GE IS220PSCAH1A 336A4940CSP9 Mark VIe Power Supply Module
Product Overview
The GE IS220PSCAH1A 336A4940CSP9 is a high-reliability power supply module designed as a critical component of GE’s Mark VIe control system, responsible for delivering stable and redundant power to I/O modules, controllers, and communication cards in industrial automation. As part of the IS220 Series, this module ensures continuous operation of mission-critical systems in power generation, oil & gas, and manufacturing, where unplanned downtime can lead to significant losses. The IS220PSCAH1A 336A4940CSP9 integrates seamlessly with other Mark VIe components, forming a robust power infrastructure that supports triple modular redundancy (TMR) and hot-swappable configurations.
Featuring a dual-input design (110/220 V AC), the GE IS220PSCAH1A 336A4940CSP9 converts AC power to regulated 24 V DC output, delivering up to 10 A current to power connected devices. Its advanced power conditioning circuitry includes overvoltage, overcurrent, and thermal protection, safeguarding sensitive electronics from electrical anomalies. The module’s rugged construction—with conformal coating and compliance with MIL-STD-810G—withstands extreme temperatures (-40°C to +70°C), vibration, and humidity, making it suitable for harsh environments like offshore platforms and power plant turbine halls.
In automation ecosystems, the IS220PSCAH1A 336A4940CSP9 serves as the power backbone, enabling redundant configurations where two modules operate in parallel: if one fails, the other seamlessly takes over, ensuring uninterrupted power. Its hot-swappable design allows replacement without system shutdown, a key feature for 24/7 operations. By combining high efficiency (up to 92%), robust protection, and redundant architecture, this module ensures the reliability of Mark VIe systems, supporting critical processes from turbine control to safety shutdowns.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS220PSCAH1A 336A4940CSP9 |
| Manufacturer | GE |
| Product Type | Power Supply Module |
| Series | Mark VIe |
| Input Voltage | 110/220 V AC (selectable), 50/60 Hz |
| Output Voltage | 24 V DC ±0.5% |
| Output Current | 10 A maximum |
| Efficiency | Up to 92% |
| Physical Dimensions | 167.6 mm (H) × 233.4 mm (W) × 44.5 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Protection Features | Overvoltage, overcurrent, thermal shutdown |
| Redundancy Support | Parallel redundancy (N+1), hot-swappable |
| Certifications | MIL-STD-810G, CE, UL, IEC 61131-2 |
Main Features and Advantages
Dual-Input Flexibility:
The IS220PSCAH1A 336A4940CSP9 supports both 110 V AC and 220 V AC input, adapting to global power grids without the need for external transformers. This flexibility simplifies installation in international facilities, from North American power plants to European refineries.
The IS220PSCAH1A 336A4940CSP9 supports both 110 V AC and 220 V AC input, adapting to global power grids without the need for external transformers. This flexibility simplifies installation in international facilities, from North American power plants to European refineries.
Redundant Power Delivery:
Designed for parallel redundancy (N+1), the module works with identical units to share load. If one module fails, the others automatically take over, ensuring uninterrupted 24 V DC supply—critical for safety systems like emergency shutdown (ESD) networks.
Designed for parallel redundancy (N+1), the module works with identical units to share load. If one module fails, the others automatically take over, ensuring uninterrupted 24 V DC supply—critical for safety systems like emergency shutdown (ESD) networks.
Advanced Protection Mechanisms:
Overvoltage, overcurrent, and thermal protection circuits prevent damage to connected devices during power surges, short circuits, or excessive heat. These features extend the lifespan of sensitive components like RTD input modules and communication cards.
Overvoltage, overcurrent, and thermal protection circuits prevent damage to connected devices during power surges, short circuits, or excessive heat. These features extend the lifespan of sensitive components like RTD input modules and communication cards.
High Efficiency:
With up to 92% efficiency, the IS220PSCAH1A 336A4940CSP9 minimizes energy loss and heat generation, reducing cooling requirements in control cabinets. This efficiency lowers operational costs, especially in large-scale systems with multiple power supplies.
With up to 92% efficiency, the IS220PSCAH1A 336A4940CSP9 minimizes energy loss and heat generation, reducing cooling requirements in control cabinets. This efficiency lowers operational costs, especially in large-scale systems with multiple power supplies.
Hot-Swappable Design:
Enables module replacement without powering down the system, minimizing downtime during maintenance. This feature is essential for 24/7 operations, such as nuclear power plants or continuous manufacturing lines.
Enables module replacement without powering down the system, minimizing downtime during maintenance. This feature is essential for 24/7 operations, such as nuclear power plants or continuous manufacturing lines.
Rugged Environmental Tolerance:
Conformal coating and MIL-STD-810G compliance ensure reliable operation in extreme temperatures, vibration, and humidity. This makes the module suitable for offshore platforms, desert power plants, and other harsh industrial settings.
