HONEYWELL CC-IP0101 PlantScape Communication Interface Module
Product Overview：HONEYWELL CC-IP0101
The HONEYWELL CC-IP0101 is a high-performance Communication Interface Module designed for industrial automation systems, specifically as part of Honeywell’s PlantScape Distributed Control System (DCS). This module serves as a critical link between different network segments, enabling seamless data exchange between PlantScape controllers, operator workstations, and external systems. By supporting multiple communication protocols and providing robust network connectivity, the CC-IP0101 ensures reliable real-time data transmission in complex industrial environments, making it indispensable for process control, monitoring, and optimization across industries such as oil & gas, power generation, and chemical manufacturing.
As a key component of the PlantScape platform, the HONEYWELL CC-IP0101 facilitates integration with legacy systems and modern automation architectures. Its dual-port design supports both Ethernet and serial communication (e.g., RS-232/485), allowing flexible connectivity to devices like PLCs, third-party instruments, and supervisory control and data acquisition (SCADA) systems. The module’s advanced diagnostics and error-checking mechanisms ensure data integrity, while its rugged construction (IP20-rated enclosure) withstands harsh industrial conditions, including temperature fluctuations and electromagnetic interference.
In automation ecosystems, the CC-IP0101 acts as a gateway for centralized control and remote monitoring, reducing latency and enhancing system responsiveness. Its compatibility with Honeywell’s C300 Controllers and Experion PKS platforms enables seamless integration into larger control networks, supporting scalable solutions for small-scale operations to large industrial complexes. By streamlining communication between disparate systems, this module optimizes operational efficiency, minimizes downtime, and enhances safety through real-time data-driven decision-making.
Technical Specifications：HONEYWELL CC-IP0101
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CC-IP0101 |
| Manufacturer | Honeywell |
| Product Type | Communication Interface Module |
| Network Interfaces | 2 x 10/100 Mbps Ethernet ports, 1 x RS-232/485 serial port |
| Supported Protocols | Modbus RTU/TCP, DNP3, Honeywell Universal Control Network (UCN) |
| Power Supply | 24 V DC ±10% (redundant input) |
| Physical Dimensions | 178 mm (H) × 102 mm (W) × 254 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -40°C to +70°C (-40°F to 158°F) |
| Mounting | Rack-mounted (19-inch standard) |
| Certifications | CE, UL 508, IEC 61131-2 |
CC-IP0101
Key Features and Advantages：HONEYWELL CC-IP0101
Dual-Network Redundancy: The CC-IP0101 features dual Ethernet ports with automatic failover, ensuring continuous network connectivity even in the event of a port or cable failure. This redundancy is critical for mission-critical applications where uninterrupted data flow is non-negotiable.
Multi-Protocol Support: With compatibility for Modbus, DNP3, and Honeywell’s proprietary UCN protocol, the module eliminates the need for multiple interface devices, simplifying system architecture and reducing hardware costs. Its flexible configuration allows seamless integration with both legacy and modern field devices.
Advanced Diagnostics: Built-in LED indicators and diagnostic software provide real-time status updates on network connectivity, power supply, and data transmission errors. This proactive monitoring capability minimizes troubleshooting time and enables predictive maintenance, reducing unplanned downtime.
Rugged Industrial Design: Engineered to withstand harsh environments, the CC-IP0101 features a reinforced metal enclosure and conformal coating to protect against dust, moisture, and vibration. Its wide operating temperature range makes it suitable for deployment in both indoor control rooms and outdoor industrial settings.
Scalable Integration: As part of Honeywell’s PlantScape ecosystem, the module can be easily scaled to support growing system requirements. It interfaces with Honeywell’s C300 Controllers and Historian servers, enabling centralized data management and advanced analytics for process optimization.
User-Friendly Configuration: The module is configured via Honeywell’s PlantScape Engineering Tools, which provide a intuitive graphical interface for setting up communication parameters, mapping data points, and monitoring network performance. This ease of use reduces engineering time and enhances operational efficiency.
CC-IP0101
Application Areas：HONEYWELL CC-IP0101
The HONEYWELL CC-IP0101 is deployed across diverse industries to address complex communication challenges in automation systems:
- Oil & Gas: Facilitates real-time data exchange between 井口 sensors (wellhead sensors), pipeline control systems, and central SCADA networks, enabling remote monitoring of pressure, flow rates, and safety interlocks. Its redundancy features are critical for offshore platforms and remote production sites.
- Power Generation: Integrates turbine control systems, generator protective relays, and grid management systems in thermal, hydro, and renewable energy plants. The module’s support for DNP3 protocol ensures compliance with utility industry standards for substation automation.
- Chemical Manufacturing: Connects batch processing systems, quality control instruments, and safety systems in chemical plants, enabling precise control of reaction parameters and real-time monitoring of hazardous processes. Its rugged design is essential for environments with high electromagnetic interference.
