GE IS200TRLYH1BHH Solid State Relay Module
Product Overview：GE IS200TRLYH1BHH
The GE IS200TRLYH1BHH solid state relay module is a high-reliability industrial component designed for precise switching control in GE’s Mark VIe Speedtronic turbine control systems. As a key member of the IS200 series, this module serves as a robust interface between digital control signals and high-power industrial loads, enabling safe and efficient operation of motors, valves, and actuators in critical applications. Engineered to meet the demands of harsh industrial environments, the IS200TRLYH1BHH combines advanced solid-state technology with a rugged design to deliver exceptional performance in power generation, oil & gas, and manufacturing sectors.
The IS200TRLYH1BHH features 16 independent relay channels, each capable of switching up to 240V AC/30V DC loads with minimal power consumption. Its solid-state design eliminates mechanical wear, providing a longer lifespan and higher switching speeds compared to traditional electromechanical relays. The module integrates seamlessly with GE’s Mark VIe controllers, accepting digital input signals and converting them into reliable output commands for process control. With its dual redundancy support, the IS200TRLYH1BHH ensures continuous operation even in the event of a single channel failure, making it ideal for mission-critical systems where downtime is unacceptable.
In automation architectures, the IS200TRLYH1BHH acts as a vital link between the control system and field devices, ensuring accurate execution of control logic. Its LED status indicators provide real-time feedback on channel activity, simplifying troubleshooting and maintenance. The module’s compact form factor (177.8mm x 101.6mm x 76.2mm) and DIN rail mounting facilitate easy integration into existing control panels, while its -40°C to 85°C operating temperature range and IP20 protection rating make it suitable for use in extreme industrial conditions. By combining high switching capacity with advanced diagnostic features, the IS200TRLYH1BHH enhances the reliability and efficiency of industrial control systems.
Technical Specifications：GE IS200TRLYH1BHH
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TRLYH1BHH |
| Manufacturer | GE |
| Product Type | Solid State Relay Module |
| Input Voltage | 24V DC ±10% |
| Output Voltage | 240V AC / 30V DC |
| Channels | 16 (independent solid-state relays) |
| Switching Current | 5A per channel (continuous) |
| Physical Dimensions | 177.8mm (H) x 101.6mm (W) x 76.2mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to 85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail |
| Country of Origin | United States |
GE IS200TRLYH1BHH
GE IS200TRLYH1BHH
Main Features and Advantages：GE IS200TRLYH1BHH
High-Density Switching with Redundancy: The IS200TRLYH1BHH offers 16 isolated relay channels, allowing simultaneous control of multiple loads in a compact footprint. Its dual-channel redundancy option ensures that if one channel fails, the redundant channel takes over instantly, minimizing disruption to critical processes. This feature is particularly valuable in applications such as turbine shutdown systems or emergency control loops.
Solid-State Reliability: Unlike mechanical relays, the IS200TRLYH1BHH uses solid-state semiconductor devices, eliminating moving parts and reducing wear and tear. This results in a mean time between failures (MTBF) of over 1 million hours, making it suitable for long-running industrial applications where maintenance access is limited. The module’s overvoltage protection and transient suppression further enhance its durability in harsh electrical environments.
Easy Integration and Diagnostics: The module’s plug-and-play design allows quick installation in GE’s Mark VIe racks, with pre-wired terminal blocks for simple connection to field devices. Built-in LED indicators for each channel show input status and fault conditions, enabling rapid identification of issues without specialized tools. Additionally, the IS200TRLYH1BHH supports remote diagnostics via the Mark VIe system, allowing operators to monitor relay health and performance from a central control room.
Wide Environmental Tolerance: Designed to withstand extreme conditions, the IS200TRLYH1BHH operates reliably in temperatures ranging from -40°C to 85°C and resists dust, moisture, and vibration. Its IP20-rated enclosure protects against accidental contact and solid particles, while the flame-retardant PCB materials comply with international safety standards, making it suitable for use in hazardous areas with proper system certification.
GE IS200TRLYH1BHH
Application Areas：GE IS200TRLYH1BHH
The GE IS200TRLYH1BHH solid state relay module is widely deployed in industries requiring precise, reliable switching control:
- Power Generation: Used in gas and steam turbine control systems to manage auxiliary equipment such as lubrication pumps, cooling fans, and emergency shutdown valves. The module’s redundancy features ensure continuous operation of critical systems during power plant startups, shutdowns, and normal operation.
- Oil and Gas: In refineries and offshore platforms, the IS200TRLYH1BHH controls pneumatic valves, motor starters, and safety interlocks in complex processing systems. Its ability to withstand high temperatures and corrosive environments makes it ideal for upstream and downstream applications.
- Industrial Manufacturing: Integrates with PLCs and DCS systems in manufacturing lines to control conveyors, robotic arms, and packaging equipment. The module’s fast switching speed (microsecond-level response) supports high-throughput production environments where precision and speed are critical.
