GE SLN080 IC086SLN080-A Synchronous Line Module
Product Overview: GE SLN080 IC086SLN080-A
The :GE SLN080 IC086SLN080-A synchronous line module is a high-precision industrial component designed for power generation and distribution systems, serving as a critical interface for synchronizing generators with utility grids or other power sources. As part of GE’s Mark VIe Speedtronic control system portfolio, this module ensures seamless integration of rotating machinery into electrical networks by precisely monitoring voltage, frequency, and phase angle parameters. Its core function is to facilitate safe and efficient paralleling of generators, minimizing transient stresses on equipment and ensuring stable power delivery in mission-critical applications.
Engineered for reliability, the SLN080 IC086SLN080-A supports three-phase voltage and current inputs, with configurable settings to adapt to diverse generator types and grid conditions. The module’s digital signal processing (DSP) technology enables real-time calculation of synchronization parameters, reducing alignment time and improving system responsiveness. Its compact design (178mm x 127mm x 76mm, 1.5kg) and rugged construction make it suitable for harsh industrial environments, with an operating temperature range of -40°C to 85°C and resistance to vibration and electromagnetic interference.
Within automation systems, the SLN080 IC086SLN080-A acts as a vital link between the generator control unit (GCU) and the grid, ensuring compliance with power quality standards. By accurately matching the generator’s output to the grid’s frequency and phase, it prevents damaging power surges and ensures smooth transition between standby and parallel operation. This module is indispensable in power plants, oil & gas facilities, and industrial campuses where reliable power synchronization is essential for operational continuity and energy efficiency.
Technical Specifications : GE SLN080 IC086SLN080-A
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SLN080 IC086SLN080-A |
| Manufacturer | GE |
| Product Type | Synchronous Line Module |
| Input Voltage | 120V AC (phase-to-ground), 240V AC (phase-to-phase) |
| Frequency Range | 45–65 Hz |
| Phase Angle Accuracy | ±0.1° |
| Physical Dimensions | 178mm (L) x 127mm (W) x 76mm (H) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to 85°C |
| Vibration Resistance | 2 g (5–500 Hz) |
| Mounting Type | Panel-mounted |
| Communication Interface | RS485 (Modbus RTU) |
| Country of Origin | United States |
GE SLN080 IC086SLN080-A
Main Features and Advantages: GE SLN080 IC086SLN080-A
Precision Synchronization: The SLN080 IC086SLN080-A leverages advanced DSP algorithms to monitor and adjust generator parameters in real time, ensuring synchronization within ±0.1° phase angle and ±0.1 Hz frequency tolerances. This precision minimizes mechanical stress on generators and transformers, extending equipment lifespan and reducing maintenance costs.
Adaptive Configuration: The module supports user-configurable voltage and current thresholds, allowing customization for different generator models (e.g., gas turbines, steam turbines, or diesel generators). Its flexible settings accommodate both single-unit synchronization and multi-generator paralleling, making it suitable for scalable power systems.
Robust Industrial Design: Built with reinforced components and a shielded enclosure, the SLN080 IC086SLN080-A withstands harsh environmental conditions, including high vibration, temperature fluctuations, and electromagnetic interference. This durability ensures reliable operation in challenging environments such as offshore platforms or industrial manufacturing facilities.
Real-Time Diagnostics: Integrated LED indicators and a serial communication interface (RS485) provide real-time status updates on synchronization parameters, fault conditions, and module health. This enables proactive maintenance and rapid troubleshooting, reducing downtime and improving system availability.
Seamless Integration: As part of GE’s Mark VIe ecosystem, the SLN080 IC086SLN080-A interfaces seamlessly with other control modules, such as the IS210BPPCH1ACA I/O processor and IS420UCECH1B controller, creating a unified control architecture. Its Modbus RTU compatibility also allows integration with third-party SCADA systems for centralized monitoring.
GE SLN080 IC086SLN080-A
Application Areas: GE SLN080 IC086SLN080-A
The GE SLN080 IC086SLN080-A synchronous line module is critical in industries where precise power synchronization is essential:
- Power Generation: Used in thermal, hydro, and combined-cycle power plants to synchronize generators with the main grid or isolate them for island mode operation. Ensures stable power output during load transfers and maintenance shutdowns.
- Oil & Gas: Deployed in offshore platforms and refineries to manage power distribution between onsite generators and emergency backup systems. Supports quick synchronization during utility outages to maintain uninterrupted production.
- Industrial Microgrids: Enables seamless integration of renewable energy sources (e.g., solar, wind) with traditional generators in industrial campuses, optimizing energy usage and reducing reliance on the main grid.
- Marine Systems: Installed in shipboard power systems to parallel multiple diesel generators, ensuring stable electricity supply for propulsion, navigation, and onboard operations.
