GE IC693MDL940J Digital Output Module
Product Overview
The GE IC693MDL940J is a 16-channel digital output module designed for GE’s Series 90-30 PLC systems, a key platform in industrial automation. This module converts digital signals from the PLC into electrical outputs. These outputs control external devices like motors, valves, and alarms. It acts as a bridge between the PLC’s processing unit and field equipment, making it essential for automated processes.
As part of the IC693 Series, the GE IC693MDL940J works with Series 90-30 backplane racks such as the IC693CHS393 and CPUs like the IC693CPU364. It fits into the rack’s slot, getting power and sending/receiving data through the backplane. The IC693MDL940J supports 24 V DC outputs. Each channel can handle up to 2 A of current, with a total module current limit of 8 A. This makes it strong enough for most industrial actuators.
Built for tough environments, the GE IC693MDL940J operates in temperatures from 0°C to 60°C and humidity up to 95% (non-condensing). It resists dust and vibrations, working reliably in factories, automotive plants, and food processing facilities. Even though GE no longer makes it, the GE IC693MDL940J remains vital for keeping older Series 90-30 systems running. It avoids the need for full system upgrades, saving time and money.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693MDL940J |
| Manufacturer | GE |
| Product Type | 16-channel Digital Output Module (Series 90-30) |
| Series | IC693 (Series 90-30) |
| Output Channels | 16 (isolated) |
| Output Voltage | 24 V DC |
| Output Current | 2 A per channel; 8 A total |
| Physical Dimensions | 125 mm (L) × 89 mm (W) × 64 mm (D) |
| Weight | 0.5 kg |
| Operating Temperature | 0°C to 60°C |
| Humidity Tolerance | 5%–95% (non-condensing) |
| Isolation Rating | 1500 V AC (channel to backplane) |
| Mounting Type | Backplane mount (fits Series 90-30 racks) |
IC693MDL940J
Related products
- GE IC693CHS393: A 10-slot backplane rack. The IC693MDL940J mounts onto it, getting power and data connections from the rack.
- GE IC693CPU364: A Series 90-30 CPU module. It sends digital signals to the IC693MDL940J, telling it which devices to turn on or off.
- GE IC693PWR330: A power supply module. It provides 24 V DC power to the IC693MDL940J and other modules in the rack.
- GE IC693MDL640: A 16-channel digital input module. It works with the IC693MDL940J to form a complete I/O system, where inputs trigger outputs.
- GE IC693BEM331L: A Genius bus interface module. It connects the PLC system, including the IC693MDL940J, to other network devices for centralized control.
Main features and advantages
16 channels for versatile control: The IC693MDL940J has 16 channels. This lets it control 16 separate devices at once, like 16 small motors or valves. It reduces the number of modules needed in a system, saving space in control cabinets.
Strong current handling: Each channel handles up to 2 A. This is enough for most industrial devices, from small solenoid valves to conveyor belt motors. The total 8 A limit prevents overloads, keeping the module and connected equipment safe.
Reliable isolation: The module has 1500 V AC isolation between channels and the backplane. This stops electrical noise from nearby machines affecting the module. It also protects the PLC from voltage spikes from devices like motors.
Tough for industrial use: The IC693MDL940J works in hot, cold, or damp places. It handles dust and vibrations, making it good for factories, car plants, and outdoor installations. It keeps working even in harsh conditions, reducing downtime.
Easy to integrate: It fits into Series 90-30 racks without special tools. It works with all Series 90-30 CPUs and backplanes. This makes it simple to add to existing systems or replace old modules. No need to change the whole system.
IC693MDL940J
Installation and maintenance
Pre-installation preparations: Check that the IC693MDL940J fits your Series 90-30 backplane rack (like the IC693CHS393). Make sure there is an empty slot. Turn off the PLC system before installing. Slide the module into the slot until it clicks. Connect wires from the module’s terminals to the devices it will control (motors, valves, etc.). Use 14–22 AWG wires. Tighten terminal screws to 5 lb-in. Turn the system on. Check the module’s green light is on, meaning it works.
Maintenance suggestions: Check the IC693MDL940J regularly. Wipe dust off with a dry cloth to stop overheating. Look at wire connections to make sure they are tight. Loose wires can cause devices to work incorrectly. If a channel stops working, check the connected device first. If the device is fine, turn off the system, take out the module, and put it back in. This fixes loose connections. Keep a spare IC693MDL940J in a dry, cool place (10–30°C) to replace quickly if needed.
