GE IC693MDL753K Series 90-30 16-Channel Digital Output Module
Product Overview
The GE IC693MDL753K is a 16-channel digital output module. It is part of GE’s Series 90-30 PLC system. It converts digital signals from a CPU module into electrical outputs. These outputs control devices like relays, solenoids, and small motors. This makes it a key component in industrial automation. It is used in manufacturing, water treatment, and energy sectors.
The GE IC693MDL753K operates with 24V DC outputs. Each channel can handle up to 0.5A of current. This allows it to control multiple devices at once. It fits into standard Series 90-30 racks. Examples include the IC693CHS397. It works with CPUs like the IC693CPU374-JY. It communicates through the backplane. This ensures fast and reliable signal transfer.
The GE IC693MDL753K is built for tough industrial environments. It operates in temperatures from 0°C to 60°C. It resists dust and vibrations. It has 1500V AC isolation between channels and the backplane. This protects the PLC system from electrical noise. It also prevents damage from voltage spikes. These features make it reliable in busy factories and outdoor installations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693MDL753K |
| Manufacturer | GE |
| Product Type | 16-Channel Digital Output Module |
| Series | Series 90-30 |
| Number of Channels | 16 (grouped into 4 isolated banks of 4) |
| Output Voltage | 24V DC (20.4V DC to 28.8V DC) |
| Maximum Current per Channel | 0.5A |
| Maximum Current per Bank | 2A |
| Physical Dimensions | 110mm (L) × 64mm (W) × 30mm (D) |
| Weight | 0.3 kg |
| Operating Temperature | 0°C to 60°C |
| Isolation | 1500V AC (channels to backplane; between banks) |
| Mounting | Fits in Series 90-30 racks (e.g., IC693CHS397) |
| Country of Origin | United States |
IC693MDL753K
Related Products
- GE IC693CPU374-JY: A high-performance CPU module. It sends digital signals to the IC693MDL753K. It controls the module’s output states based on programmed logic.
- GE IC693CHS397: A 10-slot rack. It houses the IC693MDL753K and other Series 90-30 modules. It provides physical support and electrical connections.
- GE IC693PWR330: A 24V DC power supply module. It provides power to the IC693MDL753K. It ensures stable operation of the module and connected devices.
- GE IC693MDL740K: A 16-channel digital input module. It works with the IC693MDL753K in automation systems. It sends input signals to the CPU, which then triggers outputs via the IC693MDL753K.
- GE IC693BEM331: An Ethernet communication module. It connects the PLC system (including the IC693MDL753K) to industrial networks. It allows remote monitoring of output states.
- GE IC693ALG220: An analog input module. It provides process data to the CPU. The CPU uses this data to control outputs through the IC693MDL753K, such as adjusting valve positions.
- GE IC693ACC302B: A backup battery module. It preserves program data in the CPU. This ensures the IC693MDL753K resumes correct operation after power outages.
Main features and advantages
high channel density: The IC693MDL753K has 16 channels. These channels are grouped into 4 isolated banks. This design allows it to control 16 devices in a small space. It is ideal for medium-sized automation systems. Examples include controlling multiple solenoid valves in a packaging line.
strong output capability: Each channel of the IC693MDL753K delivers 24V DC at up to 0.5A. Each bank can handle a total of 2A. This allows it to control a range of devices. These devices include small motors, relays, and indicator lights. It eliminates the need for external amplifiers in many cases.
reliable isolation: The module has 1500V AC isolation. This isolation is between channels and the backplane. It is also between different banks. This protects the PLC system from electrical noise. It prevents damage from voltage spikes. This is critical in environments with heavy machinery. Examples include welding shops or motor control centers.
tough industrial design: The IC693MDL753K operates in temperatures from 0°C to 60°C. It resists dust and vibrations. It does not require special enclosures in most factory settings. This durability reduces maintenance needs. It ensures consistent performance in harsh conditions.
easy integration: The module fits into any Series 90-30 rack. Examples include the IC693CHS397. It connects to the CPU via the rack’s backplane. No extra wiring is needed for communication. This simplifies installation. It reduces setup time in new systems or upgrades.
clear status indicators: LED lights on the front panel show the state of each channel. A light is on when the channel is active. This makes it easy to check if a device is receiving power. It speeds up troubleshooting. For example, a dark LED may indicate a loose wire or a failed device.
