GE IS220PHRAH1A Product Specification
Product Overview
The GE IS220PHRAH1A is a high-performance process I/O module engineered for GE’s Mark VIe Speedtronic Turbine Control System, designed to bridge the gap between field sensors/actuators and the central controller in industrial automation. As a critical component in power generation, oil and gas, and heavy manufacturing, this module processes analog and digital signals to enable precise monitoring and control of key process variables—such as pressure, flow, and temperature—in gas turbines, steam turbines, and rotating machinery.
Integrated into the Mark VIe distributed architecture, the GE IS220PHRAH1A features 16 configurable I/O channels (8 analog inputs, 4 analog outputs, 4 discrete inputs) that support a range of signal types, including 4–20 mA, 0–10 VDC, and dry contact signals. Its 2500 Vrms galvanic isolation between channels eliminates electrical interference, ensuring accurate data transmission even in high-noise environments. The module’s compact 3U VME form factor (228.6 mm × 101.6 mm × 165.1 mm) and rugged construction—triple-layer conformal coating, IP20 enclosure—enable reliable operation in harsh conditions (-30°C to +65°C) with high vibration, humidity, and chemical exposure.
In automation systems, the GE IS220PHRAH1A acts as a versatile interface, translating sensor data into actionable commands for turbine governors, compressor anti-surge valves, and generator excitation systems. Its dual 100 Mbps Ethernet ports (IONET protocol) support redundant communication, ensuring uninterrupted data flow in safety-critical applications. Compatibility with IS230TCISH6C terminal boards allows deployment in hazardous locations (Class I, Division 2), adhering to strict safety standards for explosive atmospheres. The module’s hot-swappable design and advanced diagnostics further solidify its role as a reliable workhorse in mission-critical operations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS220PHRAH1A |
| Manufacturer | General Electric (GE) |
| Product Type | Process I/O Module |
| Series | Mark VIe Speedtronic Turbine Control System |
| I/O Channels | 16 configurable (8 analog inputs, 4 analog outputs, 4 discrete inputs) |
| Signal Types Supported | 4–20 mA, 0–10 VDC (analog); dry contact (discrete) |
| Physical Dimensions | 228.6 mm (H) × 101.6 mm (W) × 165.1 mm (D) |
| Weight | 1.1 kg |
| Operating Temperature | -30°C to +65°C |
| Humidity | 5–95% non-condensing |
| Power Supply | 24 VDC ±10% (1.2 A max) |
| Isolation | 2500 Vrms galvanic isolation (channels to ground) |
| Communication Interface | Dual 100 Mbps Ethernet (IONET protocol) |
| Mounting Type | 3U VME rack mount |
| Certifications | CE, UL 61010-1, Class I Division 2 (Groups A-D) |
Main Features and Advantages
Flexible I/O Configuration:
The GE IS220PHRAH1A’s 16 configurable channels adapt to diverse field requirements, eliminating the need for multiple specialized modules. Whether processing pressure transmitter signals (4–20 mA) or valve position commands (0–10 VDC), the module ensures seamless integration with sensors and actuators, simplifying system design and reducing installation costs.
The GE IS220PHRAH1A’s 16 configurable channels adapt to diverse field requirements, eliminating the need for multiple specialized modules. Whether processing pressure transmitter signals (4–20 mA) or valve position commands (0–10 VDC), the module ensures seamless integration with sensors and actuators, simplifying system design and reducing installation costs.
Redundant communication:
Dual Ethernet ports with IONET protocol support ensure uninterrupted data transmission to the Mark VIe controller. In redundant architectures, automatic failover (<10 ms) maintains control continuity during network faults—a critical feature in safety systems like turbine emergency shutdown loops, where even brief interruptions could lead to operational disruptions.
Dual Ethernet ports with IONET protocol support ensure uninterrupted data transmission to the Mark VIe controller. In redundant architectures, automatic failover (<10 ms) maintains control continuity during network faults—a critical feature in safety systems like turbine emergency shutdown loops, where even brief interruptions could lead to operational disruptions.
Precision signal processing:
With 16-bit resolution and a 10 ms update rate, the GE IS220PHRAH1A delivers accurate data for closed-loop control. Its integrated signal conditioning—including filtering and linearization—minimizes noise, ensuring reliable measurements of critical variables like turbine exhaust temperature or compressor discharge pressure. This precision is vital for optimizing efficiency and preventing equipment damage.
With 16-bit resolution and a 10 ms update rate, the GE IS220PHRAH1A delivers accurate data for closed-loop control. Its integrated signal conditioning—including filtering and linearization—minimizes noise, ensuring reliable measurements of critical variables like turbine exhaust temperature or compressor discharge pressure. This precision is vital for optimizing efficiency and preventing equipment damage.
Rugged environmental resilience:
A triple-layer conformal coating protects against dust, moisture, and chemical vapors, while the module’s vibration resistance (10–2000 Hz, 10 G rms) ensures reliability in turbine halls and offshore platforms. Its wide operating temperature range (-30°C to +65°C) adapts to extreme climates, from arctic pipelines to desert power plants, ensuring consistent performance in harsh conditions.