Conformal coating and MIL-STD-810G compliance ensure reliable operation in extreme temperatures, vibration, and humidity. This makes the module suitable for offshore platforms, desert power plants, and other harsh industrial settings.
Seamless TMR Integration:
Supports triple modular redundancy, working with two other units to provide fault-tolerant power in safety-critical systems. This integration ensures compliance with SIL 3 standards, a requirement for nuclear and chemical processing facilities.
Supports triple modular redundancy, working with two other units to provide fault-tolerant power in safety-critical systems. This integration ensures compliance with SIL 3 standards, a requirement for nuclear and chemical processing facilities.
Application Areas
The GE IS220PSCAH1A 336A4940CSP9 is indispensable in industries requiring stable power for control systems:
- Power Generation:
Powers Mark VIe controllers, RTD input modules, and communication cards in thermal, hydro, and nuclear plants. Ensures turbine control systems and safety shutdown networks receive uninterrupted power. - Oil & Gas:
Supplies power to I/O modules in offshore platforms, refineries, and pipeline control rooms. Redundant design prevents failures in ESD systems, critical for preventing hazardous leaks. - Manufacturing:
Supports robotic cells, conveyor systems, and PLCs in automotive, chemical, and food processing plants. Stable 24 V DC power ensures consistent production and minimizes equipment downtime. - Chemical Processing:
Powers reactor control systems, sensor interfaces, and valve actuators. Redundancy and protection features prevent process disruptions caused by power anomalies.
Specific applications include gas turbine auxiliary system power, refinery ESD network power, and automotive assembly line control cabinet power.
Related Products
- GE IS220PRTDH1A (Mark VIe RTD Input Module):
Relies on the IS220PSCAH1A 336A4940CSP9 for 24 V DC power, using stable supply to maintain ±0.1°C temperature measurement accuracy. - GE IS220PDOAH1A 336A4940CSP2 (Mark VIe Discrete Output Module):
Receives power from the module to drive relays and solenoids in control systems, ensuring reliable actuation. - GE IS220VCMIH2CA (Mark VIe Communication Card):
Depends on the power supply for stable operation, maintaining Ethernet and PROFIBUS communication in distributed control systems. - GE IS220PSCAH1B (Mark VIe Power Supply Module):
An upgraded variant with 15 A output, suitable for larger systems with more connected devices. - GE IS200SPIDG1A (Terminal Board):
Works with the power supply to distribute 24 V DC to field sensors, simplifying wiring in control cabinets. - GE IS220PPRFH1B (Mark VIe PROFIBUS Gateway):
Uses power from the IS220PSCAH1A 336A4940CSP9 to maintain communication between Mark VIe controllers and field devices.
Installation and Maintenance
Pre-installation preparations:
Ensure the Mark VIe rack is properly grounded and ventilated, with input power lines rated for 110/220 V AC. Verify that the total load of connected devices does not exceed the module’s 10 A output. Mount the IS220PSCAH1A 336A4940CSP9 in the 6U VMEbus slot, securing it with anti-vibration screws. For redundant setups, connect parallel modules using GE-specified power distribution blocks.
Ensure the Mark VIe rack is properly grounded and ventilated, with input power lines rated for 110/220 V AC. Verify that the total load of connected devices does not exceed the module’s 10 A output. Mount the IS220PSCAH1A 336A4940CSP9 in the 6U VMEbus slot, securing it with anti-vibration screws. For redundant setups, connect parallel modules using GE-specified power distribution blocks.
Maintenance suggestions:
Perform monthly visual inspections of front-panel LEDs to check for power status and fault conditions. Use a multimeter to verify 24 V DC output, ensuring it stays within ±0.5% tolerance. Clean dust from vents quarterly with compressed air, especially in dusty environments. Test redundant 切换 annually by simulating a failure in one module to ensure the others take over seamlessly. Store spare IS220PSCAH1A 336A4940CSP9 modules in anti-static packaging at 10–30°C with <50% humidity, testing them annually to confirm functionality.
Perform monthly visual inspections of front-panel LEDs to check for power status and fault conditions. Use a multimeter to verify 24 V DC output, ensuring it stays within ±0.5% tolerance. Clean dust from vents quarterly with compressed air, especially in dusty environments. Test redundant 切换 annually by simulating a failure in one module to ensure the others take over seamlessly. Store spare IS220PSCAH1A 336A4940CSP9 modules in anti-static packaging at 10–30°C with <50% humidity, testing them annually to confirm functionality.
Product Guarantee
Our company offers a one-year quality warranty service for the IS220PSCAH1A 336A4940CSP9, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems. As a leading import-export distributor with 17 years of experience, we maintain large stocks, ensuring timely access to critical power supply modules when needed.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
