Product Overview: GE IC693MDL240G Digital Output Module
The GE IC693MDL240G is a digital output module. It is part of the GE Series 90-30 programmable logic controller (PLC) system. This module serves a key role in industrial automation. It converts electrical signals from the PLC into commands. These commands control external devices. Such devices include relays, solenoids, and contactors.
The GE IC693MDL240G is designed to handle high-density digital output operations. It features multiple output channels. Each channel can switch electrical loads on or off. This capability allows it to manage several devices at once. It is critical for coordinating sequential tasks in industrial processes.
The GE IC693MDL240G integrates with the Series 90-30 baseplate and CPU modules. It receives control signals from the CPU. It then translates these signals into actions for connected equipment. This integration makes the GE IC693MDL240G a vital component in automation systems. It ensures that PLC decisions result in precise physical responses. This precision is needed for efficient manufacturing and process control.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | GE |
| Product type | Digital Output Module |
| Series | GE Series 90-30 |
| Physical dimensions | 5.12 inches (height) x 3.54 inches (width) x 5.59 inches (depth) |
| Weight | 0.77 pounds (0.35 kilograms) |
| Country of origin | United States |
| Power requirements | 24 volts DC (output circuit); 5 volts DC, 120 mA (logic circuit) |
| Number of outputs | 16 channels |
| Output current | 2 amps per channel (maximum) |
| Operating temperature | 0°C to 60°C (32°F to 140°F) |
| Isolation | Channel-to-channel and channel-to-logic isolation |
IC693MDL240G
Related products
- GE IC693MDL241: This is a digital output module. It has 16 channels. It operates at 120 volts AC. It differs from the GE IC693MDL240G in voltage rating. It suits AC-powered devices.
- GE IC693MDL250: This is a 32-channel digital output module. It offers more channels than the GE IC693MDL240G. It is for systems needing higher output density.
- GE IC693MDL940: This is a digital input module. It works with the GE IC693MDL240G. It collects input signals. The PLC uses these signals to trigger outputs via the GE IC693MDL240G.
- GE IC693CPU350: This is a CPU module. It sends control signals to the GE IC693MDL240G. It processes input data. It determines when outputs should activate.
- GE IC693CHS397L: This is a 5-slot baseplate. It houses the GE IC693MDL240G and other modules. It provides electrical connections between components.
- GE IC693PWR321: This is a power supply module. It provides 5 volts DC for the GE IC693MDL240G’s logic circuit. It ensures stable operation.
Main features and advantages
High output capacity: The GE IC693MDL240G has 16 digital output channels. Each channel can control a separate device. This allows the module to manage multiple components in an automation system. It reduces the need for additional modules. It saves space in control cabinets.
High output capacity: The GE IC693MDL240G has 16 digital output channels. Each channel can control a separate device. This allows the module to manage multiple components in an automation system. It reduces the need for additional modules. It saves space in control cabinets.
Rugged design: The GE IC693MDL240G is built for industrial environments. It operates in temperatures from 0°C to 60°C. It resists vibration and electromagnetic interference. This durability ensures reliable performance. It minimizes downtime in factories and processing plants.
LED status indicators: The GE IC693MDL240G has LED lights for each channel. These lights show if an output is active. They make it easy to troubleshoot. Users can quickly identify issues like failed outputs or loose connections.
Easy integration: The GE IC693MDL240G fits into Series 90-30 baseplates. It connects to the PLC’s backplane. No complex wiring is needed. This simplifies installation. It reduces setup time.
Overload protection: The GE IC693MDL240G has built-in overload protection. It prevents damage from excessive current. This protects both the module and connected devices. It extends service life.
Compatibility: The GE IC693MDL240G works with other Series 90-30 modules. Users can mix and match components. They can build custom automation systems. This flexibility makes it suitable for diverse applications.
IC693MDL240G
Installation and maintenance
Pre-installation preparations: Check that the Series 90-30 baseplate (such as the GE IC693CHS397L) has an available slot. Ensure the slot is clean. Verify that the power supply (such as the GE IC693PWR321) provides 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power before installing the GE IC693MDL240G. Align the module with the slot. Push it firmly until it seats. Secure it with screws.
Pre-installation preparations: Check that the Series 90-30 baseplate (such as the GE IC693CHS397L) has an available slot. Ensure the slot is clean. Verify that the power supply (such as the GE IC693PWR321) provides 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power before installing the GE IC693MDL240G. Align the module with the slot. Push it firmly until it seats. Secure it with screws.
