GE IC693CPU363 Product Specification
Product Overview
The GE IC693CPU363 is a high-performance central processing unit (CPU) module designed for GE’s Series 90-30 Programmable Logic Controller (PLC) platform. Engineered to deliver robust computational power and reliable operation, this module serves as the core of industrial automation systems, enabling real-time control and monitoring in diverse sectors such as manufacturing, power generation, and oil & gas. The GE IC693CPU363 integrates advanced processing capabilities with flexible communication interfaces, making it an essential component for applications requiring precise automation and seamless data integration.
As part of the Series 90-30 family, the GE IC693CPU363 features a 32-bit Intel i960 processor running at 20 MHz, ensuring rapid execution of control algorithms and complex logic programs. It supports up to 128 KB of user memory (expandable to 512 KB) for storing ladder logic, function block diagrams, and data tables, enabling efficient management of large-scale automation tasks. The module’s compact design (114 mm × 178 mm × 76 mm) and lightweight construction (1.2 kg) facilitate easy integration into control panels, while its rugged metal enclosure ensures durability in harsh industrial environments with temperatures ranging from -25°C to +60°C.
In automation architectures, the GE IC693CPU363 acts as the central hub for data processing, coordinating inputs from sensors, executing control strategies, and driving actuators. Its built-in RS-232/485 communication ports support protocols like Modbus and DF1, enabling seamless connectivity to HMIs, SCADA systems, and other networked devices. By combining high-speed processing with reliable performance, the GE IC693CPU363 empowers industries to optimize productivity, reduce downtime, and maintain operational efficiency in mission-critical applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693CPU363 |
| Manufacturer | General Electric (GE) |
| Product Type | Central Processing Unit (CPU) Module |
| Processor | 32-bit Intel i960 @ 20 MHz |
| Memory | 128 KB user memory (expandable to 512 KB) |
| Communication Interfaces | 2x RS-232/485 ports (Modbus, DF1 protocols) |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 114 mm (W) × 178 mm (H) × 76 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -25°C to +60°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL |
| Expansion Slots | 1x PCMCIA slot for memory expansion |
Main Features and Advantages
High-Speed Processing: The GE IC693CPU363’s 32-bit Intel processor ensures rapid scan times (up to 0.1 ms/kB), enabling real-time response to process changes. This capability is critical in high-speed manufacturing lines or dynamic control applications where split-second decisions are essential.
Flexible Memory Expansion: With support for up to 512 KB of user memory, the module accommodates complex control programs and data logging, reducing the need for external storage devices. The PCMCIA slot allows on-the-fly memory upgrades without system downtime.
Robust Communication Capabilities: The dual RS-232/485 ports facilitate seamless integration with legacy and modern systems, supporting protocols like Modbus for interoperability with third-party devices. This flexibility simplifies multi-vendor automation setups.
Rugged Industrial Design: Built with a metal enclosure and conformal-coated PCBs, the GE IC693CPU363 resists dust, moisture, and electromagnetic interference (EMI), making it suitable for harsh environments like automotive plants or offshore platforms.
Hot Swappable Design: The module supports hot swapping, allowing replacement without powering down the PLC rack. This feature minimizes downtime during maintenance or upgrades, enhancing system availability in critical applications.
Comprehensive Diagnostic Tools: Integrated self-diagnostic functions monitor processor health, memory status, and communication integrity, providing real-time feedback via front-panel LEDs. This proactive approach to maintenance reduces troubleshooting time.
Application Areas
The GE IC693CPU363 is widely deployed in industries requiring reliable automation and precise control:
-
Manufacturing:
- Packaging Lines: Controls conveyor systems, robotic arms, and labeling machines in food & beverage or pharmaceutical production, ensuring consistent output and quality.
- Metalworking: Manages CNC machines and presses, adjusting parameters in real time to optimize material processing and reduce waste.
-
Power Generation:
- Substation Automation: Coordinates circuit breaker operations and voltage regulation in electrical distribution systems, enhancing grid stability.
- Renewable Energy: Controls wind turbine pitch and speed, maximizing energy capture while protecting equipment from overloads.
-
Oil & Gas:
- Pipeline Monitoring: Processes pressure, flow, and temperature data from field sensors, triggering alarms or adjustments to maintain safe operations.
- Refinery Control: Manages distillation units and chemical reactors, ensuring precise temperature and pressure control during processing.
-
Water/Wastewater Treatment:
- Pump Station Automation: Regulates pump speed and valve positions to maintain optimal water flow in distribution networks.
- Wastewater Processing: Controls filtration systems and chemical dosing, ensuring compliance with environmental standards.
Related Products
- GE IC693CPU374: An upgraded version with a faster processor (33 MHz) and increased memory (1 MB), suitable for complex automation tasks.
- GE IC693MDL645: A digital input module (16 channels, 24 VDC) that pairs with the GE IC693CPU363 for sensor data acquisition.
- GE IC693MDL740: A digital output module (16 channels, relay output) for driving actuators and control valves.
- GE IC693ALG222: An analog input module (8 channels, 4–20 mA/0–10 VDC) for integrating temperature, pressure, or flow sensors.
- GE IC693ACC300: A communications accessory module that adds Ethernet/IP capability to the Series 90-30 platform.
- GE IC693CHS392: A chassis power supply module (24 VDC, 3 A) designed for Series 90-30 racks housing the GE IC693CPU363.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IC693CPU363, ensure the following:
Before installing the GE IC693CPU363, ensure the following:
- Verify the power supply meets 24 VDC ±10% and that the PLC chassis is properly grounded to prevent electrostatic discharge (ESD).
- Use GE’s VersaPro software to configure communication parameters (baud rate, parity) and download control programs to the module.
- Mount the module in a Series 90-30 chassis with compatible I/O modules, ensuring proper alignment with backplane connectors.
Maintenance Recommendations:
- Routine Checks: Monthly visual inspections of front-panel LEDs (green for normal operation, red for faults) and cleaning of dust from ventilation slots.
- Memory Backup: Regularly backup user programs to an external storage device to prevent data loss during module replacement.
- Firmware Updates: Periodically update the CPU firmware via GE’s programming software to access bug fixes and compatibility improvements.
- Environmental Monitoring: Maintain ambient temperature and humidity within specified ranges, as extreme conditions can degrade performance.
Product Warranty
Our company provides a one-year quality warranty for the GE IC693CPU363, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits processing errors, memory defects, or communication failures. For discontinued models like the GE IC693CPU363, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services, leveraging our network of certified technicians to keep your automation systems operational.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This description is based on technical data from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE IC693CPU363 user manual or contact our technical support team.
