GE IC695ALG508-AA | Resistance Temperature Detector (RTD) input module GE

Original price was: $3,600.00.Current price is: $3,404.00.

Brand model:GE
Product Name:IC695ALG508-AA
Warranty: 1 year
Size:34 mm (W) × 145 mm (H) × 140 mm (D)
Weight:2.11kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days
Order time: one month after payment

Get a Quote
Category: Brand:

Description

GE IC695ALG508-AA Product Specification

Product Overview：GE IC695ALG508-AA

The GE IC695ALG508-AA is a high-precision Resistance Temperature Detector (RTD) input module designed for industrial automation systems, specifically within GE’s PACSystems RX3i platform. As a core component of GE’s Power & Water division, this module serves as a critical interface for temperature monitoring in harsh industrial environments, such as power plants, oil refineries, and chemical processing facilities. The GE IC695ALG508-AA is engineered to convert analog RTD signals into digital data for real-time control and analysis, ensuring optimal performance and safety in mission-critical applications.



Part of the IC695 series, the GE IC695ALG508-AA supports 8 isolated channels for 2-, 3-, or 4-wire RTD configurations, offering flexibility for diverse sensor setups. Its advanced signal conditioning capabilities reduce noise and interference, delivering accurate temperature measurements with a resolution of 12 bits. The module’s compact design (34 mm x 145 mm x 140 mm) and rugged metal enclosure allow for easy integration into rack-mounted systems while withstanding extreme temperatures (-40°C to +70°C) and vibration (5–500 Hz, 2 g), typical of industrial settings.



In automation architectures, the GE IC695ALG508-AA acts as a frontline interface for turbine control systems, steam generators, and process monitoring equipment. It communicates seamlessly with GE’s Proficy Machine Edition (PME) software, enabling engineers to configure channel parameters, perform diagnostics, and implement firmware updates remotely. By combining robust hardware with flexible software integration, the GE IC695ALG508-AA enhances system reliability, minimizes downtime, and supports compliance with industry standards such as IEC 61131-3 for programmable controllers.

Technical Specifications：GE IC695ALG508-AA

Parameter Name Parameter Value
Product Model GE IC695ALG508-AA
Manufacturer General Electric (GE)
Product Type RTD Input Module (8-channel, isolated)
Signal Configuration 2/3/4-wire RTD (software-selectable)
Resolution 12 bits
Input Range -200°C to +850°C (depending on RTD type)
Power Supply 24 VDC ±10%
Physical Dimensions 34 mm (W) × 145 mm (H) × 140 mm (D)
Weight 2 kg
Communication Protocol Proprietary GE RX3i backplane (expandable via optional gateways)
Operating Temperature -40°C to +70°C
Vibration Resistance 5–500 Hz, 2 g (IEC 60068-2-6)
Certifications CE, UL, CSA, ATEX Zone 2 (for hazardous environments)
GE IC695ALG508-AA

GE IC695ALG508-AA

Main Features and Advantages：GE IC695ALG508-AA

High-Accuracy Temperature Monitoring: The GE IC695ALG508-AA provides precise RTD signal conditioning with 12-bit resolution, ensuring accurate temperature measurements in applications where even minor deviations could impact process efficiency or safety. Its isolated channels reduce cross-talk and electromagnetic interference, critical for maintaining data integrity in noisy industrial environments.



Flexible Configuration: The module supports multiple RTD types (e.g., Pt100, Pt500) and wire configurations, allowing seamless integration with existing sensor networks. Engineers can customize channel parameters (e.g., filtering, scaling) via GE’s Proficy software, adapting the module to unique operational requirements without hardware modifications.



Rugged Industrial Design: Constructed with a reinforced metal casing and conformal-coated PCBs, the GE IC695ALG508-AA resists dust, moisture, and EMI, ensuring reliable operation in harsh conditions. Its wide temperature range and vibration tolerance eliminate the need for additional environmental conditioning, reducing installation complexity and costs.



Advanced Diagnostics: Built-in self-test (BIST) functionality continuously monitors module health, including channel integrity, power supply stability, and thermal conditions. Faults are reported via front-panel LED indicators and through the control system’s HMI, enabling proactive maintenance and minimizing mean time to repair (MTTR).



