GE IC695ALG626 | Analog Input Module | IC697CPU781 GE

Original price was: $1,500.00.Current price is: $1,325.00.

Brand model:GE
Product Name:IC695ALG626
Warranty: 1 year
Weight:0.45kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Category: Brand:

Description

GE IC695ALG626 Product Specification

Product Overview

The GE IC695ALG626 is a high-precision 8-channel analog input module engineered for GE’s RX3i PLC platform, designed to convert continuous physical signals (such as temperature, pressure, and flow) from field sensors into digital data for industrial automation systems. As a core component of the RX3i distributed architecture, this module enables real-time monitoring and control of critical process variables in manufacturing, power generation, oil and gas, and water/wastewater applications.



Integrated into the RX3i system, the GE IC695ALG626 supports a wide range of analog signal types, including 4–20 mA, 0–20 mA, 0–10 VDC, and thermocouples (Type J, K, T, E, R, S, B), making it versatile for diverse sensor interfaces. Its 24-bit resolution and 100 samples/second per channel sampling rate ensure high-accuracy data conversion, critical for closed-loop control in precision processes like chemical batch production or turbine efficiency optimization.



The GE IC695ALG626 features 2500 Vrms galvanic isolation between channels and from field to logic, protecting against electrical noise and surges in high-interference environments. Its compact design (115 mm × 220 mm × 125 mm) and rugged construction—including a conformal coating and IP20 enclosure—support operation in temperatures ranging from -25°C to +70°C, with resistance to vibration (10–2000 Hz, 10 G rms) and humidity (5–95% non-condensing). Front-panel LEDs provide real-time status for power, module health, and channel activity, simplifying troubleshooting, while compatibility with GE’s Proficy Machine Edition software allows easy configuration of signal scaling, filtering, and alarm thresholds. The module’s hot-swappable design minimizes downtime during maintenance, a key advantage in continuous-process industries.

Technical Specifications

Parameter Name Parameter Value
Product Model GE IC695ALG626
Manufacturer General Electric (GE)
Product Type Analog Input Module
Series RX3i PLC Platform
Input Channels 8 (configurable per channel)
Signal Types 4–20 mA, 0–20 mA, 0–10 VDC, thermocouples (J, K, T, E, R, S, B)
Resolution 24-bit
Sampling Rate 100 samples/second per channel
Isolation 2500 Vrms (field to logic), 500 Vrms (between channels)
Physical Dimensions 115 mm (H) × 220 mm (W) × 125 mm (D)
Weight 0.75 kg
Operating Temperature -25°C to +70°C
Humidity 5–95% non-condensing
Power Supply 24 VDC ±10% (2.5 W max)
Communication RX3i backplane (100 Mbps)
Certifications CE, UL 61010-1, ATEX/IECEx Zone 2

Main Features and Advantages

High-Precision Signal Conversion:
The GE IC695ALG626 delivers 24-bit resolution and ±0.01% accuracy, ensuring precise measurement of subtle process variations—such as 0.1°C temperature changes in chemical reactors or 0.01 psi pressure fluctuations in pipeline systems. This level of precision is critical for optimizing efficiency in power plants, where small deviations can impact turbine performance or emissions.



Versatile signal compatibility:
Supporting multiple signal types (current, voltage, thermocouples) eliminates the need for external converters, simplifying system design. For example, the module can directly interface with 4–20 mA pressure transmitters in oil pipelines and Type K thermocouples in furnace chambers, reducing wiring complexity and potential failure points.



Rugged environmental resilience:
A conformal coating protects against dust, moisture, and chemical vapors, while the module’s wide operating temperature range (-25°C to +70°C) and vibration resistance (10–2000 Hz, 10 G rms) ensure reliability in harsh settings—from arctic oil fields to desert solar plants. ATEX/IECEx Zone 2 certification extends its use to hazardous locations like refineries.



Advanced isolation and noise immunity:
2500 Vrms isolation between channels and field/logic circuits prevents ground loops and EMI interference from motors or welders, ensuring stable data in noisy industrial environments. This isolation is vital for accurate readings in steel mills, where electrical noise is prevalent.



Integrated diagnostics:
Front-panel LEDs (Power, Module OK, Channel Fault) provide instant status updates, while built-in self-tests monitor signal integrity, sensor faults (e.g., open thermocouple), and overrange conditions. Faults are logged with timestamps in the PLC, enabling predictive maintenance—such as replacing aging pressure sensors before they drift out of calibration.



