GE IC693ACC323B Ethernet Communication Module
Product Overview
The GE IC693ACC323B is a high-performance Ethernet Communication Module designed for GE’s 90-30 Series PLC platform, serving as a critical interface for industrial automation systems. Engineered to enable seamless data exchange between PLCs, HMIs, and enterprise-level networks, this module bridges the gap between control systems and supervisory networks, facilitating real-time monitoring and remote control. As part of the IC693 Series, the IC693ACC323B supports advanced communication protocols, ensuring compatibility with diverse automation ecosystems in manufacturing, power generation, and process industries.
Featuring a rugged industrial design, the GE IC693ACC323B integrates two independent 10/100 Mbps Ethernet ports for redundant network configurations, minimizing downtime in mission-critical applications. Its support for protocols like Modbus TCP, Ethernet/IP, and GE’s proprietary Genius Bus enables flexible integration with third-party systems, while built-in diagnostics monitor network health and data integrity. The module’s compact form factor (101.6 mm × 152.4 mm × 127 mm) and DIN rail mounting simplify installation in control panels, while a wide operating temperature range (-40°C to +70°C) ensures reliable performance in harsh environments, such as offshore platforms and refineries.
In automation systems, the IC693ACC323B acts as a gateway for real-time data transmission, enabling remote diagnostics, program upload/download, and OPC server connectivity. Its hot-swappable design allows module replacement without powering down the system, enhancing maintainability in 24/7 operations. By combining high-speed communication with robust fault tolerance, this module optimizes system efficiency and reduces total cost of ownership, making it an essential component for industrial digitization strategies.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693ACC323B |
| Manufacturer | GE |
| Product Type | Ethernet Communication Module |
| Platform | 90-30 Series PLC |
| Communication Ports | 2 × 10/100 Mbps Ethernet (RJ45), 1 × RS-232/485 |
| Supported Protocols | Modbus TCP, Ethernet/IP, Genius Bus, DF1, Profibus DP (via gateway) |
| Input Voltage | 24 V DC ±10% |
| Power Consumption | 5 W |
| Physical Dimensions | 101.6 mm (H) × 152.4 mm (W) × 127 mm (D) |
| Weight | 0.8 kg |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, cUL, IEC 61131-2 |
Key Features and Advantages
Dual Ethernet Redundancy: The IC693ACC323B features two independent Ethernet ports, supporting ring or star network topologies for redundant communication paths. This design eliminates single points of failure, ensuring continuous operation during network maintenance or cable faults.
Multi-Protocol Support: With compatibility for Modbus TCP, Ethernet/IP, and GE’s Genius Bus, the module integrates seamlessly with diverse devices, from legacy PLCs to modern SCADA systems. This versatility reduces the need for multiple communication gateways, simplifying system architecture.
Real-Time Data Processing: The module’s high-speed processors enable sub-millisecond data transfer rates, critical for applications requiring real-time monitoring, such as predictive maintenance and remote equipment control. Its built-in buffer memory handles transient data surges without loss.
Advanced Diagnostics: LED indicators and diagnostic software provide real-time feedback on network status, link quality, and module health. Fault codes are logged for later analysis, reducing troubleshooting time and minimizing downtime.
Rugged Industrial Design: Constructed with a metal enclosure and conformal-coated circuitry, the IC693ACC323B withstands vibration, humidity, and electromagnetic interference (EMI), meeting rigorous industrial standards for harsh environments.
Hot-Swap Capability: The module can be replaced while the PLC is running, allowing maintenance without interrupting operations. This feature is essential for industries where downtime equates to significant productivity loss.
Application Areas
The GE IC693ACC323B is widely deployed in industries requiring reliable industrial communication:
- Manufacturing: Connects PLCs to HMIs and enterprise systems in automotive, food & beverage, and pharmaceutical plants, enabling real-time production data analytics and remote equipment adjustment.
- Power Generation: Facilitates communication between turbine control systems, generators, and grid management networks in thermal, hydro, and renewable energy plants, ensuring stable power distribution.
- Oil & Gas: Links offshore platforms, pipeline compressors, and refinery control systems to central monitoring stations, supporting remote operation and safety interlock activation.
- Water/Wastewater Treatment: Integrates pump stations, treatment facilities, and supervisory systems for automated flow control and regulatory compliance reporting.
- Material Handling: Coordinates conveyor networks, robotic systems, and warehouse management software in logistics centers, optimizing throughput and reducing manual intervention.
Specific applications include:
- SCADA Integration: Transmits real-time process data from PLCs to SCADA systems for comprehensive plant visualization and alarm management.
- Remote Maintenance: Enables engineers to upload/download PLC programs and perform diagnostics from remote locations, reducing travel costs and response times.
- Energy Management: Collects power consumption data from distributed systems, supporting energy efficiency initiatives and carbon footprint tracking.
Related Products
- IC693ACC300A Ethernet Module: An earlier variant with single Ethernet port, suitable for basic communication needs in smaller systems.
- IC693ACC326B Redundant Ethernet Module: Features dual ports with advanced redundancy protocols, ideal for high-availability systems.
- IC693CPU363B PLC Processor: High-performance CPU for 90-30 Series, compatible with the IC693ACC323B for integrated control and communication.
- IC693APU300B Power Supply: Redundant power supply for 90-30 Series racks, ensuring uninterrupted operation of the IC693ACC323B.
- IC693CBL301J Network Cable: Shielded Ethernet cable designed for GE’s 90-30 Series, optimizing data transmission for the IC693ACC323B.
- IC693ALG222A Analog Input Module: Works in tandem with the IC693ACC323B to transmit analog process data to supervisory networks.
- IC693PWR330A Power Supply: High-efficiency power supply supporting large racks with multiple communication modules like the IC693ACC323B.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IC693ACC323B, ensure the 90-30 Series rack is properly grounded and powered. Verify network configuration (IP addressing, subnet masks) and use shielded Ethernet cables to minimize EMI. Mount the module on a DIN rail, leaving 25 mm of space on either side for heat dissipation. Configure the module using GE’s VersaPro software, assigning communication protocols and enabling redundancy settings as needed.
Before installing the GE IC693ACC323B, ensure the 90-30 Series rack is properly grounded and powered. Verify network configuration (IP addressing, subnet masks) and use shielded Ethernet cables to minimize EMI. Mount the module on a DIN rail, leaving 25 mm of space on either side for heat dissipation. Configure the module using GE’s VersaPro software, assigning communication protocols and enabling redundancy settings as needed.
Maintenance Suggestions:
- Routine Checks: Monthly, inspect LED indicators to confirm network connectivity and module health. Use VersaPro to review diagnostic logs for error events, such as packet loss or connection interruptions.
- Cable Management: Quarterly, verify cable connections and replace any damaged or loose cables. Ensure network switches connected to the IC693ACC323B are free of dust and debris.
- Firmware Updates: Annually, update the module’s firmware through GE’s official channels to incorporate security patches and protocol enhancements, following step-by-step guidelines to avoid configuration errors.
- Redundancy Testing: Biannually, simulate network failures to validate redundant path switching, ensuring the module maintains communication during primary link outages.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IC693ACC323B, covering hardware defects under normal use. In the event of performance issues—such as connectivity failures or protocol errors—we offer prompt replacement services to minimize downtime. For legacy or discontinued models like the IC693ACC323B, our global supply chain network specializes in sourcing rare industrial components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, delivering reliable solutions to maintain your automation system’s integrity.
