GE IC693CPU350 | Central Processing Unit (CPU) Module | IC693CPU364-CJ

Description

GE IC693CPU350 Product Specification

Product Overview

The GE IC693CPU350 is a central processing unit (CPU) module designed for GE’s Series 90-30 programmable logic controller (PLC) systems. It serves as the core component of automation systems, responsible for executing control programs, processing data from input modules, and sending commands to output modules. This functionality makes it essential for managing industrial processes in various settings.

The GE IC693CPU350 operates with a 32-bit microprocessor. It offers sufficient processing power to handle medium-complexity control tasks. These tasks include sequence control, timing, and simple arithmetic operations. The module is part of GE’s Series 90-30 family, which is widely used in industrial automation due to its reliability and compatibility with a range of I/O modules.

The GE IC693CPU350 features 512 KB of user memory for storing control programs and data. This memory capacity is suitable for most medium-scale applications. It connects to other Series 90-30 modules via a backplane, enabling seamless communication within the PLC system. The module also includes status indicators on its front panel. These indicators show power status, program execution, and error conditions, facilitating quick troubleshooting.

Built to withstand industrial environments, the GE IC693CPU350 operates in temperatures ranging from 0°C to 60°C. It can also function in humidity levels between 5% and 95% without condensation. This durability ensures consistent performance in factories, power plants, and other harsh industrial settings.

Technical Specifications

IC693CPU350

Main Features and Advantages

Processing capability: The GE IC693CPU350 is equipped with a 32-bit microprocessor. This processor delivers a execution speed of 0.8 ms per kilobyte of ladder logic. This speed is sufficient for medium-complexity control tasks. It ensures that control programs run efficiently, with minimal delay in responding to input signals.

Memory capacity: The module includes 512 KB of user memory. This memory can store control programs, setpoints, and temporary data. It is adequate for most medium-scale applications, such as assembly line control or small-scale process automation.

Compatibility: The GE IC693CPU350 works seamlessly with all Series 90-30 modules. These modules include input/output (I/O) modules, communication modules, and power supplies. This compatibility allows users to build customized PLC systems tailored to their specific needs.

Industrial durability: The GE IC693CPU350 is designed to operate in harsh industrial environments. It can withstand temperatures from 0°C to 60°C. It is also resistant to humidity, dust, and vibration. This durability reduces the risk of downtime due to environmental factors.

Status monitoring: Front-panel indicators on the GE IC693CPU350 provide real-time feedback. They show whether the module is powered, whether the program is running, and whether any errors have occurred. This makes it easy for technicians to diagnose issues quickly, reducing maintenance time.

Related Products

• GE IC693CHS391M: A 10-slot rack that houses the GE IC693CPU350and other Series 90-30 modules, providing mechanical support and backplane connectivity.
• GE IC693PWR330: A power supply module that delivers 5 VDC to the GE IC693CPU350and other modules in the rack, ensuring stable operation.
• GE IC693MDL740: A 16-point discrete output module that receives commands from the GE IC693CPU350to control devices such as motors and valves.
• GE IC693ALG222: An analog input module that sends sensor data (e.g., temperature, pressure) to the GE IC693CPU350for processing.
• GE IC693BEM331M: A Genius Bus Interface module that enables the GE IC693CPU350to communicate with remote I/O modules over a Genius bus network.
• GE IC693CMM311: A communication module that allows the GE IC693CPU350to exchange data with external systems (e.g., HMIs, SCADA) using the Modbus RTU protocol.


  IC693CPU350

Installation and Maintenance

Pre-installation preparations: Before installing the GE IC693CPU350, ensure the Series 90-30 rack (such as IC693CHS391M) is powered off. Check that the rack is properly grounded to prevent electrostatic discharge. Use an anti-static wristband when handling the module to protect its internal components. Align the module with the designated slot in the rack. Slide it in until it locks into place. Ensure the connection to the backplane is secure.

Maintenance suggestions: Regularly inspect the GE IC693CPU350 for signs of damage or loose connections. Clean dust from the module and the rack using compressed air every three months. This prevents overheating. Check the front-panel indicators periodically to ensure the module is operating normally. If an error indicator lights up, refer to the user manual to diagnose the issue. Replace the module if it fails to function despite troubleshooting.

Application Areas

In manufacturing: The GE IC693CPU350 is used to control assembly lines. It processes data from proximity sensors that detect the presence of parts. It then sends commands to robotic arms to perform tasks such as welding or fastening. This ensures that the assembly process is efficient and consistent.

In food processing: The module manages small-scale processing lines. It monitors temperature and pressure in cooking or mixing equipment via analog input modules. It adjusts heating elements or 搅拌器 speeds to maintain optimal conditions, ensuring product quality and safety.

In water treatment: The GE IC693CPU350 controls pump stations. It receives signals from level sensors in water tanks. It activates or deactivates pumps to maintain water levels within desired ranges, preventing overflow or underflow.

In packaging: The module coordinates packaging machinery. It processes data from photo eyes that detect product position. It triggers sealing or labeling devices at the correct time, ensuring packages are properly sealed and labeled.
