GE IC690RFH008 Product Specification
Product Overview
The GE IC690RFH008 is a high-performance radio frequency (RF) communication module designed for GE’s Series 90-30 Programmable Logic Controller (PLC) platform. Engineered to enable wireless data transmission in industrial automation systems, the GE IC690RFH008 bridges the gap between field devices and central control systems, ensuring reliable connectivity in environments where wired solutions are impractical. As part of GE’s robust industrial automation portfolio, this module supports real-time monitoring and control in harsh conditions, making it indispensable for industries such as manufacturing, oil and gas, and water treatment.
Featuring a compact design and rugged construction, the GE IC690RFH008 integrates advanced RF technology with seamless PLC compatibility. It operates in the 902–928 MHz ISM band, providing up to 100 mW of transmission power for stable wireless communication. The module supports point-to-point and point-to-multipoint configurations, enabling flexible network topologies to suit diverse application needs. With its built-in error correction and interference mitigation algorithms, the GE IC690RFH008 ensures data integrity even in high-noise industrial environments, reducing downtime and enhancing operational efficiency.
In automation architectures, the GE IC690RFH008 acts as a critical link for remote I/O systems, mobile machinery, and distributed sensor networks. Its compatibility with GE’s VersaPro programming software allows engineers to configure transmission parameters, security protocols, and data encryption settings effortlessly. By eliminating the need for extensive cabling, this module simplifies installation in hard-to-reach areas, such as offshore platforms or large manufacturing facilities, while maintaining the reliability expected from GE’s industrial solutions.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC690RFH008 |
| Manufacturer | General Electric (GE) |
| Product Type | Radio Frequency (RF) Communication Module |
| Frequency Range | 902–928 MHz (ISM band) |
| Transmission Power | Up to 100 mW |
| Communication Range | Up to 1 km (line of sight) |
| Data Rate | Up to 19.2 kbps |
| Interface | RS-232/RS-485 |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 101.6 mm (W) × 152.4 mm (H) × 76.2 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL |
Main Features and Advantages
Robust Wireless Connectivity: The GE IC690RFH008 leverages 900 MHz ISM band technology to deliver reliable wireless communication in industrial settings. Its adaptive frequency hopping (AFH) feature minimizes interference from other wireless devices, ensuring consistent data transmission in congested radio environments. This capability is crucial for applications where wired connections are susceptible to damage or impractical, such as mobile conveyor systems or remote sensor networks.
Flexible Network Topologies: Supporting both point-to-point and point-to-multipoint configurations, the module adapts to diverse automation setups. Engineers can deploy it for direct communication between two PLCs or establish the network to connect multiple remote I/O units, enhancing system scalability without complex rewiring.
Enhanced Security Features: Built-in encryption protocols (128-bit AES) protect data from unauthorized access, making the GE IC690RFH008 suitable for secure industrial networks. Its error correction algorithms and cyclic redundancy check (CRC) ensure data integrity, reducing the risk of communication errors that could lead to process disruptions.
Rugged Industrial Design: Constructed with a metal enclosure and conformal-coated PCBs, the module withstands harsh conditions, including vibration, dust, and moisture. Its wide temperature range (-40°C to +70°C) enables operation in extreme environments, such as outdoor oil fields or cold storage facilities, without additional climate control.
Seamless PLC Integration: As part of GE’s Series 90-30 platform, the GE IC690RFH008 integrates directly with GE PLCs, eliminating the need for external gateways or adapters. This compatibility streamlines programming and diagnostics via GE’s VersaPro software, reducing training costs and accelerating system deployment.
Application Areas
The GE IC690RFH008 is ideal for industries requiring reliable wireless automation solutions:
-
Oil and Gas:
- Enables wireless monitoring of pipeline pressure and flow rates in remote or hard-to-reach locations, reducing installation costs for cabling in offshore platforms or rural pipelines.
- Supports real-time data transmission from mobile drilling equipment, allowing operators to adjust parameters remotely and prevent equipment failures.
-
Manufacturing:
- Connects mobile robotic arms or automated guided vehicles (AGVs) to the central control system, enabling seamless coordination in flexible production lines.
- Monitors machine health in large factories by wirelessly transmitting vibration or temperature data from hard-to-access components, such as overhead cranes or high-rise conveyors.
-
Water/Wastewater Treatment:
- Transmits level sensor data from remote wells or treatment ponds to the central PLC, eliminating the need for buried cables in wet or corrosive environments.
- Controls pump stations in flood-prone areas via wireless commands, ensuring continuous operation during inclement weather.
-
Mining:
- Establishes wireless communication between underground mining equipment and surface control rooms, improving safety and operational efficiency in environments where physical cables are susceptible to damage.
Related Products
- GE IC690RCM001: A remote I/O communication module for wired connections, often used alongside the GE IC690RFH008 in hybrid wired/wireless systems.
- GE IC693CPU363: A Series 90-30 PLC processor that integrates with the GE IC690RFH008 for complex control applications requiring wireless data processing.
- GE IC690ALG221: An analog input module that pairs with the GE IC690RFH008 to wirelessly transmit sensor data from analog devices, such as pressure transducers or flow meters.
- GE IC690ACC700: A communication accessory kit for configuring and testing the GE IC690RFH008, including antennas and diagnostic tools.
- GE IC690PWR330: A power supply module for the Series 90-30 platform, ensuring stable power delivery to the GE IC690RFH008 in industrial environments.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IC690RFH008, ensure the following:
Before installing the GE IC690RFH008, ensure the following:
- Verify the power supply meets 24 VDC ±10% and that the installation location has minimal obstructions to optimize RF signal strength.
- Use GE’s VersaPro software to configure the module’s communication parameters (e.g., frequency channel, data rate, encryption key) based on the application’s needs.
- Mount the module in a 19″ rack with at least 25 mm clearance for airflow, and position the antenna at least 1 m away from metal surfaces to avoid signal degradation.
Maintenance Recommendations:
- Routine Checks: Monthly visual inspections of the antenna connections and front-panel LEDs (green for normal operation, red for faults) to ensure stable communication.
- Signal Optimization: Annually assess RF signal strength using GE’s diagnostic tools, adjusting antenna placement or power settings to maintain optimal performance, especially in dynamic environments where obstacles may change.
- Firmware Updates: Periodically update the module’s firmware via VersaPro to address security patches or enhance compatibility with newer PLC firmware versions.
- Environmental Cleaning: Quarterly cleaning of the module’s vents and antenna connectors to prevent dust or debris from affecting heat dissipation or signal quality.
Product Warranty
Our company provides a one-year quality warranty for the GE IC690RFH008, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits abnormal communication performance or physical defects. For discontinued models like the GE IC690RFH008, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. Additionally, we offer post-warranty technical support and repair services through our network of certified technicians, ensuring your wireless automation systems remain operational and reliable over the long term.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on technical data from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE IC690RFH008 user manual or contact our technical support team for personalized assistance.
