GE IC697PCM711P Communication Processor Module
Product Overview: GE IC697PCM711P
The GE IC697PCM711P communication processor module is a high-performance industrial communication solution designed for GE’s 90-70 Series Programmable Logic Controllers (PLCs). As a critical component of this advanced automation platform, the IC697PCM711P enables seamless data exchange between PLCs, remote I/O systems, and higher-level supervisory networks, making it an essential asset for complex industrial control architectures. Engineered to support multiple communication protocols, this module bridges the gap between field-level devices and enterprise-level systems, ensuring real-time data transmission and centralized monitoring in mission-critical applications.
Featuring a 32-bit RISC processor and dual Ethernet ports (10/100 Mbps), the IC697PCM711P supports protocols such as Ethernet/IP, Modbus TCP, and Profibus DP, enabling compatibility with diverse automation devices. Its hot-swappable design allows replacement without system shutdown, minimizing downtime in continuous production environments, while the redundant power supply input (24V DC) enhances reliability. The module’s compact form factor (178 mm x 101 mm x 76 mm) and DIN rail mounting simplify integration into existing control cabinets, while its -40°C to +55°C operating temperature range ensures performance in harsh industrial settings.
Within automation systems, the IC697PCM711P acts as a communication hub, facilitating data exchange between GE 90-70 Series CPUs (e.g., IC697CPU780) and external devices like HMIs, SCADA systems, and cloud-based analytics platforms. Its ability to handle high-speed data transfer and protocol conversion makes it ideal for industries requiring real-time monitoring and control, such as manufacturing, power generation, and oil & gas.
Technical Specifications: GE IC697PCM711P
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC697PCM711P |
| Manufacturer | GE |
| Product Type | Communication Processor Module |
| Processor | 32-bit RISC, 200 MHz |
| Communication Interfaces | 2 x Ethernet (10/100 Mbps), 1 x RS485 |
| Supported Protocols | Ethernet/IP, Modbus TCP, Profibus DP, DF1 |
| Power Supply | 24V DC (±10%), redundant input |
| Physical Dimensions | 178 mm (H) × 101 mm (W) × 76 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | -40°C to +55°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail (GE 90-70 Series rack) |
| Country of Origin | United States |
Main Features and Advantages: GE IC697PCM711P
Multi-Protocol Connectivity: The IC697PCM711P supports the simultaneous operation of multiple industrial communication protocols, eliminating the need for separate gateways. This versatility allows seamless integration of legacy and modern devices, reducing system complexity and costs in mixed-technology environments.
Redundant and Rugged Design: With dual Ethernet ports and redundant power inputs, the module ensures continuous operation even in the event of a single component failure. Its rugged metal enclosure and wide temperature tolerance make it suitable for harsh environments, including manufacturing plants, offshore platforms, and mining sites.
High-Speed Data Processing: The 32-bit processor enables real-time data translation and high-speed communication (up to 100 Mbps), critical for applications requiring low-latency control, such as robotic assembly lines or high-speed packaging systems.
Hot-Swappable Functionality: The module can be replaced while the system is running, the need for downtime during maintenance or upgrades. This feature is vital for industries like pharmaceuticals and food & beverage, where production interruptions must be minimized.
Scalable System Integration: Compatible with GE’s 90-70 Series racks (e.g., IC697CHS790D), the IC697PCM711P supports scalable automation architectures, from small standalone systems to large, networked installations with hundreds of I/O points.
Application Areas: GE IC697PCM711P
The GE IC697PCM711P communication processor module is ideally suited for industries that require robust and flexible data communication:
- Manufacturing: Integrates CNC machines, robotic cells, and conveyor systems into a unified network, enabling real-time production data monitoring and remote equipment adjustment in automotive, electronics, and consumer goods facilities.
- Power Generation: Connects turbine control systems, generators, and grid management platforms in thermal, hydro, and renewable energy plants, ensuring stable power output and grid synchronization.
- Oil and Gas: Facilitates communication between pipeline sensors, pumping stations, and central control rooms in refineries and offshore platforms, supporting real-time flow control and safety interlocks.
- Water Treatment: Manages data transmission between pumps, valves, and analytical instruments in water/wastewater plants, ensuring regulatory compliance and efficient resource management.
- Aerospace and Defense: Supports mission-critical communication in aircraft ground support equipment and military automation systems, where reliable data exchange is non-negotiable.
Related Products: GE IC697PCM711P
- GE IC697CPU780: A high-performance CPU module for the 90-70 Series, working alongside the IC697PCM711P to execute control algorithms and manage communication tasks.
- GE IC697CHS790D: A 14-slot rack chassis that houses the IC697PCM711P and other 90-70 Series modules, providing mechanical support and power distribution.
- GE IC697MDL740: A digital input module that interfaces with the IC697PCM711P to convert field signals for network transmission.
- GE IC697CMM711: A communication module supporting Ethernet/IP, complementary to the IC697PCM711P for complex network configurations.
- GE IC697PWR711: A redundant power supply module for the 90-70 Series rack, ensuring stable power for the IC697PCM711P and other components.
- GE IC697ALG724: An analog output module that works with the IC697PCM711P to control variable-speed drives in process control applications.
Installation and Maintenance: GE IC697PCM711P
Pre-installation Preparations:
Before installing the IC697PCM711P, verify the power supply (24V DC) and ensure the GE 90-70 Series rack is properly grounded. Clean the rack slot and inspect for debris, then slide the module into the designated position, securing it with the provided retention brackets. Connect the redundant power cables to the terminal block, following GE’s wiring diagrams to avoid polarity errors. Configure the Ethernet ports using GE’s Proficy software, setting IP addresses and protocol parameters to match the network infrastructure.
Before installing the IC697PCM711P, verify the power supply (24V DC) and ensure the GE 90-70 Series rack is properly grounded. Clean the rack slot and inspect for debris, then slide the module into the designated position, securing it with the provided retention brackets. Connect the redundant power cables to the terminal block, following GE’s wiring diagrams to avoid polarity errors. Configure the Ethernet ports using GE’s Proficy software, setting IP addresses and protocol parameters to match the network infrastructure.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include verifying the module’s status LEDs (green for normal operation), tightening cable connections, and cleaning dust from ventilation slots to maintain thermal performance.
- Firmware Updates: Periodically update the module’s firmware using GE’s official software to access new features, security patches, and protocol enhancements.
- Communication Testing: Quarterly tests of Ethernet ports and protocol functionality ensure data transmission reliability. Use network analyzers to monitor packet loss and latency.
- Spare Parts Management: Keep a spare IC697PCM711P on hand, leveraging our global supply chain for rapid replacement of discontinued or faulty components.
Product Guarantee: GE IC697PCM711P
Our company provides a 12-month quality warranty for the GE IC697PCM711P communication processor module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with communication failures, power supply issues, or physical damage at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt delivery, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable solutions and exceptional service. The IC697PCM711P exemplifies our dedication to quality, offering the connectivity and durability required for critical automation systems. Contact us today to optimize your industrial communication infrastructure with this robust module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical manuals.