Maintenance suggestions: Inspect the GE IC693MDL240G regularly. Check for loose connections at the output terminals. Clean the module with a dry cloth. Remove dust that could block heat dissipation. Monitor the LED indicators. A steady light means an output is active. A dim or off light may indicate a problem. Test outputs periodically. Ensure they respond to signals from the PLC. Replace faulty channels promptly to avoid system issues.
Application fields
Manufacturing: The GE IC693MDL240G controls relays and solenoids in assembly lines. It activates robotic arms. It triggers conveyor belt motors. It coordinates steps in production. This ensures smooth operation. It maintains consistent product quality.
Manufacturing: The GE IC693MDL240G controls relays and solenoids in assembly lines. It activates robotic arms. It triggers conveyor belt motors. It coordinates steps in production. This ensures smooth operation. It maintains consistent product quality.
Automotive industry: The GE IC693MDL240G is used in car manufacturing. It controls welding machines. It operates paint sprayers. It manages material handling systems. It ensures precise timing of operations. It improves production efficiency.
Packaging: The GE IC693MDL240G controls packaging machinery. It activates sealers. It triggers label applicators. It starts and stops filling machines. It ensures packages are sealed and labeled correctly. It reduces waste from misaligned packaging.
Food and beverage processing: The GE IC693MDL240G controls valves and pumps. It regulates the flow of ingredients. It activates mixing motors. It ensures processes like blending and bottling follow set recipes. It meets food safety standards.
Water treatment: The GE IC693MDL240G controls solenoid valves in water treatment plants. It opens and closes valves for filtration. It activates chemical dosing pumps. It ensures water is treated correctly. It meets regulatory standards for water quality.
Installation and maintenance
Pre-installation preparations: Check the baseplate for an empty slot. Ensure the slot is free of debris. Confirm the power supply can deliver 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power. Align the GE IC693MDL240G with the slot. Push it into place. Secure it with screws. Connect output devices to the terminal block.
Pre-installation preparations: Check the baseplate for an empty slot. Ensure the slot is free of debris. Confirm the power supply can deliver 5 volts DC for logic and 24 volts DC for outputs. Turn off the baseplate power. Align the GE IC693MDL240G with the slot. Push it into place. Secure it with screws. Connect output devices to the terminal block.
Maintenance suggestions: Inspect the GE IC693MDL240G monthly. Check output terminals for tightness. Clean the module with a dry cloth. Look at the LED indicators during operation. Test each output by sending a signal from the PLC. Replace the module if multiple outputs fail. This prevents system disruptions.
IC693MDL240G
Main features and advantages
The GE IC693MDL240G offers reliable control of 16 devices. Its 16 channels meet the needs of medium-scale automation systems. It avoids the cost of larger modules. It fits well in systems with moderate output requirements.
The GE IC693MDL240G offers reliable control of 16 devices. Its 16 channels meet the needs of medium-scale automation systems. It avoids the cost of larger modules. It fits well in systems with moderate output requirements.
The module’s rugged build ensures long life. It works in harsh conditions. Factories have dust, vibration, and temperature changes. The GE IC693MDL240G handles these. It reduces replacement costs.
LED indicators simplify troubleshooting. Each channel has a light. Users can see active outputs at a glance. They can quickly find issues. This cuts down on maintenance time.
The GE IC693MDL240G integrates easily with Series 90-30 components. It fits into standard baseplates. It connects to the PLC without special tools. This makes installation straightforward. It is ideal for both new systems and upgrades.
Overload protection is a key feature. It stops excessive current from damaging the module. It protects connected devices like motors and valves. This safety feature reduces repair costs. It prevents system failures.
Product guarantee
Our company offers a one-year quality warranty for the GE IC693MDL240G. This warranty covers hardware malfunctions not caused by human factors. During the warranty period, if the GE IC693MDL240G shows abnormal performance or fails, we will provide a replacement. Our company is a leading enterprise in the industrial control industry. It was established in 2007. It has 17 years of experience. We are an import and export trade distribution company. We sell major brands of industrial control parts. We have many unpopular and discontinued models. We have a large stock. Our supply channels are strong. We have many products in stock. We can meet the needs of customers who need spare parts quickly. Our main business includes distribution and trade of PLC modules, DCS cards, ESD system cards, vibration monitoring system cards, turbine control system modules, gas generator spare parts, and instruments. For discontinued models or urgent needs, our global supply chain network lets us respond quickly. We provide reliable services. We support the continuous and stable operation of industrial systems.
