GE IC693CBK001 | Backplane connector | IC693CBL328C

Description

Product Overview

The IC693CBK001 is a key component in GE’s Series 90-30 PLC system, serving as a backplane connector that links various modules within the PLC rack. This small but critical part ensures seamless communication and power distribution between modules like CPUs, power supplies, and I/O modules, making it essential for the overall functionality of the automation system. As a genuine GE part, IC693CBK001 is designed to fit perfectly with other Series 90-30 components, creating a reliable connection that minimizes signal loss and ensures consistent performance.

In industrial settings, where even minor disruptions can halt production, IC693CBK001 plays a vital role in maintaining system integrity. It acts as the “nervous system” of the PLC rack, allowing data and power to flow smoothly between connected modules. Whether in a factory floor control system or a process plant, IC693CBK001 ensures that each module can communicate with the others, supporting real-time monitoring and control. Its robust design makes it a trusted choice for engineers looking to build stable, long-lasting automation setups with Series 90-30 PLCs.

Technical Specifications
Product model | IC693CBK001
Manufacturer | GE
Product type | Backplane connector (Series 90-30 PLC)
Physical dimensions | 100 mm (length) × 50 mm (width) × 20 mm (height)
Weight | 0.2 kg
Material | Metal contacts with plastic housing
Number of pins | 32 pins
Operating temperature range | 0°C to 60°C
Compatibility | GE Series 90-30 PLC racks

Related products

IC693CPU364: A central processing unit (CPU) module for the Series 90-30 system, which connects to the rack via IC693CBK001 to manage overall system operations.

IC693PWR321: A 24V DC power supply module that relies on IC693CBK001 to distribute power to other modules in the Series 90-30 rack.

IC693BEM331: A communication module that uses IC693CBK001 to connect to the backplane, enabling data exchange between the PLC and external devices.

IC693MDL240: A digital input module that links to the rack through IC693CBK001, allowing the system to collect signals from sensors and switches.

IC693CMM321: A memory module that stores program data, connecting to the backplane via IC693CBK001 to ensure data is accessible to the CPU.

IC693ALG220: An analog input module that uses IC693CBK001 to integrate with the Series 90-30 rack, processing continuous signals from devices like pressure gauges.

IC693MDL645: A digital output module that connects through IC693CBK001 to receive commands from the CPU and control actuators or valves.

Main features and advantages

The IC693CBK001 stands out for its durable construction, with metal contacts that resist corrosion and wear, even in dusty or humid industrial environments. This durability ensures long-term reliability, reducing the need for frequent replacements and keeping maintenance costs low. The plastic housing adds strength without adding excess weight, making the connector easy to handle during installation.

Another key advantage of IC693CBK001 is its precise fit with Series 90-30 racks and modules. The 32-pin design aligns perfectly with corresponding ports, creating a tight connection that prevents signal interference or power loss. This precision is crucial for maintaining consistent data flow between modules, which is essential for real-time control in automation systems.

The IC693CBK001 also offers easy installation. Its compact size and clear alignment markers make it simple to insert into the rack, even in tight spaces. Once installed, it stays securely in place, reducing the risk of accidental disconnections that could disrupt operations. This combination of durability, precision, and ease of use makes IC693CBK001 an indispensable part of reliable Series 90-30 PLC systems.

Installation and maintenance

Pre-installation preparations: Before installing IC693CBK001, ensure the Series 90-30 rack is powered off and disconnected from the main supply to avoid electrical hazards. Inspect the rack’s backplane slot for dust, debris, or damage—clean it gently with a dry cloth if needed. Check the IC693CBK001 itself for bent pins or cracks in the housing, as damaged parts can cause connection issues. Align the connector with the slot’s guides to ensure proper fitting during installation.

Maintenance suggestions: To keep IC693CBK001 working well, inspect it quarterly. Power off the rack, then check for loose connections or signs of corrosion on the pins—use a soft brush to remove dust if buildup is present. Avoid using water or cleaning fluids, as they can damage the metal contacts. If pins appear bent or the housing is cracked, replace the IC693CBK001 promptly to prevent signal loss. During routine system checks, verify that all connected modules are communicating properly, as poor communication may indicate a problem with the connector.

Application fields

The IC693CBK001 is widely used in manufacturing facilities that rely on GE Series 90-30 PLCs to control production lines. In automotive plants, for example, it connects CPU modules, I/O modules, and communication modules in the PLC rack, ensuring that robotic arms, conveyor belts, and quality checks work together smoothly. Without IC693CBK001, these modules might not communicate, leading to delays or errors in assembly.

In food and beverage processing, IC693CBK001 plays a key role in maintaining control systems that monitor temperature, pressure, and flow rates. It connects modules that track pasteurization times or manage filling machines, ensuring these processes stay within safe limits. The connector’s ability to work in 0°C to 60°C temperatures makes it suitable for cold storage areas and heated processing zones alike.

Water treatment plants also depend on IC693CBK001 to link PLC modules that control pumps, valves, and filtration systems. By ensuring reliable communication between these modules, the connector helps operators monitor water quality and adjust processes in real time, preventing equipment failures and ensuring safe water output. Across all these fields, IC693CBK001 is a small but critical part of keeping automation systems running smoothly.

Product guarantee

Our company offers a one-year quality warranty service for the IC693CBK001, covering hardware malfunctions not caused by human factors. During the warranty period, if the IC693CBK001 shows abnormal performance or functional failure, we will provide replacement services. As a leading import and export trade distribution company with 17 years of experience, we have a large stock of industrial control parts, including hard-to-find and discontinued models. Our supply channels allow us to quickly meet urgent needs for spare parts. Whether you need a replacement IC693CBK001 or support for other Series 90-30 components, we are committed to ensuring your automation systems stay operational with minimal downtime.
