Sale!
GE IS200AEADH4A 109W3660P001 | Analog Input/Output Module | IS200AEPAH1AFD
GE IS200AEADH4A 109W3660P001 | Analog Input/Output Module | IS200AEPAH1AFD - Image 2
GE IS200AEADH4A 109W3660P001 | Analog Input/Output Module | IS200AEPAH1AFD - Image 3
GE IS200AEADH4A 109W3660P001 | Analog Input/Output Module | IS200AEPAH1AFD - Image 4

GE IS200AEADH4A 109W3660P001 | Analog Input/Output Module | IS200AEPAH1AFD GE

Original price was: $1,000.00.Current price is: $850.00.

Brand model:GE
Product Name:IS200AEADH4A 109W3660P001
Warranty: 1 year
Size:178 mm (H) × 101 mm (W) × 76 mm (D)
Weight:1.27kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Get a Quote
Category: Brand:

Description

GE IS200AEADH4A 109W3660P001 Product Specification

Product Overview

The GE IS200AEADH4A 109W3660P001 is a high-reliability analog input/output module designed for GE’s Mark VIe Turbine Control Platform, a cornerstone of industrial automation in power generation and heavy manufacturing. Engineered to handle precision signal conditioning for critical processes, this module serves as a vital interface between field sensors/actuators and the turbine control system, enabling real-time monitoring and control of analog signals in harsh industrial environments. Part of GE’s IS200 series, the GE IS200AEADH4A 109W3660P001 integrates advanced signal processing with rugged design, making it indispensable for mission-critical applications in power plants, oil refineries, and heavy machinery systems.



Featuring 16 channels of analog input (AI) and 8 channels of analog output (AO), the GE IS200AEADH4A 109W3660P001 supports industry-standard ranges (0–10 VDC, 4–20 mA) and includes built-in surge protection to mitigate electrical disturbances. Its 16-bit resolution ensures precise measurement and control, while the modular design allows seamless integration with GE’s Proficy software for configuration and diagnostics. The module’s compact form factor (178 mm × 102 mm × 254 mm) and rugged metal enclosure enable reliable operation in temperatures ranging from -40°C to +70°C, withstanding vibration (5–500 Hz, 2 g) typical of turbine-driven environments.



In automation architectures, the GE IS200AEADH4A 109W3660P001 acts as a frontline component for data acquisition and control, processing parameters like temperature, pressure, and flow rate in real time. Its compatibility with GE’s Genius Bus ensures high-speed data transfer to the main control processor, while diagnostic LEDs and self-test functions enhance system availability. By combining robust hardware with flexible software integration, the module empowers engineers to optimize turbine performance, reduce downtime, and maintain compliance with industry safety standards.

Technical Specifications

Parameter Name Parameter Value
Product Model GE IS200AEADH4A 109W3660P001
Manufacturer General Electric (GE)
Product Type Analog Input/Output Module
Channels 16 AI, 8 AO
Input Range 0–10 VDC, 4–20 mA (software-selectable)
Output Range 0–10 VDC, 4–20 mA
Resolution 16-bit
Power Supply 24 VDC ±10%
Physical Dimensions 178 mm (W) × 102 mm (H) × 254 mm (D)
Weight 1.8 kg
Communication Protocol GE Genius Bus
Operating Temperature -40°C to +70°C
Vibration Resistance 5–500 Hz, 2 g (IEC 60068-2-6)
Certifications CE, UL, ISO 10873

Main Features and Advantages

Dual-Mode Signal Handling: The GE IS200AEADH4A 109W3660P001 supports both analog input and output signals, offering versatility for hybrid control systems. Its 16 AI channels with 16-bit resolution enable precise monitoring of continuous variables (e.g., steam pressure, turbine speed), while 8 AO channels ensure accurate actuation of valves or drives. This dual capability reduces the need for separate modules, simplifying system architecture and costs.



Enhanced Diagnostic Capabilities: Built-in self-test (BIST) functionality continuously monitors channel integrity, power supply stability, and thermal conditions. Faults are indicated via front-panel LEDs and logged in the control system, allowing proactive maintenance. The module stores diagnostic history for post-fault analysis, minimizing mean time to repair (MTTR) in critical applications.



Rugged Industrial Design: Constructed with a reinforced metal casing and conformal-coated PCBs, the GE IS200AEADH4A 109W3660P001 resists dust, moisture, and electromagnetic interference (EMI), ensuring reliable operation in harsh environments like power plant control rooms or offshore platforms. Its wide temperature and vibration tolerance eliminates the need for additional conditioning, reducing installation complexity.



