GE IC670PBI001 Power Input Module
Product Overview
The GE IC670PBI001 is a high-reliability Power Input Module designed as a critical component of GE’s 90-70 Series PLC platform, catering to industrial automation systems that demand robust power management and signal conditioning. Engineered to convert incoming AC power to regulated DC voltage for PLC components, this module ensures stable power delivery while integrating advanced diagnostic features to monitor power quality and system health. As part of the IC670 Series, the IC670PBI001 offers seamless integration with other 90-70 Series modules, such as CPU units and I/O cards, enabling scalable control solutions for manufacturing, power generation, and process industries.
Featuring a rugged industrial design, the GE IC670PBI001 supports a wide input voltage range (85–264 V AC) and converts it to a stable 24 V DC output, capable of delivering up to 3 A of current. Its active power factor correction (PFC) ensures efficient power usage, while built-in surge protection safeguards against voltage spikes, extending the module’s lifespan in harsh environments. The module’s LED indicators provide real-time feedback on power status, fault conditions, and voltage regulation, simplifying troubleshooting and maintenance. With an operating temperature range of -40°C to +70°C and compliance with industry standards like IEC 61131-2, the IC670PBI001 is ideal for applications requiring continuous operation in challenging settings, such as offshore platforms, refineries, and heavy machinery installations.
In automation ecosystems, the IC670PBI001 acts as the power backbone for the 90-70 Series PLC, ensuring uninterrupted operation of control logic and field devices. Its hot-swappable design allows for module replacement without powering down the system, minimizing downtime during maintenance. By combining reliable power conversion with advanced diagnostic capabilities, this module enhances system efficiency and reduces overall cost of ownership, making it a cornerstone of robust industrial control strategies.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC670PBI001 |
| Manufacturer | GE |
| Product Type | Power Input Module |
| Platform | 90-70 Series PLC |
| Input Voltage | 85–264 V AC, 50/60 Hz |
| Output Voltage | 24 V DC ±0.5% |
| Output Current | 3 A continuous |
| Power Factor | 0.95+ at full load |
| Efficiency | Up to 89% |
| Physical Dimensions | 177.8 mm (H) × 101.6 mm (W) × 127 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, cUL |
Key Features and Advantages
Wide Voltage Compatibility: The IC670PBI001 supports a broad input voltage range (85–264 V AC), eliminating the need for region-specific power adapters and simplifying global deployments. This flexibility reduces hardware complexity and installation costs for multinational industrial setups.
High-Efficiency Power Conversion: With up to 89% efficiency and active PFC, the module minimizes energy waste and heat generation, contributing to lower operational costs and a smaller carbon footprint. Its regulated 24 V DC output ensures stable power for sensitive PLC components.
Robust Surge Protection: Built-in transient voltage suppression (TVS) diodes and overcurrent protection circuits safeguard the module and connected devices from voltage spikes and overloads, enhancing system reliability in environments with unstable power supplies.
Real-Time Diagnostics: LED indicators for power status, voltage regulation, and fault conditions provide instant visual feedback, while the module’s internal diagnostics monitor input voltage, output current, and temperature. This proactive monitoring reduces troubleshooting time and enables predictive maintenance.
Hot-Swap Capability: The module can be replaced while the PLC system remains operational, allowing maintenance without interrupting critical processes. This feature is invaluable for 24/7 industrial operations where downtime translates to lost productivity.
Compact and Rugged Design: With dimensions of 177.8 mm × 101.6 mm × 127 mm, the IC670PBI001 optimizes space in control panels, while its rugged metal enclosure and conformal-coated circuitry withstand extreme temperatures, vibration, and humidity.
Application Areas
The GE IC670PBI001 is widely deployed in industries requiring reliable power management for PLC systems:
- Manufacturing: Powers PLCs in automotive assembly lines, food processing plants, and pharmaceutical facilities, ensuring consistent operation of robotic arms, conveyor belts, and packaging machinery.
- Power Generation: Supports PLCs in thermal, hydro, and renewable energy plants, managing auxiliary systems such as cooling fans, lubrication pumps, and generator control units.
