GE IC66088R101 Control Module
Product Overview
The GE IC66088R101 is a high-performance control module designed for industrial automation systems, specifically engineered to integrate with GE’s Series One PLC platform. Serving as a critical component in manufacturing, energy, and infrastructure sectors, the IC66088R101 processes digital and analog signals, executes control logic, and coordinates system operations to ensure precise automation. Its modular design and robust construction make it suitable for applications requiring reliability in harsh industrial environments.
Engineered for versatility, the IC66088R101 supports 24V DC inputs/outputs and features 16 channels for monitoring and controlling field devices such as sensors, actuators, and relays. Its 1ms response time ensures rapid signal processing, making it ideal for time-sensitive applications like conveyor belt synchronization or emergency stop systems. The module operates across -20°C to 70°C and withstands 5–95% non-condensing humidity, with a rugged metal enclosure that resists vibration and electromagnetic interference (EMI)—critical for automotive plants, chemical facilities, and outdoor installations.
Within the Series One ecosystem, the IC66088R101 interfaces seamlessly with controllers like IC600CPU001 and power supplies such as IC660PWR101, forming a cohesive control infrastructure. LED indicators provide real-time status for each channel, simplifying diagnostics and reducing downtime. Compliance with UL 508 and IEC 61131-2 standards underscores its reliability in regulated industries, where accurate signal processing is essential for process safety and efficiency.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | IC66088R101 |
| Manufacturer | GE |
| Product Type | Control Module |
| Series | Series One |
| Signal Type | Digital/Analog Hybrid |
| Input Channels | 8 (24V DC) |
| Output Channels | 8 (24V DC, 0.5A max) |
| Response Time | 1ms (digital), 5ms (analog) |
| Physical Dimensions | 152mm (L) × 102mm (W) × 76mm (D) |
| Weight | 0.6 kg |
| Operating Temperature | -20°C to 70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail or panel-mounted |
| Isolation | 250V AC (channel-to-ground) |
| Compliance | UL 508, IEC 61131-2, CE |
| Country of Origin | United States |
Main Features and Advantages
Hybrid Signal Processing
The IC66088R101 combines 8 digital inputs and 8 digital outputs in a single module, offering flexibility for applications requiring both monitoring and actuation. This hybrid design reduces chassis space and simplifies wiring in systems like packaging machines, where proximity sensors (digital inputs) and solenoid valves (digital outputs) operate concurrently.
High-Speed Performance
With a 1ms response time for digital signals and 5ms for analog, the module ensures real-time control in dynamic environments. For example, in a steel mill, it can detect temperature fluctuations (analog input) and adjust cooling systems (digital output) within milliseconds, preventing material deformation.
Rugged Industrial Design
Built with a corrosion-resistant metal enclosure, the IC66088R101 withstands extreme temperatures (-20°C to 70°C), 10–500Hz vibration, and 5–95% humidity. Its conformal coating protects against dust and moisture, ensuring long-term performance in food processing plants (with frequent washdowns) or oil refineries (with high airborne particulates).
Diagnostic Efficiency
LED indicators for each channel provide instant visual feedback on signal status, enabling technicians to quickly identify faulty sensors or wiring issues. This feature is particularly valuable in large-scale systems, such as water treatment plants, where manual troubleshooting across extensive sensor networks would be time-consuming.
Easy Integration
The module connects directly to Series One chassis via a DIN rail mount, eliminating the need for additional adapters. It pairs with IC600CPU001 controllers and IC660PWR101 power supplies, forming a unified control system that reduces compatibility issues and streamlines maintenance.
Application Fields
The GE IC66088R101 excels in industries requiring hybrid signal control:
- Automotive Manufacturing: Monitors robotic arm positions (digital inputs) and actuates pneumatic grippers (digital outputs) in assembly lines. Its fast response time ensures precise part handling and reduces collision risks.
- Chemical Processing: Controls batch reactor temperature (analog input) and valve openings (digital output) in real time. The module’s rugged design ensures reliability in corrosive environments.
- Water Treatment: Detects flow rates (analog input) and adjusts pump speeds (digital output) in filtration systems. Its diagnostic LEDs simplify maintenance in humid, dusty plant environments.
- Material Handling: Coordinates conveyor belt speed (analog input) and pallet diverters (digital output) in warehouses. The hybrid design supports both sensor inputs and motor control outputs in a single module.
Related Products
- GE IC600CPU001: Series One controller that processes data from the IC66088R101, executing ladder logic to control industrial processes.
- GE IC660PWR101: 24V DC power supply for the IC66088R101, ensuring stable voltage during operation.
- GE IC660MDL179: Digital input module with 16 channels, commonly paired with the IC66088R101for systems requiring additional sensor monitoring.
- GE IC660MDL240: Digital output module that works with the IC66088R101to actuate high-power devices like motors and solenoids.
- GE IC660ALG220: Analog input module for converting 4-20mA signals from pressure/temperature transducers, expanding the system’s sensing capabilities.
- GE IC660CBL101: Shielded cable for connecting field devices to the IC66088R101, reducing electromagnetic interference in noisy environments.
Installation and Maintenance
Pre-installation preparations: Verify the mounting surface is flat and grounded. Ensure the 24V DC power supply meets ±10% tolerance. Align the IC66088R101 with the DIN rail, slide into place, and secure with retaining clips. Connect field devices to the terminal block using twisted-pair shielded cables, labeling wires according to the system diagram to simplify future maintenance.
Maintenance suggestions: Conduct monthly visual inspections to check for loose terminals, damaged wires, or dim channel LEDs. Clean dust from ventilation slots using compressed air (30 psi max) to prevent overheating. Quarterly, test each channel by manually activating connected devices and verifying LED status. For unresponsive channels, check wiring continuity and device functionality before replacing the module. When replacing the IC66088R101, label wires first and retest all channels post-installation to ensure proper operation.
Product Guarantee
Our company offers a one-year quality warranty service for the IC66088R101, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems. As a leading import and export trade distribution company established in 2007 with 17 years of experience, we maintain extensive inventory of Series One modules, ensuring 48-hour delivery for urgent requirements. Technical support includes wiring diagrams, compatibility guides, and troubleshooting assistance.
