HONEYWELL R7247C1001 Combustion Control Module
Product Overview：HONEYWELL R7247C1001
The HONEYWELL R7247C1001 is a advanced Combustion Control Module designed to optimize safety, efficiency, and reliability in industrial combustion systems. As a core component of Honeywell’s 燃烧管理系统 (BMS) portfolio, this module serves as the intelligent backbone for controlling and monitoring combustion processes in boilers, furnaces, and thermal oxidizers across industries such as oil & gas, power generation, and manufacturing. By integrating precise ignition control, flame supervision, and safety interlock functionalities, the R7247C1001 ensures compliant operation with international safety standards (e.g., NFPA 85, EN 50155) while minimizing fuel consumption and emissions.
Key functionalities of the HONEYWELL R7247C1001 include sequential startup/shutdown control, real-time flame signal analysis, and fault diagnostics. The module supports multiple flame detection technologies (e.g., UV sensors, ion current) and interfaces with field devices such as igniters, valves, and temperature transmitters via analog and digital I/O channels. Its rugged design, with a temperature rating of -40°C to +85°C and IP65 protection, ensures reliable performance in harsh environments, while modular architecture facilitates easy integration into existing BMS setups or new installations.
In automation ecosystems, the R7247C1001 acts as a critical link between human-machine interfaces (HMIs) and combustion hardware, enabling operators to monitor process variables (e.g., fuel-air ratio, stack temperature) and trigger corrective actions remotely. Its embedded self-diagnostic tools continuously monitor component health, reducing unplanned downtime through predictive maintenance. Whether deployed in single-boiler systems or complex multi-furnace configurations, this module enhances operational safety, reduces compliance risks, and improves energy efficiency, making it an indispensable asset for industries reliant on combustion-driven processes.
Technical Specifications：HONEYWELL R7247C1001
| Parameter Name | Parameter Value |
|---|---|
| Product Model | R7247C1001 |
| Manufacturer | Honeywell |
| Product Type | Combustion Control Module |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Output Signals | Relay contacts (SPDT), 4–20 mA analog, RS-485 (Modbus RTU) |
| Flame Detection | Supports UV sensors, ion current, or flame rod inputs |
| Physical Dimensions | 228 mm (H) × 127 mm (W) × 102 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, NFPA 85, EN 50155 |
| I/O Channels | 8 digital inputs, 4 analog inputs, 6 relay outputs |
R7247C1001
Key Features and Advantages：HONEYWELL R7247C1001
Comprehensive Safety Compliance: The HONEYWELL R7247C1001 is engineered to meet rigorous safety standards, providing fail-safe ignition control and flame supervision to prevent explosions and unburned fuel accumulation. Its built-in safety timers and interlocks ensure compliant shutdown sequences in the event of flame loss or system faults.
Adaptive Combustion Control: The module’s advanced algorithms optimize fuel-air mixing in real time, reducing excess air and lowering NOx emissions. This adaptability makes it suitable for diverse fuel types, including natural gas, propane, and heavy fuel oil, while enhancing combustion efficiency by up to 5%.
Modular and Scalable Design: With a compact footprint and field-replaceable components, the R7247C1001 simplifies installation and maintenance. Its expandable I/O capabilities allow integration with optional modules (e.g., remote annunciators, communication gateways) to scale with system requirements.
Real-Time Diagnostics: The module’s LCD display and status LEDs provide instant feedback on system health, including flame signal strength, valve positions, and fault codes. This proactive diagnostics capability minimizes troubleshooting time and supports predictive maintenance strategies.
Wide Environmental Tolerance: Built with ruggedized components and a sealed enclosure, the R7247C1001 withstands high vibration, humidity, and electromagnetic interference, making it ideal for harsh industrial environments such as offshore platforms and steel mills.
R7247C1001
Application Areas：HONEYWELL R7247C1001
The HONEYWELL R7247C1001 is widely deployed in industries where precise combustion control and safety are non-negotiable:
- Oil & Gas: Controlling burner systems in refineries, petrochemical plants, and offshore production platforms to ensure safe operation and comply with environmental regulations.
