Product Overview: GE IC693MDL753CA Discrete Output Module
The GE IC693MDL753CA is a discrete output module designed for the GE Fanuc Series 90-30 programmable logic controller (PLC) platform. It serves as a critical link between the PLC’s central processing unit (CPU) and field actuators in industrial automation systems. Its primary function is to convert digital signals from the CPU into electrical outputs that control devices such as solenoid valves, contactors, and small motors. This conversion allows the automation system to execute physical actions based on logic programmed into the CPU, making the GE IC693MDL753CA essential for translating digital commands into real-world operations.
The GE IC693MDL753CA features 16 output channels, each capable of handling up to 0.5 amps of current at 24V DC. This configuration makes it suitable for controlling a range of low to medium-power devices commonly found in factory settings. As part of the Series 90-30 family, it integrates seamlessly with other modules in the series, including CPUs, input modules, and communication cards. This compatibility ensures that the GE IC693MDL753CA can be easily added to existing systems or included in new installations without requiring major overhauls.
In automation architectures, the GE IC693MDL753CA is valued for its reliability and versatility. It operates in temperatures ranging from 0°C to 60°C, allowing it to function in harsh industrial environments where dust, vibration, and temperature fluctuations are common. Its design includes built-in protection against overloads and short circuits, reducing the risk of damage to connected equipment. Whether used in automotive assembly lines, packaging machinery, or material handling systems, the GE IC693MDL753CA provides consistent performance, helping to maintain smooth and efficient operations.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | General Electric (GE) |
| Product type | Discrete Output Module (Series 90-30) |
| Physical dimensions | 5.1 x 3.9 x 1.6 inches (130 x 99 x 41 mm) |
| Weight | 150 grams (5.3 ounces) |
| Country of origin | United States |
| Output voltage | 24V DC |
| Maximum current per channel | 0.5A |
| Number of output channels | 16 |
| Operating temperature | 0°C to 60°C (32°F to 140°F) |
IC693MDL753CA
Related products
- GE IC693CPU350-CF: A CPU module in the Series 90-30 platform that sends control signals to the GE IC693MDL753CA to activate connected devices.
- GE IC693MDL240: A discrete input module that works with the GE IC693MDL753CA; it collects sensor data, which the CPU uses to determine when the GE IC693MDL753CA should trigger outputs.
- GE IC693PWR321: A power supply module that provides 24V DC power to the GE IC693MDL753CA, ensuring stable operation of its output channels.
- GE IC693CHS397: A 5-slot baseplate where the GE IC693MDL753CA is installed; it connects the module to the CPU and distributes power.
- GE IC693MDL754: A discrete output module with 16 channels like the GE IC693MDL753CA but with a higher current rating (2A per channel) for larger devices.
- GE IC693CMM31: A Genius Bus communication module that shares status data from the GE IC693MDL753CA with remote monitoring systems.
- GE IC693BEM331: An Ethernet module that allows the GE IC693MDL753CA’s output status to be monitored and controlled via networked devices.
Main features and advantages
Output capacity: The GE IC693MDL753CA offers 16 discrete output channels. Each channel can handle up to 0.5A of current at 24V DC. This means it can control a variety of industrial devices, from small solenoid valves to relay coils. The 16-channel design allows it to manage multiple devices at once, reducing the need for additional output modules in mid-sized systems. This capacity balances functionality and space efficiency, making it a practical choice for crowded control cabinets.
Protective design: The GE IC693MDL753CA includes built-in protection features. It guards against short circuits and overloads on individual channels. If a connected device draws too much current or a wire touches a metal surface, the module limits damage by isolating the affected channel. Other channels continue to operate normally. This protection reduces downtime caused by electrical faults and lowers repair costs.
LED status indicators: Each output channel on the GE IC693MDL753CA has a small LED light. The LED turns on when the channel is active (sending power to a device). This makes it easy for technicians to visually confirm which outputs are working. Troubleshooting is faster because issues like a failed relay or broken wire can be identified by a dark LED when the channel should be active.
