GE IS200TBCIH2CAA Terminal Block Interface Module
Product Overview: GE IS200TBCIH2CAA
The GE IS200TBCIH2CAA terminal block interface module is a high-reliability industrial component designed for GE’s Mark VIe Turbine Control System, a cornerstone of automation in power generation and heavy machinery applications. As a critical interface between field wiring and control system racks, this module enables seamless connectivity for analog and digital signals, ensuring precise data transmission and robust protection for turbine control networks. The IS200TBCIH2CAA serves as a bridge between sensors, actuators, and the Mark VIe controller, supporting real-time monitoring and control in mission-critical environments.
Engineered for industrial durability, the IS200TBCIH2CAA features a rugged metal enclosure and modular design, allowing easy integration with GE’s VMIVME-7803 processor modules and IS200 series I/O cards. Its 24V DC isolated inputs/outputs and EMI/RFI shielding ensure signal integrity in noisy industrial settings, while the hot-swappable design minimizes downtime during maintenance. The module’s -40°C to +70°C operating range and IP20 protection rating make it suitable for harsh environments, including power plants, oil refineries, and manufacturing facilities.
Within the Mark VIe system, the IS200TBCIH2CAA plays a pivotal role in organizing and protecting control signals, enabling operators to manage turbine speed, load, and safety interlocks with precision. Its compatibility with GE’s Proficy Machine Edition software and compliance with IEEE standards solidify its position as a trusted solution for critical turbine control applications, where reliability and performance are non-negotiable.
Technical Specifications: GE IS200TBCIH2CAA
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TBCIH2CAA |
| Manufacturer | GE |
| Product Type | Terminal Block Interface Module |
| Signal Type | Analog and digital I/O |
| Input Voltage | 24V DC (isolated) |
| Number of Channels | 16 channels (8 inputs/8 outputs) |
| Electrical Isolation | 500V DC between channels and ground |
| Physical Dimensions | 228.6 mm (H) × 101.6 mm (W) × 76.2 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (GE Mark VIe system) |
| Compliance | IEEE 1149.1 (JTAG), RoHS |
| Country of Origin | United States |
Main Features and Advantages: GE IS200TBCIH2CAA
Robust Signal Conditioning: The IS200TBCIH2CAA provides electrical isolation and noise filtering for 16 channels, ensuring accurate signal transmission in high-interference environments. This feature is critical for maintaining control precision in turbine systems, where signal integrity directly impacts operational safety.
Modular and Hot-Swappable Design: The module’s plug-and-play architecture allows replacement without powering down the system, reducing maintenance downtime. Its standardized design within the Mark VIe ecosystem enables easy integration with existing control setups, minimizing installation complexity.
Wide Environmental Tolerance: Built to withstand extreme temperatures and harsh conditions, the IS200TBCIH2CAA ensures reliable operation in challenging industrial settings. Its metal enclosure and EMI/RFI shielding protect against electromagnetic interference, enhancing system stability.
Comprehensive Diagnostic Capabilities: Integrated LED indicators provide real-time status feedback for each channel, simplifying troubleshooting. The module’s self-test functions help identify faulty connections or signal anomalies, enabling proactive maintenance.
Scalable System Integration: As part of GE’s Mark VIe family, the IS200TBCIH2CAA supports scalable configurations, from small turbine setups to large-scale power plant networks. It seamlessly interfaces with GE’s control processors and I/O modules, ensuring cohesive system performance.
Application Areas: GE IS200TBCIH2CAA
The GE IS200TBCIH2CAA terminal block interface module is essential for industries relying on precise turbine control and monitoring:
- Power Generation: Installed in thermal, hydro, and combined-cycle power plants to interface with turbine sensors and actuators, enabling real-time control of speed, pressure, and load. The module supports critical safety interlocks to prevent overspeeding or mechanical failure.
- Oil and Gas: Deployed in natural gas turbines and compressor stations to manage fuel flow, temperature, and vibration monitoring. Its rugged design withstands the harsh conditions of offshore platforms and refineries.
- Manufacturing: Used in heavy machinery applications, such as steam turbines in paper mills or chemical plants, to regulate process parameters and ensure consistent production quality.
- Marine Engineering: Integrates with shipboard turbine systems for propulsion and power generation, providing reliable signal management in marine environments with high vibration and humidity.
- District Heating: Controls steam turbines in district heating networks, optimizing heat distribution and energy efficiency in urban infrastructure.
Related Products: GE IS200TBCIH2CAA
- GE IS200TBIIH1BAA: A digital input module compatible with the IS200TBCIH2CAA, expanding digital signal processing capabilities in Mark VIe systems.
- GE IS200TBOIH1CAA: A digital output module that works alongside the IS200TBCIH2CAA to control actuators and relays in turbine control loops.
- GE VMIVME-7803: The Mark VIe processor module that coordinates with the IS200TBCIH2CAA to execute control algorithms and manage system operations.
- GE IS200TBVIH1DAA: An analog input module for voltage signals, complementing the IS200TBCIH2CAA in systems requiring mixed signal types.
- GE IS200TBCNH1BAA: A terminal block connector kit for the IS200TBCIH2CAA, providing replacement wiring components for maintenance.
- GE IS200TBSCH1CAA: A surge protection module that enhances the IS200TBCIH2CAA by safeguarding against electrical transients in field wiring.
Installation and Maintenance: GE IS200TBCIH2CAA
Pre-installation Preparations:
Before installing the IS200TBCIH2CAA, verify the control rack is properly grounded and powered (24V DC). Clean the mounting surface and align the module with the rack guides, securing it with the provided screws. Connect field wiring to the terminal blocks, following GE’s wiring diagrams to ensure correct polarity and signal type. Use shielded cables for analog signals to minimize interference, and verify all connections are tight to prevent loose contacts.
Before installing the IS200TBCIH2CAA, verify the control rack is properly grounded and powered (24V DC). Clean the mounting surface and align the module with the rack guides, securing it with the provided screws. Connect field wiring to the terminal blocks, following GE’s wiring diagrams to ensure correct polarity and signal type. Use shielded cables for analog signals to minimize interference, and verify all connections are tight to prevent loose contacts.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for loose connections, damaged cables, or overheating. Use the module’s LED indicators to confirm channel status (green for normal operation, red for faults).
- Periodic Cleaning: Quarterly cleaning of the module’s vents and terminals to remove dust and debris, ensuring optimal heat dissipation and electrical conductivity.
- Functional Testing: Annually test each channel’s signal integrity using a multimeter, replacing any faulty channels promptly. Update firmware via GE’s Proficy software to access the latest features and bug fixes.
- Spare Parts Management: Keep a spare IS200TBCIH2CAA and terminal block kits on hand, leveraging our global supply chain for quick replacement of discontinued components.
Product Guarantee: GE IS200TBCIH2CAA
Our company provides a 12-month quality warranty for the GE IS200TBCIH2CAA terminal block interface module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with faulty isolation, damaged terminals, or communication failures at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous operation of your critical systems.
With 17 years of expertise in industrial control distribution, we are committed to delivering reliable products and exceptional service. The IS200TBCIH2CAA exemplifies our dedication to quality, offering robust signal management for GE’s Mark VIe turbine control systems. Contact us today to optimize your industrial connectivity with this advanced interface module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical manuals.