Seamless System Integration: As part of GE’s Mark VIe platform, the module integrates directly with GE’s Proficy software for configuration, calibration, and remote diagnostics. This compatibility allows engineers to customize signal scaling, filter settings, and alarm thresholds without hardware modifications, adapting to unique operational requirements (e.g., load-sharing or emergency shutdown protocols).



Hot-Swap Capability: The module supports hot-swapping, enabling replacement without powering down the control system. This feature is critical for 24/7 operations, as it minimizes downtime during maintenance or component failure, enhancing overall system availability.

Application Areas

The GE IS200AEADH4A 109W3660P001 is purpose-built for industries requiring precise analog signal management in critical systems:



  1. Power Generation:
    • Monitors steam turbine parameters (temperature, pressure, flow) in combined cycle power plants, enabling real-time adjustments to fuel supply and blade positioning for optimal efficiency.
    • Controls generator excitation systems by processing analog feedback from voltage sensors, ensuring stable grid synchronization.
  2. Oil and Gas:
    • Manages pipeline pressure and flow rates in upstream/downstream processes, integrating with SCADA systems for remote monitoring.
    • Regulates valve actuators in refinery distillation units, maintaining precise control over crude oil processing parameters.
  3. Industrial Manufacturing:
    • Maintains temperature and pressure control in chemical reactors, ensuring consistent product quality in pharmaceutical or petrochemical production.
    • Monitors vibration and displacement in high-speed rotating machinery, triggering alarms or shutdowns via analog outputs to prevent equipment damage.
  4. Marine Propulsion:
    • Controls marine turbine speed and load in commercial vessels, processing analog signals from shaft sensors and adjusting fuel injectors via AO channels.
    • Integrates with shipboard power management systems to optimize energy distribution across auxiliary turbines.

Related Products

  • GE IS200TCTAH1B: A turbine control module with advanced PID tuning, often used alongside the GE IS200AEADH4A 109W3660P001 for closed-loop speed control.
  • GE IS200DSVIH1A: A servo drive interface module that converts digital control signals to analog outputs, complementing the GE IS200AEADH4A 109W3660P001 in precision actuation systems.
  • GE IS200AEBIH1BED: A communication module with dual Gigabit Ethernet ports, enabling the GE IS200AEADH4A 109W3660P001 to integrate with IIoT platforms for remote monitoring.
  • GE IS200PTVIH1A: A pressure transducer interface module for high-accuracy pressure measurements, expanding the GE IS200AEADH4A 109W3660P001’s sensor compatibility.
  • GE IS200ALGHH1A: A logic solver module that executes safety algorithms based on AI data from the GE IS200AEADH4A 109W3660P001, supporting SIL 3-compliant safety systems.

Installation and Maintenance

Pre-installation Preparation:
Before installing the GE IS200AEADH4A 109W3660P001, ensure the following:



  • Verify the power supply meets 24 VDC ±10% and that the control rack is properly grounded to prevent ESD damage.
  • Use GE’s Proficy software to configure channel types (AI/AO), input/output ranges, and calibration parameters based on sensor/actuator specifications.
  • Mount the module in a 19″ rack with at least 50 mm clearance for airflow, avoiding high-heat components.



Maintenance Recommendations:



  • Routine Inspections: Monthly checks of front-panel LEDs (green for normal, red for faults) and cleaning dust from vents to maintain optimal cooling.
  • Calibration: Annual calibration of AI/AO channels using certified test equipment to ensure measurement accuracy, particularly in high-precision applications.
  • Firmware Updates: Periodic updates via GE’s software to access bug fixes and compatibility with newer control system versions.
  • Spare Parts Management: Keeping a spare GE IS200AEADH4A 109W3660P001 on hand for critical systems, as hot-swapping reduces downtime during replacements.

Product Warranty

Our company provides a one-year quality warranty for the GE IS200AEADH4A 109W3660P001, covering hardware failures due to non-human factors. During the warranty period, we will replace any module exhibiting abnormal signal processing or functional defects. For discontinued models like the GE IS200AEADH4A 109W3660P001, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through certified technicians, ensuring your critical systems remain operational long-term.



Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com



Note: This description is based on GE’s official specifications and industry applications. For detailed guidelines, refer to the GE IS200AEADH4A 109W3660P001 user manual or contact our technical support team.
