GE IC693MDL930 Digital Output Module
Product Overview
The GE IC693MDL930 is a 16-channel digital output module designed for GE’s Series 90-30 PLC systems, a key platform in industrial automation. This module converts digital signals from the PLC into electrical outputs. These outputs control devices like relays, solenoids, and indicator lights. It acts as a bridge between the PLC’s processing unit and field equipment, ensuring that commands from the control system are carried out accurately.
As part of the IC693 Series, the GE IC693MDL930 fits into Series 90-30 backplane racks, such as the IC693CHS393. It works with CPUs like the IC693CPU364 to extend the PLC’s ability to control external devices. The module operates on 24 V DC power, a standard in industrial settings, making it easy to integrate with existing systems.
Built for tough environments, the GE IC693MDL930 handles temperatures from 0°C to 60°C and humidity up to 95% (non-condensing). This durability makes it suitable for factories, power plants, and water treatment facilities. Even though GE has stopped producing it, the GE IC693MDL930 remains important for keeping older Series 90-30 systems running. It helps businesses avoid the high cost of replacing entire systems while maintaining reliable operation.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693MDL930 |
| Manufacturer | GE |
| Product Type | 16-channel Digital Output Module (Series 90-30) |
| Series | IC693 (Series 90-30) |
| Output Channels | 16 (isolated) |
| Output Voltage | 24 V DC |
| Output Current | 0.5 A per channel; 4 A total per module |
| Physical Dimensions | 127 mm (L) × 89 mm (W) × 64 mm (D) |
| Weight | 0.4 kg |
| Operating Temperature | 0°C to 60°C |
| Humidity Tolerance | 5%–95% (non-condensing) |
| Isolation | 1500 V AC (channel to backplane) |
| Mounting Type | Backplane mount (fits Series 90-30 racks) |
IC693MDL930
Related Products
- GE IC693CPU364: A central processing unit for Series 90-30 systems. It sends control signals to the IC693MDL930 to operate field devices.
- GE IC693CHS393: A 10-slot backplane rack. The IC693MDL930 is mounted here, along with other modules, to form a complete control system.
- GE IC693PWR330: A power supply module. It provides 24 V DC power to the IC693MDL930 and other modules in the rack.
- GE IC693MDL630: A 16-channel digital input module. It works with the IC693MDL930 to create a full I/O system, where inputs from sensors trigger outputs via the PLC.
- GE IC693BEM331L: A Genius bus interface module. It connects the PLC system, including the IC693MDL930, to a wider network for remote monitoring.
- GE IC693CBL324: A 1-meter cable. It connects the IC693MDL930 to terminal blocks, ensuring secure wiring to field devices.
Main features and advantages
16-channel capacity: The IC693MDL930 has 16 independent channels. This allows it to control up to 16 devices at once, such as 16 different solenoid valves in a packaging line. It reduces the need for multiple modules, saving space in the control cabinet.
Isolated channels: Each channel is isolated from the others and the backplane (1500 V AC). This prevents electrical interference from one device affecting others. For example, a voltage spike from a motor won’t disrupt the signal to a nearby indicator light.
Reliable operation: The module handles 24 V DC, a standard voltage in industrial settings. It delivers 0.5 A per channel, enough to power most small to medium field devices. This reliability ensures that devices respond correctly to PLC commands, reducing downtime.
Easy integration: The IC693MDL930 fits into any Series 90-30 backplane rack. It slides into place and locks with a simple mechanism. No special tools are needed for installation, making setup quick.
Durable design: It works in a wide temperature range (0°C to 60°C) and resists humidity. This makes it suitable for harsh environments like food processing plants (with washdowns) or foundries (with dust and heat).
Compatibility with legacy systems: The IC693MDL930 works with all Series 90-30 CPUs and racks. This means businesses can keep using their existing PLC systems without replacing them. It extends the life of the automation setup, saving money.
IC693MDL930
Installation and maintenance
Pre-installation preparations: Check that the IC693MDL930 is compatible with your Series 90-30 backplane rack (like the IC693CHS393). Ensure there is an empty slot in the rack. Power off the PLC system before installing. Slide the module into the slot until it clicks into place. Connect the output wires from field devices (relays, solenoids) to the module’s terminals. Use the correct wire size (14–18 AWG) and tighten terminal screws to 5 lb-in. Power the system back on and check that the module’s status light is green, showing it is working.
Maintenance suggestions: Inspect the IC693MDL930 regularly. Look for loose wires or dust on the module. Wipe dust off with a dry cloth to prevent overheating. Check the status light during operation. A red light means there is a problem, such as a short circuit in a connected device. Disconnect the faulty device to fix the issue. Store a spare IC693MDL930 in a dry, cool area (10–30°C). This allows quick replacement if the module fails, minimizing downtime.
Application fields
The GE IC693MDL930 is used in industries where controlling multiple devices is key:
- Automotive manufacturing: In car assembly plants, the module controls robotic grippers, conveyor belt motors, and welding machine relays. Its 16 channels handle the many small devices needed to assemble car parts, ensuring each step happens in the right order.
- Food and beverage processing: It operates filling valves, labeling machines, and conveyor diverters. The module’s durability stands up to washdowns with cleaning chemicals, keeping the system running in hygienic environments.
- Material handling: In warehouses, the IC693MDL930 controls elevator motors, sorting gates, and stop/start relays for conveyors. It ensures that packages and materials move to the right place, reducing delays in shipping.
- Water treatment: It manages pump relays, valve actuators, and alarm lights in treatment plants. The module’s ability to handle wet conditions ensures that filtration and chemical dosing systems work reliably, keeping water safe.
IC693MDL930
Product guarantee
Our company offers a one-year quality warranty service for the IC693MDL930, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems.
Our company is a leading enterprise in the industrial control industry, established in 2007, has been 17 years. We are an import and export trade distribution company, mainly selling major brands of industrial control parts, there are many unpopular discontinued models, with a large stock. Our company has the advantage of supply channels, a large number of spot, to meet the needs of customers anxious to find spare parts. Our main PLC module, DCS card, ESD system card, vibration monitoring system card, turbine control system module, gas generator spare parts, instruments and other products distribution trade.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