- Water and Wastewater Treatment: Manages pumps, filters, and chemical dosing systems in water treatment plants, ensuring reliable operation of purification processes. The module’s diagnostic features help maintain compliance with regulatory requirements by minimizing downtime and process interruptions.
- Mining and Metals: Used in heavy machinery control systems to operate crushers, conveyor belts, and ventilation systems. The IS200TRLYH1BHH’s rugged design ensures reliable performance in dusty, high-vibration mining environments.
GE IS200TRLYH1BHH
Related Products：GE IS200TRLYH1BHH
- IS200TRLYH1BHA: A 16-channel relay module with lower current rating (3A per channel), suitable for low-power applications. Offers similar form factor and integration but with reduced load capacity compared to the IS200TRLYH1BHH.
- IS215TRLYH1A: A next-generation relay module with enhanced diagnostic capabilities and support for Ethernet-based communication. Serves as an upgrade path for systems requiring advanced connectivity.
- IS200ADIIH1A: A dual-channel analog input module that works alongside the IS200TRLYH1BHH to provide feedback from sensors, enabling closed-loop control systems.
- IS200AEPCH1AB: A redundant power supply module designed for GE’s Mark VIe systems, ensuring stable power delivery to the IS200TRLYH1BHH and other modules.
- IS220PAOCH1A: An analog output module that complements the IS200TRLYH1BHH by providing continuous control signals for proportional valves or variable speed drives.
- IS410SRLYS2A: A solid-state relay terminal board that simplifies field wiring for the IS200TRLYH1BHH, offering a secure and organized connection point for high-power cables.
- IS200BPPCH1ACA: A processor module that controls the IS200TRLYH1BHH and other I/O modules, executing control logic and managing system redundancy.
Installation and Maintenance：GE IS200TRLYH1BHH
Pre-installation Preparations:
Before installing the IS200TRLYH1BHH, ensure the control cabinet is properly grounded and free of debris. Verify that the 24V DC power supply matches the module’s requirements and that all field devices (valves, motors) connected to the relay channels are within the module’s voltage and current ratings. Mount the module on a DIN rail using the provided clips, ensuring adequate spacing for heat dissipation. Connect the power cables to the terminal block, following GE’s wiring diagrams to ensure correct polarity, and terminate the load cables securely to prevent arcing or loose connections.
Before installing the IS200TRLYH1BHH, ensure the control cabinet is properly grounded and free of debris. Verify that the 24V DC power supply matches the module’s requirements and that all field devices (valves, motors) connected to the relay channels are within the module’s voltage and current ratings. Mount the module on a DIN rail using the provided clips, ensuring adequate spacing for heat dissipation. Connect the power cables to the terminal block, following GE’s wiring diagrams to ensure correct polarity, and terminate the load cables securely to prevent arcing or loose connections.
Maintenance Recommendations:
Regular maintenance of the IS200TRLYH1BHH includes quarterly inspections to check for loose connections, damaged cables, or overheating. Use a dry cloth to clean the module’s surface and ensure ventilation slots are unobstructed. Annually, test each relay channel using a multimeter to confirm proper switching functionality and check the module’s firmware for updates via GE’s ToolboxST software. In high-dust environments, increase cleaning frequency to prevent dust accumulation that could affect thermal performance. If a channel fails, replace the module with a pre-tested spare, ensuring the new unit is configured identically to the original to maintain system integrity.
Regular maintenance of the IS200TRLYH1BHH includes quarterly inspections to check for loose connections, damaged cables, or overheating. Use a dry cloth to clean the module’s surface and ensure ventilation slots are unobstructed. Annually, test each relay channel using a multimeter to confirm proper switching functionality and check the module’s firmware for updates via GE’s ToolboxST software. In high-dust environments, increase cleaning frequency to prevent dust accumulation that could affect thermal performance. If a channel fails, replace the module with a pre-tested spare, ensuring the new unit is configured identically to the original to maintain system integrity.
GE IS200TRLYH1BHH
Product Warranty：GE IS200TRLYH1BHH
Our company provides a 12-month quality warranty for the GE IS200TRLYH1BHH solid state relay module, covering all non-human-induced hardware defects. During the warranty period, we will promptly replace any module that exhibits performance issues or functional failures. For discontinued models or urgent repair needs, our global supply chain network ensures rapid availability of spare parts, minimizing downtime and supporting the continuous operation of your industrial systems.
With 17 years of expertise in industrial control distribution, we are committed to delivering products that meet the highest standards of reliability and performance. The IS200TRLYH1BHH exemplifies our dedication to providing robust solutions for mission-critical applications. Contact us today to leverage our inventory and technical support for your automation needs.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for official technical documentation. Always refer to GE’s manuals for detailed installation and safety guidelines.
