Product Overview: GE IC693MDL753G Digital Output Module
The GE IC693MDL753G is a digital output module. It is part of the GE Series 90-30 programmable logic controller (PLC) platform. This module serves a critical role in industrial automation systems. It converts electrical signals from the PLC into physical actions. These actions control external devices. Examples of such devices include relays, solenoids, and small motors.
The GE IC693MDL753G features 16 output channels. Each channel operates at 24 volts DC. This design allows it to handle a range of industrial loads. It is suitable for both low-power and medium-power devices. The module is housed in a compact enclosure. This enclosure fits into standard Series 90-30 baseplate slots. It does not require extra space beyond the module’s footprint.
The GE IC693MDL753G integrates seamlessly with other Series 90-30 components. These components include CPUs, input modules, and communication modules. It supports real-time signal transmission. This transmission is essential for synchronized operations in manufacturing lines and process control systems. The module’s rugged construction ensures reliable performance in harsh industrial environments. It makes the GE IC693MDL753G a key component in automation setups across multiple industries.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | GE |
| Product type | Digital Output Module |
| Series | GE Series 90-30 |
| Physical dimensions | 5.12 inches (height) x 3.54 inches (width) x 5.59 inches (depth) |
| Weight | 0.77 pounds (0.35 kilograms) |
| Country of origin | United States |
| Power requirements | 24 volts DC (output), 5 volts DC (logic, supplied by baseplate) |
| Number of outputs | 16 channels |
| Output current | 0.5 amps per channel, 4 amps total |
| Operating temperature | 0°C to 60°C (32°F to 140°F) |
| Output type | Sinking (NPN) |
IC693MDL753G
Related products
- GE IC693MDL940: This is a digital input module. It works with the GE IC693MDL753G in automation systems. It collects signals from sensors. It sends these signals to the PLC for processing.
- GE IC693CPU350: This is a CPU module. It controls the GE IC693MDL753G. It sends commands to the output module based on logic programs.
- GE IC693PWR321: This is a power supply module. It provides 5 volts DC to the GE IC693MDL753G for logic operations. It also supplies 24 volts DC for the module’s output channels.
- GE IC693CMM311: This is a communication module. It connects the PLC system (including the GE IC693MDL753G) to external networks. It enables remote monitoring of output status.
- GE IC693MDL754: This is another digital output module. It has 32 channels. It offers more outputs than the GE IC693MDL753G. It is used in systems needing higher output capacity.
- GE IC693CHS397L: This is a 5-slot baseplate. It houses the GE IC693MDL753G and other Series 90-30 modules. It provides electrical connections between components.
Main features and advantages
Channel capacity: The GE IC693MDL753G has 16 output channels. This allows it to control multiple devices at once. It reduces the need for extra modules in small to medium systems. Each channel can handle 0.5 amps. The total load across all channels is limited to 4 amps. This balance protects the module from overload. It ensures stable operation.
Channel capacity: The GE IC693MDL753G has 16 output channels. This allows it to control multiple devices at once. It reduces the need for extra modules in small to medium systems. Each channel can handle 0.5 amps. The total load across all channels is limited to 4 amps. This balance protects the module from overload. It ensures stable operation.
Voltage compatibility: The GE IC693MDL753G operates on 24 volts DC. This is a standard voltage in industrial settings. It works with most sensors, relays, and small motors. This compatibility simplifies system design. It reduces the need for voltage converters.
Rugged design: The GE IC693MDL753G is built to withstand tough industrial conditions. It works in temperatures from 0°C to 60°C. It resists vibration and electromagnetic interference. This durability minimizes downtime. It makes the module suitable for factories, warehouses, and outdoor installations.
Diagnostic capabilities: The GE IC693MDL753G has status LEDs for each channel. These LEDs light up when a channel is active. They help identify faults quickly. For example, a dim or unlit LED may indicate a wiring issue or a faulty device. This feature speeds up troubleshooting. It reduces maintenance time.
Easy integration: The GE IC693MDL753G fits into standard Series 90-30 baseplate slots. It connects to the PLC backplane without complex wiring. It is recognized automatically by the CPU module. This plug-and-play design simplifies installation. It lowers the risk of setup errors.
Installation and maintenance
Pre-installation preparations: Check that the Series 90-30 baseplate (such as the GE IC693CHS397L) has an empty slot. Ensure the slot is clean. Verify that the power supply (such as the GE IC693PWR321) can provide 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power before installing the GE IC693MDL753G. Align the module with the slot guides. Push it firmly into place. Secure it with screws.
Pre-installation preparations: Check that the Series 90-30 baseplate (such as the GE IC693CHS397L) has an empty slot. Ensure the slot is clean. Verify that the power supply (such as the GE IC693PWR321) can provide 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power before installing the GE IC693MDL753G. Align the module with the slot guides. Push it firmly into place. Secure it with screws.
Maintenance suggestions: Inspect the GE IC693MDL753G regularly. Check for loose wires at the output terminals. Tighten any loose connections. Clean the module with a dry, lint-free cloth. This removes dust. Dust can block vents and cause overheating. Monitor the status LEDs during operation. A steady green light on a channel means it is working. A flickering or off light may signal a problem. Replace faulty channels or the module if issues persist.
IC693MDL753G
Application fields
The GE IC693MDL753G is used in manufacturing. It controls conveyor belts, robotic arms, and packaging machines. It turns devices on or off based on signals from the PLC. This coordination ensures smooth production flows. It reduces manual intervention.
The GE IC693MDL753G is used in manufacturing. It controls conveyor belts, robotic arms, and packaging machines. It turns devices on or off based on signals from the PLC. This coordination ensures smooth production flows. It reduces manual intervention.
The GE IC693MDL753G is used in automotive plants. It operates assembly line tools. These tools include welders, paint sprayers, and part feeders. The module’s 16 channels handle multiple tools in a single work cell. This streamlines the assembly process. It improves efficiency.
The GE IC693MDL753G is used in packaging lines. It controls sealers, labelers, and conveyor diverters. It ensures packages are sealed, labeled, and sorted correctly. The module’s fast response time keeps up with high-speed packaging operations. It reduces errors in product handling.
The GE IC693MDL753G is used in water treatment facilities. It operates valves and pumps. These control the flow of water through filtration and treatment stages. The module’s rugged design works in damp environments. It ensures consistent operation of critical water systems.
The GE IC693MDL753G is used in material handling systems. It controls motor starters for lifts, conveyors, and palletizers. It coordinates the movement of materials in warehouses and distribution centers. This automation reduces labor costs. It improves safety by minimizing human contact with heavy machinery.
IC693MDL753G
Product guarantee
Our company offers a one-year quality warranty service for the GE IC693MDL753G. This warranty covers hardware malfunctions not caused by human factors. During the warranty period, if the GE IC693MDL753G shows abnormal performance or functional failure, we will provide replacement services. Our company is a leading enterprise in the industrial control industry. It was established in 2007 and has a history of 17 years up to now. We are an import and export trade distribution company. We mainly sell major brands of industrial control parts. We have many unpopular discontinued models. We have a large stock. Our company has the advantage of supply channels. We have a large number of spot products. We can meet the needs of customers anxious to find spare parts. Our main business includes the distribution and trade of PLC modules, DCS cards, ESD system cards, vibration monitoring system cards, turbine control system modules, gas generator spare parts, and instruments. For discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts. We provide reliable services to support the continuous and stable operation of industrial systems.