- Oil & Gas: Operates in offshore platforms, refineries, and pipeline compression stations, providing stable power for PLCs that control valves, compressors, and safety interlocks.
- Water/Wastewater Treatment: Powers PLCs that manage pump stations, filtration systems, and chemical dosing equipment in water treatment plants, ensuring regulatory compliance and efficient operations.
- Material Handling: Drives PLCs in automated warehouses and logistics centers, controlling hoists, cranes, and sorting systems to optimize throughput.
Specific applications include:
- Redundant Power Systems: Used in parallel with other IC670PBI001 modules for redundant power configurations, enhancing system availability in mission-critical setups.
- Remote Industrial Sites: Deployed in remote locations with unstable grid power, leveraging its wide input range and surge protection to maintain PLC operation.
- Harsh Environment Control: Installed in environments with high vibration or temperature fluctuations, such as mining equipment or heavy machinery, where reliable power is essential.
Related Products
- IC670PWR001 Power Supply Module: A higher-current variant (5 A) of the IC670PBI001, suitable for large PLC systems with high power demands.
- IC670CPU780 CPU Module: High-performance processor for 90-70 Series PLCs, compatible with the IC670PBI001 for seamless power and control integration.
- IC670MDL740 Digital Input Module: Works in tandem with the IC670PBI001, providing discrete signal acquisition for PLC systems.
- IC670ALG222 Analog Input Module: Complements the IC670PBI001 by enabling analog data acquisition for mixed-signal control applications.
- IC670ACC001 Communication Module: Enables Ethernet connectivity for the 90-70 Series, allowing remote monitoring of the IC670PBI001 via SCADA systems.
- IC670CBL001 Rack Cable: Connects the IC670PBI001 to other modules in the PLC rack, ensuring reliable power and data transmission.
- IC670TBD024 Transistor Output Module: An output module that pairs with the IC670PBI001 to drive field actuators, forming a complete control solution.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IC670PBI001, ensure the PLC rack is properly grounded and ventilated. Verify that the input voltage (85–264 V AC) matches the local power supply, and use shielded cables for power connections to minimize electromagnetic interference. Mount the module on a DIN rail or panel using the provided hardware, leaving sufficient space for heat dissipation. Connect the output terminals to the PLC’s power bus, ensuring correct polarity, and configure any optional redundant power settings in the system’s hardware configuration tool.
Before installing the GE IC670PBI001, ensure the PLC rack is properly grounded and ventilated. Verify that the input voltage (85–264 V AC) matches the local power supply, and use shielded cables for power connections to minimize electromagnetic interference. Mount the module on a DIN rail or panel using the provided hardware, leaving sufficient space for heat dissipation. Connect the output terminals to the PLC’s power bus, ensuring correct polarity, and configure any optional redundant power settings in the system’s hardware configuration tool.
Maintenance Suggestions:
- Routine Inspections: Perform monthly checks to verify LED indicators (power on, voltage OK) and ensure all connections are secure. Use the PLC’s diagnostic software to monitor output voltage and current levels for any deviations from normal parameters.
- Cleaning and Cooling: Quarterly, clean the module’s vents and enclosure to prevent dust accumulation, which can lead to overheating. Ensure the control panel’s cooling fans are functioning properly to maintain optimal operating temperatures.
- Component Testing: Annually, test the module’s output voltage stability under varying loads using a multimeter. Replace the module if voltage regulation falls outside the ±0.5% tolerance range to prevent damage to connected components.
- Firmware Updates: Periodically update the PLC’s firmware to ensure compatibility with the IC670PBI001, following GE’s recommended procedures to avoid system disruptions.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IC670PBI001, covering hardware defects under normal use. In the event of power output inconsistencies or module failures, we offer prompt replacement services to minimize downtime. For legacy or discontinued models like the IC670PBI001, our global supply chain network specializes in sourcing rare industrial control components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, troubleshooting, and power system optimization, delivering reliable solutions to maintain your PLC’s operational integrity.