Seamless RX3i integration:
The GE IC695ALG626 connects directly to GE IC695CPU310 (RX3i CPU) via the backplane, enabling high-speed data transfer (100 Mbps) for real-time control. Compatibility with Proficy Machine Edition software allows easy configuration of scaling, filtering (0.1–100 ms), and alarm thresholds, reducing setup time by 30% compared to legacy modules.



Hot-swappable design:
The module supports hot swapping, allowing replacement without powering down the RX3i rack. This feature cuts mean time to repair (MTTR) to under 15 minutes, critical for maintaining uptime in continuous processes like pharmaceutical manufacturing or water treatment.

Application Areas



Power Generation:

  1. Monitors steam turbine inlet pressure via 4–20 mA transmitters, adjusting bypass valves to maintain optimal flow during load changes.
  2. Measures generator winding temperature using Type R thermocouples, triggering cooling systems to prevent overheating and insulation damage.

Oil and Gas:

  1. Processes 0–10 VDC signals from level transmitters in storage tanks, automating pump operations to prevent overflow or underflow.
  2. Monitors pipeline flow rates via 4–20 mA flowmeters, adjusting compressor speeds to maintain efficient throughput

Manufacturing:

  1. Regulates oven temperature in automotive paint shops using Type K thermocouples, ensuring consistent curing and finish quality.
  2. Measures hydraulic pressure in robotic arms via 4–20 mA sensors, optimizing motion control for precise welding

Water/Wastewater:

  1. Monitors pH levels (converted to 4–20 mA) in treatment tanks, activating chemical dosing pumps to maintain compliance with discharge standards.
  2. Tracks filter pressure drop via 0–20 mA transmitters, scheduling backwashing to prevent system clogging

Renewable Energy:

  1. Measures solar panel coolant temperature using Type T thermocouples, adjusting pump speeds to maximize inverter efficiency.
  2. Monitors wind turbine gearbox oil pressure via 4–20 mA sensors, triggering maintenance alerts for low lubrication.

Related Products

  • GE IC695CPU310: RX3i CPU module that processes data from GE IC695ALG626, serving as the system’s control core.
  • GE IC695PSD140: 24 VDC power supply module that delivers stable power to GE IC695ALG626and other RX3i modules.
  • GE IC695MDL645: 16-point discrete output module paired with GE IC695ALG626to actuate valves or motors based on analog inputs.
  • GE IC695CBL001: Backplane cable connecting GE IC695ALG626to remote RX3i racks in distributed systems.
  • GE IC695HSC304: High-speed counter module that works with GE IC695ALG626for applications requiring both analog and pulse signals.
  • GE IC695IFM001: Ethernet interface module enabling remote monitoring of GE IC695ALG626data via SCADA systems.
  • GE IC695TBM001: Terminal base that provides secure wiring connections for GE IC695ALG626, simplifying field sensor integration.

Installation and Maintenance

Pre-installation preparations: Before installing GE IC695ALG626, verify the RX3i rack is properly grounded to prevent ESD damage. Use an ESD wrist strap during handling. Mount the module in an GE IC695CHS010 10-slot rack with 30 mm clearance for airflow, securing it with M3 screws (torque: 0.5 N·m). Connect field sensors to the terminal base, ensuring correct wiring for signal type (e.g., 2-wire for 4–20 mA, 3-wire for thermocouples). Power the module via GE IC695PSD140, checking polarity to avoid damage.



Maintenance suggestions: Perform monthly visual inspections of GE IC695ALG626 LEDs to confirm normal operation (green Module OK). Clean dust from ventilation slots with compressed air quarterly. Calibrate annually using a precision signal generator to verify ±0.01% accuracy. Inspect terminal connections for corrosion, especially in humid environments. Update firmware via Proficy Machine Edition yearly to access diagnostic enhancements. Test redundancy by simulating a channel fault, ensuring the PLC triggers alarms as configured.

Product Guarantee

Our company offers a one-year quality warranty service for GE IC695ALG626, covering hardware malfunctions not caused by human factors. During the warranty period, if GE IC695ALG626 shows abnormal performance—such as signal drift beyond specifications or communication failures—we will provide replacement services. As a leading import and export trade distribution company established in 2007 with 17 years of experience, we maintain large inventories of industrial control parts, including many unpopular and discontinued models. Our supply channels and large stock allow us to meet urgent customer needs for spare parts. For discontinued models or hard-to-find components, our global supply chain network ensures rapid response to procurement demands, supporting continuous and stable operation of industrial systems.
