GE IS200PMCIH1AAA6BA00 Mark VIe Power Management Control Module
Product Overview
The GE IS200PMCIH1AAA6BA00 is a high-reliability Power Management Control Module designed as a critical component of GE’s Mark VIe distributed control system (DCS), specializing in power generation and industrial automation. Engineered to manage power distribution and control logic in steam and gas turbine applications, this module ensures precise regulation of power supply and system stability in mission-critical environments. As part of the IS200 Series, the IS200PMCIH1AAA6BA00 integrates seamlessly with other Mark VIe components, such as I/O modules and communication gateways, forming the backbone of turbine control systems in power plants, oil & gas facilities, and heavy manufacturing.
Featuring a rugged industrial design, the GE IS200PMCIH1AAA6BA00 supports redundant power input configurations (24 V DC) and advanced fault detection, ensuring continuous operation during transient power fluctuations. Its modular architecture allows flexible integration with field devices, while built-in diagnostic tools monitor power quality, voltage levels, and thermal conditions in real time. The module’s compatibility with GE’s Proficy software suite enables remote configuration and predictive maintenance, reducing downtime and enhancing operational efficiency. With a wide operating temperature range (-40°C to +85°C) and compliance with industry standards (e.g., IEEE 1131-2), the IS200PMCIH1AAA6BA00 delivers reliable performance in harsh industrial environments, from offshore platforms to thermal power stations.
In automation ecosystems, the IS200PMCIH1AAA6BA00 serves as the power management hub, converting control signals into precise power adjustments for turbine operations. Its dual-core processing architecture ensures rapid response to load changes, while redundant communication interfaces (Ethernet, RS-485) maintain data integrity in high-noise environments. By combining power regulation with system protection, this module optimizes energy efficiency and safeguards critical equipment from overvoltage, overcurrent, and thermal stress, making it indispensable for industries requiring uninterrupted power generation and distribution.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200PMCIH1AAA6BA00 |
| Manufacturer | GE |
| Product Type | Power Management Control Module |
| Platform | Mark VIe |
| Input Voltage | 24 V DC ±10% (dual redundant inputs) |
| Output Voltage | 5 V DC, 12 V DC, 24 V DC (regulated) |
| Power Output | 150 W maximum |
| Communication Interfaces | Ethernet (10/100 Mbps), RS-485, Profibus DP |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 2.1 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted (19-inch standard) |
| Certifications | CE, UL, IEEE 1131-2 |
Key Features and Advantages
Redundant Power Architecture: The IS200PMCIH1AAA6BA00 features dual redundant power inputs, ensuring continuous operation even if one input fails. This design eliminates single points of failure, critical for 24/7 industrial operations.
Advanced Power Conditioning: Built-in voltage regulation and filtering mechanisms maintain stable power output, protecting connected equipment from fluctuations and surges. The module’s thermal management system prevents overheating in high-load scenarios.
Real-Time Diagnostics: Integrated self-diagnostic tools monitor power quality, component health, and communication integrity, providing real-time alerts via LED indicators and the Mark VIe control network. This proactive approach reduces troubleshooting time and enhances system availability.
Modular and Hot-Swappable Design: The module can be replaced without powering down the system, allowing maintenance during operation. Its plug-and-play design simplifies installation and reduces downtime during upgrades or repairs.
Wide Environmental Tolerance: Engineered to withstand extreme temperatures, vibration, and electromagnetic interference, the IS200PMCIH1AAA6BA00 meets rigorous industrial standards, making it suitable for harsh environments like refineries and power plants.
Seamless System Integration: Compatible with GE’s Mark VIe ecosystem, the module interfaces seamlessly with I/O modules (e.g., IS200AAHAH2ADC) and control processors, enabling unified management via Proficy software.
Application Areas
The GE IS200PMCIH1AAA6BA00 is essential for power management in critical industrial sectors:
- Power Generation: Manages power distribution in steam and gas turbines, ensuring stable grid synchronization and load sharing in thermal, hydro, and combined-cycle power plants.
- Oil & Gas: Regulates power supply for compressors, pumps, and processing equipment in refineries, pipelines, and offshore platforms, adapting to fluctuating operational demands.
- Manufacturing: Controls power input for high-speed machinery in automotive, chemical, and pharmaceutical plants, optimizing energy use and preventing equipment damage from power irregularities.
- Water/Wastewater Treatment: Manages power for pumps and filtration systems, ensuring consistent operation in water treatment facilities and wastewater plants.
Specific applications include:
- Turbine Power Regulation: Adjusts power supply to match turbine load changes, maintaining speed and frequency stability in power generation.
- Redundant Power Systems: Implements failover mechanisms in critical processes, such as emergency shutdown systems (ESD) and safety instrumented systems (SIS).
- Energy Efficiency Optimization: Monitors and adjusts power consumption in industrial processes to reduce energy waste and support sustainability goals.
Related Products
- IS200PWRCH1A Power Supply Module: Provides redundant power to the IS200PMCIH1AAA6BA00, ensuring uninterrupted operation.
- IS200TCTGG1A Turbine Control Module: Works in tandem with the IS200PMCIH1AAA6BA00 to manage turbine speed and load.
- IS200COMM Communication Module: Enables Ethernet connectivity for the IS200PMCIH1AAA6BA00, supporting remote monitoring.
- IS200TBCH Terminal Block Module: Simplifies field wiring for the IS200PMCIH1AAA6BA00, reducing installation complexity.
- IS200ALG Algorithm Module: Executes power management algorithms in conjunction with the IS200PMCIH1AAA6BA00 for advanced control.
- IS200DSCCG1A Digital Signal Conditioning Module: Conditions input signals for the IS200PMCIH1AAA6BA00 in mixed-signal applications.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS200PMCIH1AAA6BA00, ensure the Mark VIe rack is properly grounded and ventilated. Verify power supply compatibility (24 V DC) and install redundant power cables for reliability. Mount the module in the rack using anti-vibration brackets, ensuring adequate spacing for heat dissipation. Connect input power and communication cables using shielded wiring to minimize electromagnetic interference. Use GE’s Proficy software to configure power parameters, such as voltage thresholds and alarm settings, before commissioning.
Before installing the GE IS200PMCIH1AAA6BA00, ensure the Mark VIe rack is properly grounded and ventilated. Verify power supply compatibility (24 V DC) and install redundant power cables for reliability. Mount the module in the rack using anti-vibration brackets, ensuring adequate spacing for heat dissipation. Connect input power and communication cables using shielded wiring to minimize electromagnetic interference. Use GE’s Proficy software to configure power parameters, such as voltage thresholds and alarm settings, before commissioning.
Maintenance Suggestions:
- Routine Inspections: Quarterly checks of LED indicators to verify power status and module health. Use Proficy software to review diagnostic data for voltage fluctuations or thermal anomalies.
- Cleaning and Cooling: Monthly cleaning of module vents to prevent dust accumulation, which can cause overheating. Ensure the rack’s cooling system functions optimally.
- Calibration and Testing: Annually calibrate voltage outputs using a precision multimeter to maintain accuracy. Test redundant power failover mechanisms to ensure reliability.
- Spare Parts Management: Store spare IS200PMCIH1AAA6BA00 modules in a controlled environment (10–30°C, <50% humidity) for rapid replacement during failures.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS200PMCIH1AAA6BA00, covering hardware defects under normal use. In the event of power regulation issues or functional failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS200PMCIH1AAA6BA00 and related spares. Our technical support team assists with installation, configuration, and troubleshooting, delivering reliable solutions to maintain your power management systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
