GE IC695ALG608-HD is a high-density analog input module designed for GE’s PACSystems RX3i platform, engineered to provide precise measurement and conversion of analog signals in industrial automation systems. This module features eight isolated channels with configurable input ranges, supporting voltage, current, RTD, and thermocouple inputs. Its high-speed sampling and 16-bit resolution ensure accurate data acquisition, making it ideal for applications requiring detailed process monitoring, such as chemical reactors, power generation, and water treatment facilities.
Product Overview
The GE IC695ALG608-HD serves as a critical interface between field sensors and the PACSystems RX3i controller, converting real-world analog signals into digital data for processing. Each channel supports multiple input types, including ±10V, ±5V, ±1V, 0–20mA, 4–20mA, and various RTD/thermocouple configurations (e.g., J, K, T, E). This flexibility allows the module to accommodate diverse sensor outputs without requiring hardware changes, simplifying system design and reducing inventory costs.
As part of the RX3i ecosystem, the GE IC695ALG608-HD integrates seamlessly with other modules, including CPUs, power supplies, and communication interfaces. Its compact design (3.4 cm x 14.5 cm x 14 cm) optimizes rack space, while LED indicators provide real-time status monitoring for each channel. The module’s isolated inputs prevent electrical interference between channels, ensuring reliable performance in noisy industrial environments.
Technical Specifications
| Product model | GE IC695ALG608-HD |
|---|---|
| Manufacturer | GE |
| Product type | High-density analog input module |
| Input types | Voltage, current, RTD, thermocouple |
| Resolution | 16-bit |
| Number of channels | 8 (isolated) |
| Isolation | 1500V AC (field to backplane) |
| Sampling rate | Up to 10ms per channel |
| Physical dimensions | 3.4 cm x 14.5 cm x 14 cm (1.34 in x 5.71 in x 5.51 in) |
| Weight | 0.91 kg (2.01 lbs) |
| Terminal block compatibility | IC694TBB032 (box-style), IC694TBS032 (spring-style) |
| Operating temperature | 0°C to 60°C (32°F to 140°F) |
| Storage temperature | -40°C to 85°C (-40°F to 185°F) |
| Safety certifications | UL, CSA, CE |
IC695ALG608-HD
Related Products
- GE IC694TBB032: Box-style terminal block 配套使用 with the GE IC695ALG608-HD for secure field wiring connections.
- GE IC695CPE305: Mid-range CPU module that pairs with the GE IC695ALG608-HD to enable advanced logic control and data processing.
- GE IC695ALG412: 12-channel analog input module offering more channels but lower density, suitable for applications requiring additional inputs.
- GE IC695PSD140: Power supply module ensuring stable 24V DC delivery to the GE IC695ALG608-HD and connected devices.
- GE IC695CHS016: 16-slot universal backplane that houses the GE IC695ALG608-HD and other RX3i modules for scalable system design.
Main Features and Advantages
High-Density Design: The GE IC695ALG608-HD provides eight isolated channels in a compact form factor, maximizing I/O capacity while minimizing rack space. This makes it ideal for applications with limited panel space or those requiring dense analog input monitoring.
Configurable Inputs: Each channel can be independently configured for different input types (voltage, current, RTD, thermocouple), eliminating the need for multiple specialized modules. This flexibility reduces system complexity and simplifies maintenance.
Advanced Signal Processing: The module’s 16-bit resolution and high-speed sampling ensure accurate and timely conversion of analog signals, even in dynamic processes. Its built-in digital filtering reduces noise interference, improving measurement reliability.
Reliable Operation: The GE IC695ALG608-HD features 1500V AC isolation between channels and the backplane, protecting against electrical noise and voltage spikes. Its rugged construction and wide operating temperature range ensure consistent performance in harsh industrial environments.
IC695ALG608-HD
Installation and Maintenance
Pre-installation Preparations: Before installing the GE IC695ALG608-HD, power off the RX3i chassis and verify compatibility with the CPU firmware (version 4.0 or later). Clean the mounting slot to remove debris and ensure proper airflow. Use the appropriate terminal block (e.g., GE IC694TBB032) to connect field sensors, following the module’s wiring diagram to ensure correct signal types and polarities.
Maintenance Suggestions: Regularly inspect the module’s LED indicators for 异常 status and check terminal connections for tightness during scheduled system shutdowns. Clean dust from the surface with a dry cloth to maintain optimal thermal performance. If a channel fails, verify sensor functionality before replacing the module. For long-term storage, keep the GE IC695ALG608-HD in a dry environment within its specified temperature range.
Application Fields
The GE IC695ALG608-HD is widely used in industries requiring precise analog signal monitoring. In chemical processing, it measures temperature, pressure, and flow rates in reactors and pipelines, ensuring process safety and product quality. Water treatment plants utilize its capabilities to monitor pH levels, turbidity, and chemical dosages, enabling efficient treatment processes.
In energy sectors, the module monitors parameters such as turbine temperatures, generator outputs, and fuel flow rates in power plants, supporting optimal performance and predictive maintenance. Food and beverage manufacturers rely on its accuracy to control cooking temperatures, pressure, and ingredient proportions in processing equipment, maintaining product consistency and safety.
IC695ALG608-HD
Product Guarantee
Our company offers a one-year quality warranty service for the GE IC695ALG608-HD, covering hardware malfunctions not caused by human factors. During the warranty period, if the module shows abnormal performance or functional failure, we will provide replacement services. Established in 2007, our company specializes in distributing industrial control spare parts, including many unpopular and discontinued models, with a large inventory in stock. Leveraging our global supply chain network, we can quickly respond to customers’ urgent procurement needs for scarce spare parts, ensuring the continuous and stable operation of industrial systems.
