GE IC697ALG440 Analog Input Module
Product Overview: GE IC697ALG440
The GE IC697ALG440 analog input module is a high-precision industrial automation component designed for GE’s 90-70 Series PLC system. As a key member of this advanced control platform, the IC697ALG440 converts analog signals from field devices into digital data for processing by the PLC, enabling precise monitoring and control of industrial processes. Engineered for reliability and accuracy, this module supports multiple signal types and features advanced diagnostics, making it an essential component for complex automation systems in manufacturing, energy, and process industries.
Featuring 16 isolated analog input channels, the IC697ALG440 accepts various input types, including 4–20 mA, 0–10 V DC, and thermocouple signals, with a resolution of 16 bits. Its auto-ranging capability eliminates the need for manual configuration, reducing setup time and minimizing errors. The module’s hot-swappable design allows replacement without system shutdown, while its built-in self-diagnostics (LED indicators and fault reporting) enhance maintainability. Compatible with GE’s Series 90-70 racks (e.g., IC697CHS790), the IC697ALG440 ensures seamless integration into existing control architectures.
In automation systems, the IC697ALG440 serves as a critical interface between analog sensors (e.g., pressure transducers, temperature probes) and the PLC, enabling real-time data acquisition for process optimization. Its -40°C to +70°C operating range and IP20 protection rating make it suitable for harsh industrial environments, while compliance with CE, UL, and CSA standards ensures global applicability. By delivering accurate and reliable analog-to-digital conversion, this module enhances system precision, reduces downtime, and supports data-driven decision-making.
Technical Specifications: GE IC697ALG440
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC697ALG440 |
| Manufacturer | GE |
| Product Type | Analog Input Module |
| Input Channels | 16 isolated channels |
| Input Signal Types | 4–20 mA, 0–10 V DC, thermocouples (J, K, T) |
| Resolution | 16 bits |
| Accuracy | ±0.05% of full scale |
| Update Rate | <1 ms per channel |
| Physical Dimensions | 101.6 mm (H) × 152.4 mm (W) × 76.2 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | -40°C to +70°C |
| Communication Protocol | Series 90-70 背板通信 |
| Mounting Type | Rack-mounted (GE 90-70 Series) |
| Country of Origin | United States |
Main Features and Advantages: GE IC697ALG440
High-Precision Signal Conversion: The IC697ALG440 delivers 16-bit resolution and ±0.05% accuracy, ensuring precise measurement of analog signals. This precision is critical for applications requiring tight process control, such as chemical dosing or temperature regulation in pharmaceutical manufacturing.
Versatile Input Compatibility: With support for multiple signal types (current, voltage, thermocouples), the module adapts to diverse sensor setups without additional signal conditioning. This versatility reduces hardware complexity and inventory needs, making it suitable for mixed-signal industrial environments.
Robust Industrial Design: The module’s rugged construction and wide temperature range enable reliable operation in harsh conditions, including vibration, dust, and extreme temperatures. Its hot-swappable feature further enhances uptime by allowing maintenance without system shutdowns, essential for continuous production lines.
Advanced Diagnostics: Built-in LED indicators and fault reporting (e.g., open circuit, overrange) provide real-time visibility into module health, reducing troubleshooting time. The module’s self-diagnostic capabilities help identify issues such as sensor failures or wiring problems proactively.
Seamless System Integration: As part of GE’s 90-70 Series, the IC697ALG440 integrates seamlessly with other 90-70 components (e.g., processors, communication modules), enabling scalable automation solutions. Its compatibility with GE’s Proficy Machine Edition software simplifies configuration and programming.
Application Areas: GE IC697ALG440
The GE IC697ALG440 analog input module is widely used in industries that require precise analog data acquisition:
- Manufacturing: Monitors pressure, temperature, and flow in automotive paint lines, food processing equipment, and semiconductor fabrication tools, ensuring process consistency and product quality.
- Power Generation: Measures analog signals from turbines, generators, and transformers in thermal, hydro, and renewable energy plants, supporting real-time performance optimization and grid stability.
- Oil and Gas: Deploys in refineries and pipeline systems to monitor pressure, level, and flow rates, enabling safe operation and efficient resource management in harsh offshore and onshore environments.
- Water Treatment: Manages analog inputs from pH sensors, flow meters, and chemical analyzers in water/wastewater plants, ensuring compliance with environmental standards and efficient treatment processes.
- Aerospace and Defense: Supports analog monitoring in test stands, ground support equipment, and military applications, where precision and reliability are non-negotiable.
Related Products: GE IC697ALG440
- GE IC697CPU780: A 90-70 Series processor that works with the IC697ALG440 to process analog data and execute control logic.
- GE IC697CHS790: A rack chassis that houses the IC697ALG440 and other 90-70 modules, providing mechanical support and power distribution.
- GE IC697ACC700: A communication module that enables Ethernet/IP connectivity for the IC697ALG440, facilitating data exchange with higher-level systems.
- GE IC697BEM731: A bus expansion module that extends the 90-70 system’s I/O capacity, allowing more IC697ALG440 modules in complex setups.
- GE IC697PWR711: A power supply module that ensures stable power for the IC697ALG440 and other rack-mounted components.
- GE IC697ALG222: A 8-channel analog input module for smaller systems, offering similar features with reduced channel count.
Installation and Maintenance: GE IC697ALG440
Pre-installation Preparations:
Before installing the IC697ALG440, ensure the GE 90-70 rack is powered off and properly grounded. Verify the module’s compatibility with the rack and other installed components (e.g., CPU, power supply). Clean the rack slot and align the module with the guides, then slide it into place and secure it with the provided screws. Connect shielded sensor cables to the terminal block, following GE’s wiring diagrams to prevent noise interference, and terminate the shield at the rack ground.
Before installing the IC697ALG440, ensure the GE 90-70 rack is powered off and properly grounded. Verify the module’s compatibility with the rack and other installed components (e.g., CPU, power supply). Clean the rack slot and align the module with the guides, then slide it into place and secure it with the provided screws. Connect shielded sensor cables to the terminal block, following GE’s wiring diagrams to prevent noise interference, and terminate the shield at the rack ground.
Maintenance Recommendations:
- Routine Inspections: Monthly checks include verifying LED status (green for normal operation), tightening cable connections, and inspecting for physical damage. Clean the module’s surface to prevent dust accumulation, which can affect heat dissipation.
- Calibration: Annually calibrate the IC697ALG440 using a certified signal source to ensure measurement accuracy. Reference GE’s calibration procedures to adjust offsets and gains as needed.
- Firmware Updates: Periodically update the module’s firmware via GE’s Proficy software to access new features and bug fixes, especially for compatibility with newer system components.
- Spare Parts Management: Keep a spare IC697ALG440 on hand for quick replacement. Ensure the spare is configured identically to the original to minimize downtime during module failure.
Product Guarantee: GE IC697ALG440
Our company provides a 12-month quality warranty for the GE IC697ALG440 analog input module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with faulty channels, communication issues, or physical damage at no cost. For discontinued models or urgent needs, our global supply chain network ensures rapid delivery of scarce components, minimizing disruptions to your operations.
With 17 years of expertise in industrial control distribution, we are committed to reliable solutions and exceptional support. The IC697ALG440 exemplifies our dedication to quality, delivering precision and durability for critical automation tasks. Contact us today to optimize your analog data acquisition with this robust module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical documentation.
