GE IC693CPU360-EL Series 90-30 Enhanced CPU Module
Product Overview
The GE IC693CPU360-EL is an enhanced central processing unit (CPU) module designed for GE’s Series 90-30 programmable logic controller (PLC) system. It serves as the core of industrial automation systems, processing data from input modules and sending control signals to output modules. This functionality makes it critical for managing complex machinery and processes in manufacturing, energy, and water treatment sectors.
The GE IC693CPU360-EL features a 386SX processor running at 33 MHz, offering higher processing power than basic Series 90-30 CPUs. It includes 128 KB of user memory, expandable to 512 KB with an optional memory module. This capacity allows it to handle large control programs and complex logic, such as coordinating multiple production lines or regulating advanced industrial processes.
As part of the Series 90-30 platform, the GE IC693CPU360-EL integrates seamlessly with other modules, including the IC693PWR330 power supply, IC693MDL740K digital input module, and IC693BEM331 Ethernet module. It fits into standard Series 90-30 racks like the IC693CHS397, ensuring compatibility with existing systems. Its rugged design operates in temperatures from 0°C to 60°C, resisting dust and vibrations common in factory environments, making it reliable for continuous industrial use.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693CPU360-EL |
| Manufacturer | GE |
| Product Type | Enhanced CPU Module |
| Series | Series 90-30 |
| Processor | 386SX microprocessor, 33 MHz |
| User Memory | 128 KB RAM (expandable to 512 KB via memory module) |
| I/O Capacity | 1024 discrete I/O points; 128 analog input/output points |
| Communication Ports | 2 x RS-232/422/485 (supports SNP, Modbus RTU) |
| Physical Dimensions | 110mm (L) × 64mm (W) × 30mm (D) |
| Weight | 0.4 kg |
| Operating Temperature | 0°C to 60°C |
| Power Consumption | 500 mA at 5V DC; 100 mA at 24V DC |
| Mounting | Fits in Series 90-30 racks (e.g., IC693CHS397) |
| Country of Origin | United States |
IC693CPU360-EL
Related Products
- GE IC693PWR330: A power supply module that provides 5V DC and 24V DC to the IC693CPU360-EL and other Series 90-30 components, ensuring stable operation.
- GE IC693CHS397: A 10-slot rack that houses the IC693CPU360-EL and other modules, organizing components in control cabinets for efficient wiring.
- GE IC693MDL740K: A digital input module that connects to sensors and switches, sending data to the IC693CPU360-EL for processing in manufacturing lines.
- GE IC693ALG220: An analog input module that measures variables like temperature and pressure, transmitting data to the IC693CPU360-EL for regulatory control.
- GE IC693BEM331: An Ethernet communication module that links the IC693CPU360-EL to industrial networks, enabling remote monitoring and data logging.
- GE IC693CMM302: A serial communication module that extends the IC693CPU360-EL’s connectivity to RS-232/485 devices such as HMIs and printers.
- GE IC693ACC302B: A backup battery module that preserves program data in the IC693CPU360-EL during power outages, preventing data loss.
Main features and advantages
Enhanced processing power: The IC693CPU360-EL uses a 386SX processor at 33 MHz. This speed allows it to handle complex control logic. It processes 1K of boolean logic in 0.1 milliseconds. This capability is critical for applications like synchronizing multiple robotic arms in an automotive assembly line.
Expanded memory: The module includes 128 KB of user memory. This memory can be expanded to 512 KB with an optional module. This allows users to store large programs. It also lets users save extensive data, such as production logs and fault records, without performance loss.
Increased I/O capacity: The IC693CPU360-EL supports up to 1024 discrete I/O points and 128 analog I/O points. This range fits large-scale applications. It can control entire production lines with dozens of machines. It can also monitor multiple tanks and pumps in a water treatment plant.
Dual communication ports: The module has two RS-232/422/485 ports. These ports support SNP and Modbus RTU protocols. This allows simultaneous connection to HMIs and other PLCs. It simplifies system integration. It reduces the need for additional communication modules.
Industrial durability: The IC693CPU360-EL operates in temperatures from 0°C to 60°C. It resists dust, vibrations, and electrical noise. It functions reliably in harsh environments, such as near welding machines or in outdoor pump stations. This durability reduces downtime and maintenance costs.
Series 90-30 compatibility: The module works with all Series 90-30 components. It fits into standard racks. It integrates with power supplies, I/O modules, and communication devices. This compatibility allows users to upgrade from basic CPUs without replacing their entire system, saving time and money.
IC693CPU360-EL
Installation and maintenance
Pre-installation preparations: Turn off power to the Series 90-30 rack, such as the IC693CHS397. Check that the rack has an open slot for the IC693CPU360-EL. Verify that the power supply, like the IC693PWR330, provides 5V DC at 500 mA and 24V DC at 100 mA. Gather a screwdriver and anti-static wristband to prevent damage from electrostatic discharge. Ensure the rack is mounted securely on a DIN rail or panel.
Maintenance suggestions: Inspect the IC693CPU360-EL monthly. Check for loose connections or dust buildup. Wipe the surface with a dry cloth. Monitor the LED indicators on the front panel. Steady green lights indicate normal operation. Flashing or red lights signal issues, such as communication errors or power problems. Replace the backup battery, if used, every two years to ensure data retention during power outages. If the module fails, replace it with a new or refurbished IC693CPU360-EL following proper shutdown procedures to avoid damaging connected modules.
Application fields
The GE IC693CPU360-EL is widely used in industries requiring advanced automation:
In automotive manufacturing, it controls entire assembly lines. It processes data from hundreds of sensors. These sensors monitor part positions and robot movements. It sends signals to output modules to adjust conveyor speeds and trigger welding cycles. Its high processing power ensures smooth coordination between machines, reducing production delays.
In energy plants, the IC693CPU360-EL manages generator systems. It monitors fuel flow, temperature, and voltage via analog input modules. It adjusts valves and pumps to maintain stable power output. Its dual communication ports send real-time data to SCADA systems and local HMIs, supporting both remote monitoring and on-site control.
In water treatment facilities, it regulates complex processes. It controls filtration systems, chemical dosing pumps, and distribution valves. It processes data from pH and turbidity sensors. It adjusts operations to meet water quality standards. Its expanded memory stores historical data, aiding in regulatory compliance reporting.
In large-scale food processing, the IC693CPU360-EL coordinates mixing, cooking, and packaging lines. It monitors temperature and pressure in ovens and mixers. It adjusts settings to ensure product consistency. Its durability allows it to function in humid environments, such as near washing stations, without performance issues.
IC693CPU360-EL
Product guarantee
Our company offers a one-year quality warranty service for the IC693CPU360-EL, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems.