- Power Generation: Managing steam boilers in thermal power plants, optimizing fuel efficiency while monitoring emissions for regulatory compliance.
- Manufacturing: Overseeing furnaces and ovens in metal processing, glass manufacturing, and cement production, ensuring consistent process temperatures and reducing energy waste.
- Water/Wastewater: Controlling thermal oxidizers and incinerators to safely dispose of waste gases and liquids, minimizing environmental impact.
Specific applications include:
- Boiler Safety Systems: Providing ignition sequence control and flame supervision for commercial and industrial boilers, reducing the risk of catastrophic failures.
- Combustion Efficiency Upgrades: Retrofitting older combustion systems with advanced control logic to improve fuel economy and reduce greenhouse gas emissions.
- Multi-Burner Systems: Coordinating multiple burners in large-scale furnaces, ensuring synchronized operation and load balancing.
Related Products：HONEYWELL R7247C1001
- HONEYWELL R7247D1001: An upgraded version with enhanced communication capabilities, supporting Ethernet/IP and Profibus DP for integration with modern SCADA systems.
- HONEYWELL UV300A: A UV flame sensor designed to pair with the R7247C1001, providing reliable flame detection in high-temperature environments.
- HONEYWELL S8660U1021: A flame rod amplifier module that enhances ion current signal reliability for burners using flame rod detection.
- HONEYWELL C7012E1001: A temperature transmitter compatible with the R7247C1001, enabling precise measurement of stack or process temperatures.
- HONEYWELL R7800A1001: A remote annunciator module that extends fault reporting capabilities, displaying alarms and status updates at operator stations.
- HONEYWELL R7243A1001: A simplified single-loop version for smaller burners, offering basic ignition control at a lower cost.
- HONEYWELL DT9800: A data logger module that records combustion parameters for the R7247C1001, supporting compliance reporting and performance analysis.
R7247C1001
Installation and Maintenance：HONEYWELL R7247C1001
Installation Preparation:
Before installing the HONEYWELL R7247C1001, ensure the control panel is properly grounded and ventilated. Verify compatibility with existing flame detection devices and fuel valves, using shielded cables for signal connections to minimize interference. Mount the module on a DIN rail or panel, ensuring adequate clearance for heat dissipation. Configure the module’s parameters (e.g., fuel type, ignition timing) using the front-panel keypad or Honeywell’s BMS Configuration Software.
Before installing the HONEYWELL R7247C1001, ensure the control panel is properly grounded and ventilated. Verify compatibility with existing flame detection devices and fuel valves, using shielded cables for signal connections to minimize interference. Mount the module on a DIN rail or panel, ensuring adequate clearance for heat dissipation. Configure the module’s parameters (e.g., fuel type, ignition timing) using the front-panel keypad or Honeywell’s BMS Configuration Software.
Maintenance Recommendations:
- Routine Inspections: Perform monthly visual checks for loose connections, damaged components, or signs of overheating. Clean the module’s enclosure with a dry cloth to prevent dust accumulation.
- Flame Sensor Calibration: Annually calibrate UV sensors or flame rods using Honeywell’s diagnostic tools to ensure accurate flame detection. Replace sensors if signal drift exceeds acceptable limits.
- Firmware Updates: Periodically update the module’s firmware to access new features and security patches, following Honeywell’s official procedures to avoid corruption.
- Spare Parts Inventory: Maintain a spare R7247C1001 module in a controlled environment (10–30°C, 20–80% RH) to quickly replace failed units and minimize downtime.
R7247C1001
Product Warranty：HONEYWELL R7247C1001
Our company provides a 12-month quality warranty for the HONEYWELL R7247C1001, covering hardware defects under normal use. In the event of performance issues or functional failures, we offer prompt replacement services. For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of hard-to-find components, supporting uninterrupted operation of industrial systems. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, ensuring optimal performance and reliability throughout the product lifecycle.