- Critical Infrastructure: Used in data centers, hospitals, and transportation hubs to manage backup generator synchronization, ensuring continuous power supply during grid disturbances.
Related Products: GE SLN080 IC086SLN080-A
- IS210BPPCH1ACA: A Mark VIe I/O processor that interfaces with the SLN080 IC086SLN080-A to manage analog and digital signals, supporting triple modular redundancy (TMR) for high-reliability applications.
- IS420UCECH1B: A Mark VIe controller that coordinates with the SLN080 IC086SLN080-A to execute synchronization logic and monitor system health, providing centralized control for generator operations.
- DS200SLCCG1A: A legacy synchronous line module compatible with GE’s Mark V systems, serving as a predecessor to the SLN080 IC086SLN080-A with similar synchronization capabilities.
- IS200ADIIH1A: A dual-channel I/O module that expands the system’s signal processing capacity, integrating with the SLN080 IC086SLN080-A to handle additional voltage and current inputs.
- IS220PAOCH1A: An analog output module that translates synchronization commands into control signals for actuators and circuit breakers, working in tandem with the SLN080 IC086SLN080-A.
- IS410SRLYS2A: A solid-state relay module that provides fault-free switching for high-power circuits, complementing the SLN080 IC086SLN080-A in generator paralleling applications.
GE SLN080 IC086SLN080-A
Installation and Maintenance: GE SLN080 IC086SLN080-A
Pre-installation Preparations:
Before installing the SLN080 IC086SLN080-A, verify the input voltage (120/240V AC) and frequency (45–65 Hz) match the module’s specifications. Ensure the mounting panel is grounded to mitigate EMI and provide adequate ventilation for heat dissipation. Connect the module’s voltage and current inputs to the generator’s potential transformers (PTs) and current transformers (CTs), following GE’s wiring diagrams to ensure proper phase alignment. Configure the module’s parameters (e.g., synchronization thresholds, communication settings) using GE’s ToolboxST software to match the specific generator and grid requirements.
Before installing the SLN080 IC086SLN080-A, verify the input voltage (120/240V AC) and frequency (45–65 Hz) match the module’s specifications. Ensure the mounting panel is grounded to mitigate EMI and provide adequate ventilation for heat dissipation. Connect the module’s voltage and current inputs to the generator’s potential transformers (PTs) and current transformers (CTs), following GE’s wiring diagrams to ensure proper phase alignment. Configure the module’s parameters (e.g., synchronization thresholds, communication settings) using GE’s ToolboxST software to match the specific generator and grid requirements.
Maintenance Recommendations:
Regular maintenance is essential to ensure the SLN080 IC086SLN080-A operates at peak performance. Conduct monthly inspections to check for loose connections, damaged cables, or overheating. Use a soft brush to clean dust from the module’s vents, as accumulation can affect thermal management. Quarterly, verify the accuracy of voltage and frequency measurements using a calibrated multimeter, adjusting settings if discrepancies are detected. Annually, update the module’s firmware to incorporate the latest improvements and security patches, and test the synchronization logic with a simulated grid connection to ensure responsiveness. In the event of a fault, replace the module with a pre-calibrated unit to minimize downtime, ensuring all configuration settings are replicated to maintain system consistency.
Regular maintenance is essential to ensure the SLN080 IC086SLN080-A operates at peak performance. Conduct monthly inspections to check for loose connections, damaged cables, or overheating. Use a soft brush to clean dust from the module’s vents, as accumulation can affect thermal management. Quarterly, verify the accuracy of voltage and frequency measurements using a calibrated multimeter, adjusting settings if discrepancies are detected. Annually, update the module’s firmware to incorporate the latest improvements and security patches, and test the synchronization logic with a simulated grid connection to ensure responsiveness. In the event of a fault, replace the module with a pre-calibrated unit to minimize downtime, ensuring all configuration settings are replicated to maintain system consistency.
GE SLN080 IC086SLN080-A
Product Warranty: GE SLN080 IC086SLN080-A
Our company offers a 12-month quality warranty for the GE SLN080 IC086SLN080-A synchronous line module, covering non-human-induced hardware defects. During the warranty period, we will replace any module experiencing performance anomalies or functional failures at no additional cost. For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of scarce spare parts, supported by decades of expertise in industrial control logistics.
With 17 years of specialization in industrial automation components, we prioritize customer reliability by providing rigorous quality assurance and responsive technical support. The SLN080 IC086SLN080-A exemplifies our commitment to delivering cutting-edge solutions that enhance the efficiency and stability of power systems worldwide. Contact us today to explore how this module can optimize your generator synchronization processes, backed by our industry-leading supply chain and service guarantees.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for official technical documentation. Always refer to GE’s manuals for detailed installation, operation, and safety instructions.
