GE IC698CPE030 Control Processor for 90-70 Series PLC
Product Overview: GE IC698CPE030
The GE IC698CPE030 control processor is a high-performance central processing unit designed for GE’s 90-70 Series Programmable Logic Controllers (PLCs). As the core component of this advanced automation platform, the IC698CPE030 delivers robust computational capabilities and reliable operation for mission-critical industrial applications. Engineered to handle complex control algorithms and real-time data processing, this processor serves as the brain of automation systems, enabling precise coordination of I/O modules, communication interfaces, and field devices.
Featuring a 32-bit RISC processor and 256 MB RAM, the IC698CPE030 supports high-speed execution of control logic, with scan times as low as 0.1 ms for basic instructions. Its dual Ethernet ports (10/100 Mbps) enable seamless integration with supervisory control and data acquisition (SCADA) systems, while the hot-swappable design allows replacement without system shutdown—a critical feature for minimizing downtime in continuous production environments. The processor’s -40°C to +70°C operating temperature range and IP20 protection rating ensure durability in harsh industrial settings, from manufacturing plants to oil refineries.
Within automation ecosystems, the IC698CPE030 acts as the central hub for GE’s 90-70 Series, supporting advanced features like redundant control paths, predictive maintenance protocols, and cybersecurity measures. Its compatibility with GE’s Proficy Machine Edition software enables intuitive programming in IEC 61131-3 languages, while the built-in real-time clock ensures accurate event timestamping for diagnostic and logging purposes. By combining high performance with rugged reliability, the IC698CPE030 optimizes system efficiency and reduces total cost of ownership for industrial operators.
Technical Specifications: GE IC698CPE030
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC698CPE030 |
| Manufacturer | GE |
| Product Type | PLC Control Processor |
| Processor | 32-bit RISC, 400 MHz |
| Memory | 256 MB RAM, 512 MB Flash |
| Communication Interfaces | 2 x Ethernet (10/100 Mbps), 1 x RS485 |
| Programming Languages | IEC 61131-3 (LD, ST, FBD, SFC) |
| Physical Dimensions | 178 mm (H) × 102 mm (W) × 279 mm (D) |
| Weight | 1.8 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (GE 90-70 Series) |
| Compliance | UL 508, CSA C22.2, CE |
| Country of Origin | United States |
Main Features and Advantages: GE IC698CPE030
High-Speed Processing: The IC698CPE030’s 400 MHz processor and optimized memory architecture enable rapid execution of complex control logic, supporting up to 1 million I/O operations per second. This performance is critical for high-speed manufacturing lines or real-time process control in energy sectors.
Redundant Communication Paths: With dual Ethernet ports, the processor supports network redundancy (e.g., Ring Topology) to ensure continuous data transmission. This feature is vital for applications where communication failures could lead to safety hazards or production losses, such as in chemical processing plants.
Rugged Industrial Design: Built to withstand harsh conditions, the IC698CPE030 features a metal enclosure and wide temperature tolerance. Its resistance to vibration, dust, and electromagnetic interference makes it suitable for demanding environments like mining or offshore platforms.
Advanced Cybersecurity: The processor integrates the GE Proficy Security Suite, offering features like user authentication, firmware validation, and encrypted communication to protect against cyber threats—a key advantage in today’s connected industrial landscapes.
Scalable System Integration: As part of the 90-70 Series, the IC698CPE030 supports up to 14 I/O modules per chassis, enabling scalable configurations from small control panels to large-scale plant-wide systems. Its compatibility with legacy 90-70 components ensures smooth migration for existing users.
Application Areas: GE IC698CPE030
The GE IC698CPE030 control processor is ideally suited for industries that require reliable, high-performance automation:
- Manufacturing: Powers automotive assembly lines, robotic welding cells, and CNC machining centers, ensuring precise control over complex motion profiles and quality inspection systems.
- Power Generation: Manages steam turbines, generators, and grid synchronization in thermal, hydro, and renewable energy plants, with real-time data processing for optimal energy output.
- Oil and Gas: Controls pipeline pressure, flow rates, and safety interlocks in refineries and offshore platforms, supporting 24/7 operation in harsh, remote environments.
- Water Treatment: Orchestrates pump stations, filtration systems, and chemical dosing in water/wastewater plants, ensuring regulatory compliance and continuous operation.
- Aerospace and Defense: Supports mission-critical control systems in aircraft ground support equipment and military installations, where reliability and security are non-negotiable.
Related Products: GE IC698CPE030
- GE IC698MDL750: A digital input module compatible with the IC698CPE030, converting field signals (24V DC) for PLC processing.
- GE IC698MDL740: A digital output module that interfaces with the processor to control relays and solenoids in automation systems.
- GE IC698ALG724: An analog output module for precise control of variable-speed drives and valves, complementing the processor in process control applications.
- GE IC698CMM711: A communication module enabling Ethernet/IP and Modbus TCP/IP protocols for the IC698CPE030, facilitating cloud integration.
- GE IC698CHS790D: A rack chassis that houses the IC698CPE030 and up to 13 additional modules, providing mechanical support and power distribution.
- GE IC698PWR711: A redundant power supply module for the 90-70 Series, ensuring stable 24V DC delivery to the IC698CPE030.
Installation and Maintenance: GE IC698CPE030
Pre-installation Preparations:
Before installing the IC698CPE030, verify the control cabinet is properly grounded and ventilated to maintain ambient temperatures between -40°C and +70°C. Clean the rack slot and ensure the GE 90-70 Series chassis (e.g., IC698CHS790D) is securely mounted. Slide the processor into the first slot of the chassis, securing it with retention brackets. Connect the 24V DC power supply to the terminal block, ensuring correct polarity, and establish Ethernet connections using shielded cables for optimal signal integrity. Download and install GE’s Proficy Machine Edition software to configure the processor’s IP address and programming environment.
Before installing the IC698CPE030, verify the control cabinet is properly grounded and ventilated to maintain ambient temperatures between -40°C and +70°C. Clean the rack slot and ensure the GE 90-70 Series chassis (e.g., IC698CHS790D) is securely mounted. Slide the processor into the first slot of the chassis, securing it with retention brackets. Connect the 24V DC power supply to the terminal block, ensuring correct polarity, and establish Ethernet connections using shielded cables for optimal signal integrity. Download and install GE’s Proficy Machine Edition software to configure the processor’s IP address and programming environment.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include verifying status LEDs (power, run, fault), tightening cable connections, and cleaning dust from ventilation slots to prevent overheating.
- Firmware Updates: Periodically update the processor’s firmware via GE’s official website to access security patches and new features, using the Proficy software to ensure compatibility.
- Redundancy Testing: Quarterly tests of dual Ethernet ports and power supplies ensure failover functionality, minimizing downtime in case of component failure.
- Spare Parts Management: Keep a spare IC698CPE030 on hand, pre-configured with current firmware, to facilitate rapid replacement during emergencies, leveraging our global supply chain for quick delivery.
Product Guarantee: GE IC698CPE030
Our company provides a 12-month quality warranty for the GE IC698CPE030 control processor, covering hardware defects from non-human causes. During the warranty period, we will replace any processor with abnormal performance—such as unstable operation or communication failures—at no cost. For discontinued models or urgent needs, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing disruptions to your industrial operations.
With 17 years of expertise in industrial control distribution, we are committed to delivering reliable solutions and exceptional support. The IC698CPE030 exemplifies our dedication to quality, offering the performance and durability required for critical automation systems. Contact us today to optimize your PLC infrastructure with this advanced control processor.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical manuals.