- Water/Wastewater Treatment: Bridges the gap between field devices (e.g., flow meters, level sensors) and plant-wide DCS systems, optimizing water distribution and treatment processes. The module’s serial communication capabilities are ideal for retrofitting older infrastructure.
Specific applications include:
- System Integration: Serving as a gateway between PlantScape DCS and third-party PLCs (e.g., Allen-Bradley, Siemens) in hybrid automation setups.
- Remote Monitoring: Enabling secure remote access to industrial networks via VPN tunnels, supporting predictive maintenance and remote troubleshooting.
- Data Aggregation: Collecting data from distributed sensors and devices into a centralized historian for trend analysis, regulatory compliance reporting, and energy management.
CC-IP0101
Related Products：HONEYWELL CC-IP0101
- HONEYWELL CC-IP0201: A Upgraded version (upgraded version) with dual serial ports and enhanced Ethernet capabilities, designed for applications requiring high-speed data transfer and multi-device connectivity.
- HONEYWELL CC-TD0101: A Terminal Driver Module that expands the number of serial ports in a PlantScape system, ideal for connecting legacy devices with limited network interfaces.
- HONEYWELL C300 Controller: A high-performance controller that pairs with the CC-IP0101 for real-time process control, featuring built-in Ethernet and serial communication ports.
- HONEYWELL FC-PS101 Power Supply: A redundant power supply module designed to support PlantScape I/O and communication modules, ensuring stable operation during power fluctuations.
- HONEYWELL HI-IP0101 Ethernet Interface Module: A specialized module for high-speed Ethernet networks, offering advanced security features like firewall integration and encrypted data transmission.
- HONEYWELL CC-PA0101 Protocol Adapter: Facilitates communication between PlantScape systems and proprietary industrial protocols (e.g., Profibus, Ethernet/IP), enhancing interoperability in multi-vendor environments.
- HONEYWELL WM-IPC01 Industrial PC: A ruggedized computer that works with the CC-IP0101 for operator interface and supervisory control, supporting Honeywell’s PlantScape HMI software.
- HONEYWELL CC-AL0101 Alarm Interface Module: Integrates with the CC-IP0101 to provide real-time alarm notification and event logging across distributed control networks.
CC-IP0101
Installation and Maintenance：HONEYWELL CC-IP0101
Installation Preparation:
Before installing the HONEYWELL CC-IP0101, ensure the 19-inch rack is properly grounded and ventilated. Verify compatibility with the existing network infrastructure, including IP addressing schemes and protocol requirements. Use shielded Ethernet cables for high-speed data links and twisted-pair cables for serial connections to minimize interference. Mount the module in a dedicated rack slot, securing it with captive screws, and connect the redundant 24 V DC power supplies to ensure uninterrupted operation. Configure the module’s IP address and communication parameters using Honeywell’s PlantScape software, ensuring alignment with the overall network architecture.
Before installing the HONEYWELL CC-IP0101, ensure the 19-inch rack is properly grounded and ventilated. Verify compatibility with the existing network infrastructure, including IP addressing schemes and protocol requirements. Use shielded Ethernet cables for high-speed data links and twisted-pair cables for serial connections to minimize interference. Mount the module in a dedicated rack slot, securing it with captive screws, and connect the redundant 24 V DC power supplies to ensure uninterrupted operation. Configure the module’s IP address and communication parameters using Honeywell’s PlantScape software, ensuring alignment with the overall network architecture.
Maintenance Recommendations:
- Routine Checks: Perform monthly visual inspections to verify LED status indicators (e.g., power, network activity) and ensure no physical damage or loose connections. Clean the module’s air vents with compressed air to prevent dust accumulation that could affect heat dissipation.
- Firmware Updates: Periodically update the module’s firmware using Honeywell’s official software tools to access new features, security patches, and protocol enhancements. Back up existing configurations before updating to avoid data loss.
- Redundancy Testing: Conduct quarterly tests of the dual Ethernet ports and power supplies to ensure failover mechanisms operate correctly. Simulate network outages or power interruptions to validate system resilience.
- Spare Parts Management: Maintain a spare CC-IP0101 module in a controlled environment (temperature: 10–30°C, humidity: 20–80% RH) to quickly replace faulty units. Regularly check spare modules for firmware compatibility with the active system.
Product Warranty：HONEYWELL CC-IP0101
Our company provides a 12-month quality warranty for the HONEYWELL CC-IP0101, covering hardware defects under normal use. In the event of performance issues or functional failures, we offer prompt replacement services to minimize downtime. For discontinued models or urgent requirements, our global supply chain network ensures rapid sourcing of Scarce spare parts (rare spare parts), leveraging partnerships with original equipment manufacturers and authorized distributors. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, delivering customized solutions to maintain optimal system performance. We stand behind the reliability of our products, committed to supporting our clients’ industrial operations with secure, efficient, and long-lasting automation components.
For inquiries, contact our team via Whatsapp:+86 18859254943 or E-mail :sales@ygplc.com. to explore how the CC-IP0101 can enhance your automation infrastructure.