Hot-Swap Capability: The module supports hot-swapping, allowing replacement without powering down the entire system. This feature is particularly valuable in applications where continuous operation is essential, such as power generation or oil production.

GE IC695ALG508-AA

GE IC695ALG508-AA

Application Areas：GE IC695ALG508-AA

The GE IC695ALG508-AA is widely used in industries where precise temperature monitoring is critical:



  1. Power Generation:
    • Steam Turbines: Monitors bearing temperatures and steam inlet conditions to optimize energy efficiency and prevent overheating.
    • Gas Turbines: Integrates with combustion control systems to ensure safe and efficient fuel combustion, reducing emissions and maintenance costs.
  2. Oil and Gas:
    • Refineries: Manages temperature-sensitive processes in distillation units and catalytic crackers, ensuring product quality and regulatory compliance.
    • Offshore Platforms: Provides real-time temperature data for subsea pipelines and wellheads, supporting predictive maintenance and leak detection.
  3. Chemical Processing:
    • Reactor Systems: Monitors reaction temperatures to maintain process stability and prevent runaway reactions.
    • HVAC Systems: Controls climate in cleanrooms and storage facilities, ensuring product integrity.
  4. Industrial Manufacturing:
    • Metallurgy: Measures furnace temperatures in steel mills and foundries, optimizing production cycles and reducing material waste.
    • Food and Beverage: Ensures consistent pasteurization and sterilization temperatures in bottling and canning lines.
      GE IC695ALG508-AA

      GE IC695ALG508-AA

Related Products：GE IC695ALG508-AA

  • GE IC695CPU310: A high-performance controller module for the RX3i platform, providing processing power for real-time control logic execution alongside the GE IC695ALG508-AA.
  • GE IC695PSA040: A redundant power supply module that ensures continuous operation of the GE IC695ALG508-AA in mission-critical systems.
  • GE IC695ETM001: An Ethernet communication module that enables the GE IC695ALG508-AA to integrate with cloud-based IIoT platforms for remote monitoring and analytics.
  • GE IC695ALG616: A higher-channel-count RTD input module (16 channels) for applications requiring expanded temperature monitoring capabilities.
  • GE IC695DSVIH1A: A servo drive interface module that complements the GE IC695ALG508-AA in motion control systems, converting digital signals to analog outputs for precision actuators.

Installation and Maintenance：GE IC695ALG508-AA

Pre-installation Preparation:
Before installing the GE IC695ALG508-AA, ensure the following:



  • Verify the power supply meets the module’s requirements (24 VDC ±10%) and that the control rack is properly grounded to prevent EMI interference.
  • Use GE’s Proficy Machine Edition software to configure RTD type, wire configuration, and calibration parameters before mounting the module in the RX3i rack.
  • Ensure adequate airflow around the module to maintain optimal operating temperature, especially in high-density I/O configurations.



Maintenance Recommendations:



  • Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Health” indicators). Replace faulty modules immediately to avoid cascading system failures.
  • Signal Calibration: Perform annual calibration of RTD channels using certified test equipment to maintain measurement accuracy. Use GE’s calibration tools to verify linearity and offset adjustments.
  • Firmware Updates: Periodically update the module’s firmware via Proficy software to address security patches or enhance compatibility with newer control system versions.
  • Environmental Checks: Clean dust and debris from the module’s vents quarterly, particularly in dusty environments, to prevent overheating. Monitor ambient temperature and humidity levels using the control system’s built-in sensors.
    GE IC695ALG508-AA

    GE IC695ALG508-AA

Product Warranty：GE IC695ALG508-AA

Our company provides a one-year quality warranty for the GE IC695ALG508-AA, covering all non-human-induced hardware defects. During the warranty period, any module exhibiting abnormal signal processing, power supply failures, or physical defects will be replaced at no cost. For discontinued models like the GE IC695ALG508-AA, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.



Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com



Note: This document is based on technical data derived from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE IC695ALG508-AA user manual or contact our technical support team for personalized assistance.
