Honeywell CC-PUIO31 | Process Universal Input/Output Module | CC-HCN911

Description

Product Overview：Honeywell CC-PUIO31

Technical Specifications：Honeywell CC-PUIO31

Parameter Name	Parameter Value
Product Model	CC-PUIO31
Manufacturer	Honeywell
Product Type	Universal I/O Module
Platform	Experion PKS C300
Channels	16 configurable (AI/AO/DI/DO)
Input Types	4–20 mA, 0–10 V DC, RTD, thermocouple, dry/wet contacts
Output Types	4–20 mA, 0–10 V DC, relay contacts (24 V DC/30 V AC)
Isolation	Galvanic (250 V AC/DC per channel)
Power Supply	24 V DC ±15% (module), 110–240 V AC (optional for relay outputs)
Physical Dimensions	101.6 mm (H) × 177.8 mm (W) × 76.2 mm (D)
Weight	1.2 kg
Operating Temperature	-40°C to +70°C
Mounting	Rack-mounted in C300 chassis
Certifications	CE, FM, CSA, ATEX (for hazardous areas)

Honeywell CC-PUIO31

Key Features and Advantages：Honeywell CC-PUIO31

Seamless Integration with Experion PKS: As part of Honeywell’s integrated automation platform, the module interfaces seamlessly with C300 controllers, HMIs, and historian systems. Its plug-and-play compatibility reduces commissioning time, while built-in diagnostics (via LED indicators and software alerts) enable proactive maintenance and rapid fault resolution.

Honeywell CC-PUIO31

Application Areas：Honeywell CC-PUIO31

• Oil & Gas: Monitors pressure, flow, and level in upstream wellheads, midstream pipelines, and downstream refineries. Controls emergency shutdown valves (ESD) and adjusts pump speeds in real time to optimize throughput.
• Chemical Processing: Manages reactor temperature and pressure via analog inputs, while digital outputs control agitators and batch valves. Supports compliance with ISO 13485 and other regulatory standards in specialty chemical production.
• Power Generation: Integrates with turbine control systems to monitor vibration (AI) and manage auxiliary equipment (DO), such as cooling fans and generator circuit breakers. Enables seamless coordination with SCADA systems for grid balancing.
• Water/Wastewater Treatment: Controls pump 启停 (DO) based on 液位 (AI) measurements, ensuring efficient water distribution and wastewater treatment. Supports remote monitoring via Modbus gateway integration.

• Batch Process Automation: Configures channels as both analog inputs (for temperature/production) and digital outputs (for valve sequencing) in pharmaceutical or food processing lines.
• Condition Monitoring: Uses analog inputs to collect vibration data from accelerometers, enabling predictive maintenance of rotating equipment like motors and compressors.
• Safety Systems Integration: Works with Honeywell’s Safety Manager to provide fail-safe I/O for safety instrumented systems (SIS), ensuring compliance with IEC 61508.

Related Products：Honeywell CC-PUIO31

1. CC-PAI03 (Analog Input Module): A dedicated 16-channel AI module for high-accuracy temperature and process variable monitoring, complementary to the CC-PUIO31 in mixed-signal systems.
2. CC-PDO32 (Digital Output Module): A 32-channel DO module for large-scale discrete control, ideal for expanding the CC-PUIO31’s output capacity in complex automation setups.
3. C300 Controller: The core processing unit of Experion PKS, which communicates with the CC-PUIO31 via proprietary Ethernet, enabling real-time control and data logging.
4. FTA-CC-PUIO31 (Field Termination Assembly): A pre-wired terminal block that simplifies field wiring for the CC-PUIO31, reducing installation time and minimizing errors.
5. PM-PS24-40 (Power Supply): A redundant 24 V DC power supply for C300 racks, ensuring uninterrupted operation of the CC-PUIO31 in mission-critical applications.
6. HM-2000 HMI: Honeywell’s human-machine interface, which visualizes data from the CC-PUIO31 and enables operator interaction with the control system.
7. CM-6000 Communication Module: Enables integration of the CC-PUIO31 with third-party systems via Profibus DP or Ethernet/IP, expanding its utility in hybrid automation environments.


   Honeywell CC-PUIO31

Installation and Maintenance：Honeywell CC-PUIO31

• Routine Checks: Perform monthly visual inspections to confirm LED status (e.g., power, communication, and channel health). Clean the module’s vents with compressed air to prevent dust buildup that could affect heat dissipation.
• Calibration: Annually calibrate analog channels using a certified calibration tool, comparing module readings against a reference standard. Document results for audit compliance.
• Firmware Updates: Periodically update the module’s firmware through Experion’s software platform to access new features and security patches. Back up all configurations prior to updating to prevent data loss.
• Spare Parts Management: Store spare CC-PUIO31 modules in anti-static packaging at ambient temperature (15–30°C) with low humidity. Rotate inventory to ensure shelf life and test spares annually in a simulated environment.


  Honeywell CC-PUIO31

Product Warranty：Honeywell CC-PUIO31
