GE IC694ALG392-FG Product Specification
Product Overview
The GE IC694ALG392-FG is a high-performance analog output module designed for GE’s RX3i PAC (Programmable Automation Controller) system. It serves as a critical link between the PLC’s digital control signals and analog field devices, converting digital data from the CPU into precise analog outputs that can control valves, motors, and other industrial equipment. This functionality makes it essential for automation systems where precise control over physical processes is required.
The GE IC694ALG392-FG features 4 channels, each capable of delivering both voltage and current outputs. It supports common industrial ranges: 0–10 VDC, ±10 VDC for voltage, and 0–20 mA, 4–20 mA for current. This versatility allows it to integrate with a wide range of field devices without the need for additional converters. As part of the RX3i series, the GE IC694ALG392-FG works seamlessly with racks like the IC694CHS790 (16-slot) and CPUs such as the IC694CPU331, ensuring smooth communication and coordinated operation within the system.
Built to withstand harsh industrial environments, the GE IC694ALG392-FG operates in temperatures from 0°C to 60°C and handles humidity between 5% and 95% (non-condensing). Its compact design (263 mm × 58 mm × 28 mm) and lightweight structure (0.45 kg) make it easy to install in control cabinets, even in space-constrained setups. Whether in manufacturing lines, power plants, or chemical processing facilities, the GE IC694ALG392-FG provides reliable analog control to maintain precise process parameters.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC694ALG392-FG |
| Manufacturer | General Electric (GE) |
| Product Type | 4-Channel Analog Output Module (Voltage/Current) |
| Series | RX3i PAC System |
| Output Ranges | Voltage: 0–10 VDC, ±10 VDC; Current: 0–20 mA, 4–20 mA |
| Resolution | 16 bits |
| Physical Dimensions | 263 mm (L) × 58 mm (W) × 28 mm (H) [10.35″ × 2.28″ × 1.10″] |
| Weight | 0.45 kg (0.99 lb) |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5–95% non-condensing |
| Power Requirements | 24 VDC (external), 120 mA max |
| Isolation | 250 VAC (field to backplane) |
| Certifications | CE, UL 508 |
IC694ALG392-FG
Main Features and Advantages
4 channels for flexible control: The GE IC694ALG392-FG has 4 independent channels. Each channel can be set to voltage or current output. This means it can control up to 4 different devices at once, such as a valve (4–20 mA) and a variable speed drive (0–10 VDC), reducing the need for extra modules.
High precision: With 16-bit resolution, the GE IC694ALG392-FG delivers precise outputs. This accuracy ensures that devices like flow controllers or temperature regulators receive exact signals, leading to consistent process results. For example, in chemical mixing, it can adjust dosing pumps with small increments to maintain precise ratios.
Easy integration: The module fits into any slot of RX3i racks. It connects to the rack’s backplane for communication with the CPU. No extra wiring is needed for data transfer. This makes installation quick and reduces the chance of setup errors.
Rugged design: The GE IC694ALG392-FG works in tough conditions. It handles high temperatures, humidity, and vibrations. This durability ensures it works reliably in factories, outdoor power stations, or dusty industrial areas.
Clear status monitoring: Front-panel LEDs show power and module status. A green light means it’s working. A red light signals a problem, like a power issue or internal error. This helps technicians find and fix issues fast, reducing downtime.
Related Products
- GE IC694CHS790: A 16-slot RX3i rack that holds the GE IC694ALG392-FG and other modules, providing power and backplane connections.
- GE IC694CPU331: An RX3i CPU that sends digital signals to the GE IC694ALG392-FG, which converts them to analog outputs.
- GE IC694PWR710: A power supply module that provides 24 VDC to the GE IC694ALG392-FG, ensuring stable operation.
- GE IC694ALG222: A 16-channel analog input module that works with the GE IC694ALG392-FG—the input module sends sensor data to the CPU, which uses the output module to adjust devices.
- GE IC694BEM731: A communication module that allows the CPU (and thus the GE IC694ALG392-FG) to send data to HMIs for remote monitoring.
IC694ALG392-FG
Installation and Maintenance
Pre-installation preparations: Before installing the GE IC694ALG392-FG, turn off power to the RX3i rack. Check that the rack is compatible, like the IC694CHS790. Align the module with an empty slot. Slide it in until it clicks. Connect the 24 VDC power supply to the terminal block. Make sure wires are tight to avoid loose connections.
Maintenance suggestions: Check the GE IC694ALG392-FG monthly. Look at the front LEDs to ensure they show normal operation. Clean dust from the module with a dry cloth every three months. This prevents overheating. Once a year, use a multimeter to check output accuracy. If readings are off, recalibrate or replace the module. If the red LED lights up, check power connections first. If that doesn’t fix it, replace the module.
Application Areas
In manufacturing: Factories use the GE IC694ALG392-FG to control robotic arms. It converts CPU signals to 0–10 VDC outputs, adjusting arm speed for precise welding or assembly. It also controls conveyor belt speed via 4–20 mA signals, matching production rates to avoid bottlenecks.
In power plants: It controls turbine valves. The module converts CPU commands to 4–20 mA signals, adjusting valve openings to regulate steam flow. This keeps turbine speed stable, ensuring consistent electricity generation.
In chemical processing: The GE IC694ALG392-FG adjusts dosing pumps. It uses 4–20 mA outputs to control pump speed, adding exact amounts of chemicals to mixing tanks. This maintains product quality and meets safety standards.
In water treatment: It controls variable speed pumps. The module receives signals from the CPU (based on tank level data) and outputs 0–10 VDC to adjust pump speed. This keeps water levels steady and reduces energy use.
IC694ALG392-FG