Environmental durability: The GE IC693MDL753CA is built to perform in tough industrial conditions. It operates in temperatures from 0°C to 60°C, which covers the typical range of factory floors and processing plants. It resists dust and minor vibrations, ensuring consistent performance even in less controlled environments. This durability means it rarely needs replacement, saving time and money on maintenance.
Series 90-30 compatibility: The GE IC693MDL753CA is part of the Series 90-30 platform. It works seamlessly with other modules in the series, including CPUs, input modules, and power supplies. This compatibility makes it easy to expand systems. Users can add more output channels or new functions by installing additional Series 90-30 modules, without replacing existing hardware.
IC693MDL753CA
Installation and maintenance
Pre-installation preparations: Before installing the GE IC693MDL753CA, check the baseplate (such as the GE IC693CHS397) to ensure it is securely mounted in the control cabinet. Verify that the baseplate has an open slot for the module. Confirm that the power supply (like the GE IC693PWR321) provides stable 24V DC power. Clean the module’s connectors and the baseplate’s slot with a dry cloth to remove dust or debris. This prevents poor electrical connections that can cause output failures.
Maintenance suggestions: Regularly inspect the GE IC693MDL753CA for dust buildup, especially in dusty environments. Use compressed air to gently blow off dust from the module and its vents every three months. Check the LED indicators during operation. A dark LED when the channel should be active may indicate a problem with the module, wiring, or connected device. Inspect wiring connections to ensure they are tight. Loose connections can cause intermittent output issues. Avoid exposing the GE IC693MDL753CA to extreme moisture or corrosive chemicals, as these can damage its internal components over time.
Application fields
Automotive manufacturing: In car assembly plants, the GE IC693MDL753CA controls devices like robotic grippers and conveyor stoppers. When the PLC’s CPU receives a signal that a car part is in position (from an input module like the GE IC693MDL240), the GE IC693MDL753CA activates the gripper to pick up the part or stops the conveyor to hold the part steady. Its 16 channels allow it to manage multiple steps in the assembly process, ensuring parts are moved and positioned accurately.
Packaging machinery: The GE IC693MDL753CA is used in packaging lines to control sealers, labelers, and carton formers. It activates heat sealers when a package is in place and triggers labelers to apply stickers at the right moment. If a sensor detects a misaligned package, the module can stop the line via a conveyor brake. Its reliable performance ensures packages are sealed and labeled correctly, reducing waste from faulty products.
Material handling: In warehouses and distribution centers, the GE IC693MDL753CA controls motor starters for conveyor belts and sorters. It starts or stops belts based on signals from sensors that detect pallet or box presence. It can also activate pushers to redirect items to different chutes. The module’s durability is valuable here, as warehouses often have dusty environments and constant vibration from machinery.
Food and beverage processing: The GE IC693MDL753CA manages valves in food processing lines. It opens valves to release ingredients into mixers and closes them when the correct amount is added. It also controls door locks on ovens and freezers to ensure they stay closed during operation. Its 24V DC compatibility works with the hygienic, low-voltage equipment common in food facilities, and its protective design prevents issues from occasional spills or washdowns.
IC693MDL753CA
Product guarantee
Our company offers a one-year quality warranty service for the GE IC693MDL753CA. This warranty covers hardware malfunctions not caused by human factors. During the warranty period, if the GE IC693MDL753CA shows abnormal performance—such as unresponsive output channels or failed LEDs—we will provide a replacement.
Our company is a leading import and export trade distribution company in the industrial control industry. We were established in 2007 and have 17 years of experience. We specialize in selling industrial control parts from major brands, including many unpopular and discontinued models. We have a large stock of products, so we can often supply the GE IC693MDL753CA immediately, even for urgent needs.
We have strong supply channels that allow us to meet customers’ urgent demands for spare parts. Whether you need the GE IC693MDL753CA to replace a faulty module or to expand your system, we can quickly respond to your procurement needs. Our main business includes distributing PLC modules, DCS cards, ESD system cards, and other industrial control products. We are committed to supporting the continuous and stable operation of your industrial systems with reliable parts and services.
