuators, and packaging machines. The module receives signals from the CPU telling it when to start or stop each device, keeping the line moving in sync.
In power plants: The GE IC693MDL930D controls valves and pumps in turbine auxiliary systems. It opens or closes valves based on signals from the CPU, regulating the flow of cooling water or lubricants to keep turbines running smoothly. This helps maintain stable power generation.
In water treatment: The module operates pumps and valve actuators in treatment plants. It turns pumps on when water levels rise and shuts them off when levels drop, preventing overflows. It also controls chemical dosing valves, ensuring the right amount of cleaning agents is added to the water.
In food processing: The GE IC693MDL930D runs mixing machines, conveyor belts, and packaging equipment. It starts and stops these devices based on timing signals from the CPU, ensuring food products move through processing steps at the right speed to maintain quality.
IC693MDL930D
Product Guarantee
Our company offers a one-year quality warranty service for GE IC693MDL930D, covering hardware malfunctions not caused by human factors. During the warranty period, if GE IC693MDL930D shows abnormal performance—such as unresponsive channels or failed LEDs—we will provide replacement services.
Our company is a leading enterprise in the industrial control industry, established in 2007, with 17 years of experience. We are an import and export trade distribution company, mainly selling major brands of industrial control parts. We have many unpopular discontinued models and a large stock. Our supply channels are strong, with a large number of products in stock to meet customers’ urgent needs for spare parts. Our main business includes the distribution and trade of PLC modules, DCS cards, ESD system cards, vibration monitoring system cards, turbine control system modules, gas generator spare parts, and instruments.
