Product Overview
The GE IC693CPU351DH is a high-performance programmable logic controller (PLC) designed for GE’s Series 90-30 automation platform, delivering reliable control for industrial processes in manufacturing, power generation, and oil and gas sectors. As a single-slot CPU module, the IC693CPU351DH integrates a 25 MHz 80386EX processor and 240 KB user program memory, enabling real-time execution of complex logic, motion control, and data acquisition tasks. It supports up to 7 expansion racks and 2048 I/O points, making it suitable for large-scale automation systems requiring high scalability.
Engineered for rugged environments, the IC693CPU351DH operates within 0°C to 60°C and features a compact design (127mm x 127mm x 76mm) with 0.5 kg weight, ensuring easy integration into space-constrained control cabinets. Its three serial ports (RS-232/485) support protocols like SNP/X, RTU, and ASCII, while the built-in Ethernet interface enables seamless connectivity to HMIs, SCADA systems, and cloud platforms via Modbus TCP and Ethernet/IP 711. The module also includes battery-backed RAM and flash memory for program storage, ensuring data integrity during power outages.
Within the Series 90-30 ecosystem, the IC693CPU351DH interfaces with modules like IC693CHS397 (rack), IC693PWR330 (power supply), and IC695CRU320 (communication module), forming a cohesive control architecture. Its hot-swappable design allows field replacements without system downtime, reducing maintenance costs in 24/7 operations.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | IC693CPU351DH |
| Manufacturer | GE |
| Product Type | PLC Controller Module |
| Series | Series 90-30 |
| Processor | 80386EX, 25 MHz |
| User Program Memory | 240 KB |
| Communication Interfaces | Ethernet (10/100 Mbps), RS-232/485 (x3) |
| Supported Protocols | Modbus TCP, Ethernet/IP, SNP/X, RTU, ASCII |
| Power Supply | +5 VDC, 890 mA (max) |
| Physical Dimensions | 127 mm (W) × 127 mm (H) × 76 mm (D) |
| Weight | 0.5 kg |
| Operating Temperature | 0°C to 60°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (Series 90-30 compatible) |
| I/O Capacity | Up to 2048 discrete I/O, 32,640 analog I/O |
| Redundancy Support | Optional via external modules (e.g., IC695CRU320) |
| Compliance | CE, UL 508 (pending verification) |
Main Features and Advantages
High-Performance Processing
The IC693CPU351DH’s 25 MHz 80386EX processor and 240 KB user memory enable rapid execution of ladder logic, structured text, and motion control algorithms. Its 0.22 ms/kB scan rate ensures real-time response in applications like conveyor belt synchronization or turbine speed regulation 711.
Versatile Communication
With three serial ports and Ethernet connectivity, the module supports diverse communication scenarios:
- Modbus TCPfor integration with third-party devices
- Ethernet/IPfor industrial IoT (IIoT) and cloud-based analytics
- SNP/Xfor seamless interaction with GE’s Genius Bus modules
- RTU/ASCIIfor legacy equipment retrofitting 712.
Rugged Industrial Design
Built with a conformal-coated circuit board and metal enclosure, the IC693CPU351DH withstands vibrations, electromagnetic interference (EMI), and harsh temperatures. Its wide operating range (0°C to 60°C) makes it suitable for offshore platforms, chemical plants, and outdoor installations 11.
Scalable Architecture
The module supports 7 expansion racks and 2048 I/O points, allowing users to scale from small-scale projects to complex systems. It works with IC693CHS397 racks and IC693PWR330 redundant power supplies to create fault-tolerant control systems 511.
Easy Maintenance
LED indicators provide real-time status feedback for power, communication, and I/O activity. The hot-swappable design allows field replacement of faulty modules without system shutdown, while battery-backed RAM ensures program retention during maintenance 311.
Application Fields
Manufacturing
- Packaging Machinery: Controls conveyor belts, robotic arms, and filling systems to optimize production line efficiency.
- Automotive Assembly: Manages welding robots, quality inspection sensors, and material handling systems for high-precision manufacturing
Power Generation
- Turbine Control: Regulates steam/gas turbine speed, fuel injection, and load distribution in thermal power plants.
- Renewable Energy: Monitors solar panel arrays and wind turbine performance, ensuring grid stability and energy optimization
Oil and Gas
- Pipeline Monitoring: Collects data from pressure/temperature sensors and controls valve actuators to prevent overpressure events.
- Refinery Automation: Manages distillation units, pumps, and compressors for safe and efficient crude oil processing.
Water Treatment
- Wastewater Management: Controls pump stations, filtration systems, and chemical dosing equipment to meet environmental compliance standards.
- Irrigation Systems: Optimizes water distribution in agricultural settings using real-time flow and level monitoring.
Related Products
- GE IC693CPU350: Lower-cost alternative with 32 KB user memory, ideal for small-scale applications requiring basic logic control.
- GE IC695CRU320: Communication module enabling Ethernet/IP, Profibus, and Modbus TCPconnectivity, expanding the IC693CPU351DH’s network capabilities.
- GE IC693CHS397: Rack system supporting up to 7 I/O modules, ensuring scalable infrastructure for the IC693CPU351DH.
- GE IC693PWR330: Redundant power supply providing +5 VDCto the IC693CPU351DH and other Series 90-30 modules, enhancing system reliability.
- GE IC693MDL940: Digital input/output module with 32 isolated channels, compatible with the IC693CPU351DHfor discrete control applications.
- GE IC693ALG221: Analog input module supporting 4-20 mA signals, used alongside the IC693CPU351DHfor process monitoring in oil refineries.
Installation and Maintenance
Pre-installation preparations: Verify the Series 90-30 rack is securely grounded and powered with +5 VDC ±5%. Align the IC693CPU351DH with the rack’s CPU slot, secure it with captive screws, and torque terminal connections to 0.8–1.0 N·m. Use shielded cables for Ethernet and serial connections to minimize EMI. Configure the module via Proficy Machine Edition software, assigning IP addresses and communication protocols 57.
Maintenance suggestions: Conduct monthly visual inspections to check for loose connectors, damaged cables, or LED warnings. Clean dust from ventilation slots using compressed air to prevent overheating. Quarterly, update firmware via Proficy to ensure compatibility with newer modules. For redundant systems, test power supplies and communication links individually to validate failover functionality. When replacing the IC693CPU351DH, label all cables before disconnection and retest I/O channels post-installation 311.
Product Guarantee
Our company offers a one-year quality warranty for the IC693CPU351DH, covering hardware malfunctions not caused by human factors. During the warranty period, we provide replacement services for abnormal performance or functional failures. For urgent demands, our global supply chain ensures 48-hour delivery of in-stock modules, minimizing downtime. As a leading industrial control distributor with 17 years of experience, we maintain extensive inventory of Series 90-30 components, including discontinued models like the IC693CPU351DH, and offer technical support for wiring diagrams, firmware updates, and on-site commissioning.