A triple-layer conformal coating protects against dust, moisture, and chemical vapors, while the module’s vibration resistance (10–2000 Hz, 10 G rms) ensures reliability in turbine halls and offshore platforms. Its wide operating temperature range (-30°C to +65°C) adapts to extreme climates, from arctic pipelines to desert power plants, ensuring consistent performance in harsh conditions.
Hot-swappable operation:
The GE IS220PHRAH1A supports hot swapping, allowing replacement without powering down the control system. This feature reduces mean time to repair (MTTR) to under 15 minutes, critical for minimizing downtime in mission-critical applications like gas turbine control. Front-panel LEDs (Power, Fault, Activity) provide real-time status updates, enabling quick identification of issues during maintenance.
The GE IS220PHRAH1A supports hot swapping, allowing replacement without powering down the control system. This feature reduces mean time to repair (MTTR) to under 15 minutes, critical for minimizing downtime in mission-critical applications like gas turbine control. Front-panel LEDs (Power, Fault, Activity) provide real-time status updates, enabling quick identification of issues during maintenance.
Seamless integration:
The module directly interfaces with Mark VIe terminal boards like IS230TCISH6C (discrete I/O) and IS400STCIS2AFF (analog terminal blocks), simplifying wiring and reducing installation time. Its 3U VME form factor fits standard control racks, ensuring compatibility with existing systems during retrofits, making it easy to integrate into both new installations and legacy setups.
The module directly interfaces with Mark VIe terminal boards like IS230TCISH6C (discrete I/O) and IS400STCIS2AFF (analog terminal blocks), simplifying wiring and reducing installation time. Its 3U VME form factor fits standard control racks, ensuring compatibility with existing systems during retrofits, making it easy to integrate into both new installations and legacy setups.
Application Areas
-
Power Generation:
- Monitors steam turbine inlet pressure via analog inputs, adjusting bypass valves to maintain optimal flow rates during load changes.
- Controls gas turbine fuel valves using analog outputs, regulating flow to match grid demand while minimizing emissions.
- Processes discrete inputs from generator breaker status sensors, triggering protective actions during grid faults.
-
Oil and Gas:
- Measures pipeline pressure in offshore platforms, using analog outputs to adjust compressor speeds and prevent surge conditions.
- Monitors wellhead temperature via RTD inputs, activating heating systems to prevent fluid freezing in subsea environments.
- Processes discrete signals from emergency shutdown (ESD) valves, ensuring rapid closure during hazardous events.
-
Heavy Manufacturing:
- Regulates boiler feedwater flow in steel mills by processing flowmeter signals and adjusting control valves.
- Monitors chemical reactor pressure, using discrete outputs to trigger relief valves if pressure exceeds safe limits.
-
Renewable Energy:
- Controls biogas turbine fuel mixing valves based on gas composition sensor inputs, optimizing combustion efficiency.
- Monitors wind turbine nacelle temperature, activating cooling fans via discrete outputs to prevent generator overheating.
Related Products
- GE IS230TCISH6C: Discrete I/O terminal board that works with GE IS220PHRAH1A to manage dry contact signals from limit switches and valves.
- GE IS400STCIS2AFF: Analog terminal board that conditions sensor signals before transmission to GE IS220PHRAH1A, reducing noise in high-interference environments.
- GE IS220PPROS1B: Redundant power supply module that delivers stable 24 VDC to GE IS220PHRAH1A, ensuring reliable operation in critical loops.
- GE IS420ESWBH3A: Ethernet switch that extends IONET connectivity, enabling GE IS220PHRAH1A to communicate with remote I/O racks in distributed systems.
- GE IS220PVIBH1A: Vibration monitoring module whose data is processed alongside GE IS220PHRAH1A inputs for comprehensive machinery health assessment.
- GE IS230SRTDH2A: RTD input module that complements GE IS220PHRAH1A by providing high-precision temperature data for turbine bearing monitoring.
Installation and Maintenance
Pre-installation preparations: Before installing GE IS220PHRAH1A, verify the control rack is properly grounded to prevent electrostatic discharge (ESD). Use an ESD wrist strap during handling to protect sensitive components. Mount the module in a 3U VME rack with 50 mm clearance for airflow, securing it with M4 screws (torque: 0.6 N·m). Connect shielded cables to the IS230TCISH6C terminal board for I/O signals and to the Mark VIe controller via Ethernet ports, ensuring correct polarity for power connections (24 VDC ±10%).
Maintenance suggestions: Perform monthly visual inspections of GE IS220PHRAH1A front-panel LEDs to confirm normal operation (green Power, no Fault). Clean dust from ventilation slots using compressed air to maintain cooling efficiency. Quarterly, use a signal generator to calibrate analog channels, verifying ±0.1% accuracy. Inspect terminal connections for corrosion, especially in humid environments. Annually, update firmware via GE’s Proficy software to access bug fixes and enhance compatibility with newer I/O modules. Test redundancy by disconnecting one Ethernet port, ensuring seamless failover to the backup path.
