GE IS200EGDMH1ADF Ethernet Communication Module
Product Overview: GE IS200EGDMH1ADF
The GE IS200EGDMH1ADF Ethernet communication module is a high-reliability industrial networking component designed for GE’s Mark VIe Turbine Control System, a cornerstone of distributed control systems (DCS) in power generation and process industries. As a critical interface within the Mark VIe platform, this module enables seamless data exchange between programmable logic controllers (PLCs), human-machine interfaces (HMIs), and supervisory control and data acquisition (SCADA) systems, ensuring real-time monitoring and control of complex industrial processes. The IS200EGDMH1ADF integrates advanced networking protocols with rugged hardware to support mission-critical applications in power plants, oil refineries, and manufacturing facilities.
Featuring dual 10/100 Mbps Ethernet ports, the IS200EGDMH1ADF supports multiple communication protocols, including Modbus TCP/IP, EtherNet/IP, and Profinet, enabling flexible integration with diverse automation ecosystems. Its hot-swappable design allows replacement without system shutdown, minimizing downtime in continuous operations, while built-in redundancy mechanisms ensure uninterrupted data transmission. The module’s -40°C to +70°C operating temperature range and IP20 protection rating make it suitable for harsh industrial environments, resisting dust, vibration, and electromagnetic interference.
Within automation architectures, the IS200EGDMH1ADF serves as a bridge between field devices and enterprise-level networks, facilitating real-time data analytics and predictive maintenance. Its compatibility with GE’s Mark VIe system (e.g., IS200CPU modules) and compliance with industry standards (e.g., IEEE 802.3) solidifies its role in critical infrastructure, where reliable communication is essential for optimizing equipment performance and reducing operational risks.
Technical Specifications: GE IS200EGDMH1ADF
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200EGDMH1ADF |
| Manufacturer | GE |
| Product Type | Ethernet Communication Module |
| Communication Protocols | Modbus TCP/IP, EtherNet/IP, Profinet |
| Network Interfaces | 2 x 10/100 Mbps Ethernet (RJ45) |
| Input Voltage | 24V DC (±10%) |
| Physical Dimensions | 178 mm (H) × 102 mm (W) × 76 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (Mark VIe system) |
| Compliance | IEEE 802.3, IEC 61000-6-2 |
| Country of Origin | United States |
Main Features and Advantages: GE IS200EGDMH1ADF
Multi-Protocol Connectivity: The IS200EGDMH1ADF supports diverse industrial communication protocols, eliminating the need for multiple gateways and enabling seamless integration with legacy and modern systems. This versatility simplifies network architecture and reduces integration costs in complex automation setups.
Redundant Design for Reliability: With dual Ethernet ports and built-in failover mechanisms, the module ensures continuous operation even if one network path fails. This redundancy is critical for applications where data loss could lead to production interruptions, such as in power plant turbine control.
Hot-Swappable Functionality: The module can be replaced without powering down the system, allowing maintenance during operation. This feature minimizes mean time to repair (MTTR) and enhances overall system availability in 24/7 industrial processes.
Industrial-Grade Durability: Engineered for harsh environments, the IS200EGDMH1ADF withstands extreme temperatures, vibration, and electromagnetic interference. Its rugged construction ensures reliable performance in challenging settings, from offshore platforms to manufacturing floors.
Easy Configuration and Monitoring: The module supports web-based configuration via a built-in interface, enabling intuitive setup and real-time status monitoring. This reduces dependency on specialized software and simplifies maintenance for operational teams.
Application Areas: GE IS200EGDMH1ADF
The GE IS200EGDMH1ADF Ethernet communication module is essential for industries requiring robust and flexible data connectivity:
- Power Generation: Integrates with gas and steam turbine control systems in power plants, enabling real-time monitoring of generator performance, load management, and grid synchronization.
- Oil and Gas: Deploys in refineries and pipeline networks to connect process controllers with SCADA systems, supporting remote monitoring of pressure, flow, and temperature parameters.
- Manufacturing: Links PLCs and robotic systems in automotive and pharmaceutical production lines, ensuring seamless coordination between machines and central control systems.
- Water Treatment: Connects pump stations and filtration systems to plant-wide networks, enabling automated adjustment of processes based on real-time data.
- Aerospace and Defense: Supports communication in ground support equipment and military automation systems, where reliable data transmission is critical for mission success.
Related Products: GE IS200EGDMH1ADF
- GE IS200CPUxxxxx: Central processing units for the Mark VIe system, working alongside the IS200EGDMH1ADF to process and transmit control data.
- GE IS200VCMCH1AA: Voltage control modules that interface with the IS200EGDMH1ADF for power system regulation in turbine applications.
- GE IS200TBVCH1AA: Terminal base modules providing physical connectivity for the IS200EGDMH1ADF and other Mark VIe components.
- GE IS200DSVCH1AA: Digital servo modules that integrate with the IS200EGDMH1ADF for precise motion control in industrial machinery.
- GE IS200PTWCH1AA: Power supply modules ensuring stable voltage for the IS200EGDMH1ADF and associated components.
- GE IS200ALGCH1BA: Analog input/output modules that feed process data to the IS200EGDMH1ADF for network transmission.
Installation and Maintenance: GE IS200EGDMH1ADF
Pre-installation Preparations:
Before installing the IS200EGDMH1ADF, verify the control cabinet is properly grounded and the power supply (24V DC) matches the module’s requirements. Clean the rack slot and ensure adequate ventilation to maintain optimal operating temperature. Align the module with the rack guides, securing it with retention brackets, and connect shielded Ethernet cables to the dual ports, following GE’s wiring specifications to minimize electromagnetic interference. Configure IP addresses and communication protocols using GE’s Proficy software, testing network connectivity before commissioning.
Before installing the IS200EGDMH1ADF, verify the control cabinet is properly grounded and the power supply (24V DC) matches the module’s requirements. Clean the rack slot and ensure adequate ventilation to maintain optimal operating temperature. Align the module with the rack guides, securing it with retention brackets, and connect shielded Ethernet cables to the dual ports, following GE’s wiring specifications to minimize electromagnetic interference. Configure IP addresses and communication protocols using GE’s Proficy software, testing network connectivity before commissioning.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include verifying LED status indicators for network activity, tightening cable connections, and cleaning dust from ventilation slots.
- Firmware Updates: Periodically update firmware via the module’s web interface to access new features and security patches, ensuring compatibility with evolving industrial protocols.
- Redundancy Testing: Quarterly simulate network failures to verify failover functionality, ensuring continuous operation in case of cable or port issues.
- Environmental Monitoring: Regularly assess ambient temperature and humidity to prevent overheating or condensation, which could impact module performance.
Product Guarantee: GE IS200EGDMH1ADF
Our company provides a 12-month quality warranty for the GE IS200EGDMH1ADF Ethernet communication module, covering non-human-induced hardware defects. During the warranty period, we will replace any module with communication failures, power issues, or physical damage at no cost. For discontinued models or urgent needs, our global supply chain network ensures prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to delivering reliable products and exceptional service. The IS200EGDMH1ADF exemplifies our dedication to quality, offering robust communication solutions for critical infrastructure. Contact us today to optimize your automation network with this advanced Ethernet module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical manuals.
