GE IS215UCCCM04A Product Specification
Product Overview：GE IS215UCCCM04A
The GE IS215UCCCM04A is ahttps://www.ygplc.com/ high-performance Universal Control and Communication Module designed for advanced industrial automation systems, specifically as part of GE’s PACSystems RX3i platform. Engineered to serve as the central processing unit (CPU) in distributed control systems (DCS), this module integrates computing, communication, and control functionalities to manage complex industrial processes with precision. The GE IS215UCCCM04A is ideal for applications requiring real-time data processing, seamless network integration, and robust reliability, such as power generation, oil and gas, and manufacturing.
As a core component of the PACSystems RX3i family, the GE IS215UCCCM04A features a 1.8 GHz Intel Pentium M processor and 1.5 GB DDR SDRAM, delivering rapid execution of control algorithms and concurrent communication with field devices. Its dual Gigabit Ethernet ports support redundant network configurations, ensuring uninterrupted data flow in mission-critical environments. The module also includes a PCI-X expansion slot for adding specialized I/O or communication modules, enhancing its adaptability to diverse system requirements. With a compact form factor (160 mm width × 200 mm height × 80 mm depth) and rugged metal casing, the GE IS215UCCCM04A is built to withstand harsh industrial conditions, including extreme temperatures (-40°C to +70°C) and vibration (5–500 Hz, 2 g).
In automation architectures, the GE IS215UCCCM04A acts as the brain of the system, coordinating between field-level devices (sensors, actuators) and supervisory control layers. It supports multiple communication protocols, including Ethernet/IP, Modbus, and Profibus, enabling integration with both legacy and modern industrial networks. The module’s compatibility with GE’s Proficy Machine Edition software simplifies programming, diagnostics, and firmware updates, reducing operational complexity and downtime. By combining high-speed processing, flexible connectivity, and industrial-grade durability, the GE IS215UCCCM04A empowers industries to optimize productivity, enhance system uptime, and meet stringent regulatory standards.
Technical Specifications：GE IS215UCCCM04A
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS215UCCCM04A |
| Manufacturer | General Electric (GE) |
| Product Type | Universal Control and Communication Module (CPU) |
| Processor | 1.8 GHz Intel Pentium M |
| Memory | 1.5 GB DDR SDRAM |
| Communication Interfaces | Dual Gigabit Ethernet (10/100/1000BaseT), PCI-X expansion slot |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 160 mm (W) × 200 mm (H) × 80 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 2 g (IEC 60068-2-6) |
| Certifications | CE, UL, CSA |
GE IS215UCCCM04A
Main Features and Advantages：GE IS215UCCCM04A
High-Speed Processing and Multitasking: The GE IS215UCCCM04A’s 1.8 GHz Intel processor and ample memory enable simultaneous execution of control logic, data logging, and network communication, making it suitable for high-speed automation tasks. It supports up to 10,000 I/O points, ensuring scalability for large-scale systems without performance degradation.
Redundant Network Architecture: The dual Gigabit Ethernet ports allow for active-backup network configurations, minimizing the risk of communication failures. This feature is critical in industries like power generation, where uninterrupted control is essential to prevent blackouts or equipment damage.
Flexible Expansion Capability: The PCI-X slot allows integration of specialized modules, such as analog I/O, serial communication interfaces, or motion control cards. This flexibility eliminates the need for multiple standalone controllers, streamlining system design and reducing hardware costs.
Industrial-Grade Durability: Built with a ruggedized enclosure and conformal-coated circuitry, the GE IS215UCCCM04A resists dust, moisture, and electromagnetic interference (EMI). Its wide temperature and vibration tolerance make it suitable for harsh environments, including factory floors, offshore platforms, and outdoor installations.
User-Friendly Software Ecosystem: Compatible with GE’s Proficy software suite, the module supports ladder logic, structured text, and function block programming, catering to diverse engineering preferences. Real-time diagnostics and remote firmware updates via the Proficy platform enhance maintainability and reduce downtime.
GE IS215UCCCM04A
Application Areas：GE IS215UCCCM04A
The GE IS215UCCCM04A is deployed across industries that demand reliable, high-performance control systems:
-
Power Generation:
- Manages steam or gas turbine operations in thermal power plants, optimizing fuel efficiency and load balancing.
- Integrates with renewable energy systems (e.g., wind farms) to coordinate power generation and grid synchronization.
-
Oil and Gas:
- Controls upstream wellhead operations, midstream pipeline networks, and downstream refinery processes.
- Supports real-time monitoring of pressure, flow, and temperature, enabling quick response to process anomalies and ensuring safety compliance.
-
Manufacturing:
- Oversees automated production lines in automotive, food and beverage, and pharmaceutical industries, ensuring precise control of robotics, conveyors, and quality control systems.
- Enables predictive maintenance by analyzing machine data to detect wear and tear before failures occur.
-
Water and Wastewater Treatment:
- Automates pump stations, filtration systems, and chemical dosing processes, ensuring consistent water quality and regulatory compliance.
- Provides remote access for operators to monitor system status and adjust parameters via SCADA interfaces.
Related Products
- GE IS215UCVCM01A: A variant with enhanced cybersecurity features, including firewall and VPN capabilities, designed for IIoT-connected environments.
- GE IS215UCSCM02A: A compact CPU module for smaller-scale applications, offering similar functionality at a reduced cost.
- GE IS215UCDMM03A: A distributed motion module that works alongside the GE IS215UCCCM04A to control servo drives in complex machinery.
- GE IS215UCPBM05A: A backplane module that expands the I/O capacity of the PACSystems RX3i platform, supporting up to 16 additional modules.
- GE IS215UCDSM01A: A safety-rated module for SIL 3 applications, providing redundant control paths for critical safety interlocks.
GE IS215UCCCM04A
Installation and Maintenance：GE IS215UCCCM04A
Pre-installation Preparation:
Before installing the GE IS215UCCCM04A, ensure the following:
Before installing the GE IS215UCCCM04A, ensure the following:
- Verify the power supply meets the module’s requirements (24 VDC) and that the control cabinet is properly grounded to mitigate EMI.
- Install the module in a RX3i backplane, aligning it with the PCI-X and power connectors to ensure secure mechanical and electrical contact.
- Use Proficy Machine Edition to configure network settings, assign IP addresses, and define communication protocols for connected devices.
Maintenance Recommendations:
- Routine Checks: Monitor front-panel LED indicators regularly to verify power status, network connectivity, and module health. A flashing red LED indicates a fault requiring immediate attention.
- Cooling System Maintenance: Clean dust from the module’s ventilation slots quarterly to prevent overheating, especially in high-dust environments.
- Firmware Management: Update firmware annually or as needed to address security vulnerabilities or add new features, following GE’s recommended procedures to avoid bricking the module.
- Redundancy Testing: Periodically simulate network failures to ensure the dual Ethernet ports switch seamlessly between primary and backup connections, maintaining system availability.
GE IS215UCCCM04A
Product Warranty：GE IS215UCCCM04A
Our company provides a one-year quality warranty for the GE IS215UCCCM04A, covering all non-human-caused hardware defects. If the module exhibits issues such as failed processors, faulty communication ports, or memory errors during the warranty period, we will promptly replace it at no additional cost. For discontinued or hard-to-find models like the GE IS215UCCCM04A, our extensive global inventory and supply chain network ensure fast delivery for urgent orders. Beyond the warranty period, we offer comprehensive repair services and technical support to help maintain your system’s performance indefinitely.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on technical data from GE’s official documentation and industry applications. For detailed operational instructions or customization options, consult the GE IS215UCCCM04A user manual or contact our technical team for personalized support.
