GE IC670MDL930 Digital Input Module
Product Overview: GE IC670MDL930
The GE IC670MDL930 digital input module is a high-reliability industrial automation component designed for GE’s 90-70 Series PLC system. As a critical part of this advanced control platform, the IC670MDL930 serves as a bridge between field devices and the PLC, converting physical switch states into digital signals for processing. Engineered to withstand harsh industrial environments, this module combines robust hardware with flexible configuration to ensure precise and reliable operation in mission-critical applications.
Featuring 16 isolated digital input channels, the IC670MDL930 supports both AC and DC input signals (24–240V), making it compatible with a wide range of sensors, switches, and limit devices. Its 光电隔离 (opto-isolation) technology protects the PLC from electrical noise and transient spikes, enhancing system stability. The module’s screw-terminal connections and hot-swappable design allow for easy installation and maintenance without disrupting system operation, while its LED status indicators provide real-time feedback on input states.
Within automation systems, the IC670MDL930 plays a pivotal role in monitoring machine status, process conditions, and safety interlocks. Its compatibility with GE’s 90-70 Series racks (e.g., IC670CHS721) and compliance with UL 508, CSA C22.2 standards make it a trusted choice for industries requiring reliable data acquisition. By integrating seamlessly with GE’s PLC ecosystem, this module enables real-time control and monitoring, optimizing productivity and reducing downtime.
Technical Specifications: GE IC670MDL930
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC670MDL930 |
| Manufacturer | GE |
| Product Type | Digital Input Module |
| Input Channels | 16 channels (isolated) |
| Input Voltage | 24–240V AC/DC |
| Input Current | 10 mA (per channel) |
| Isolation | Opto-isolation (2500V rms) |
| Physical Dimensions | 101.6 mm (H) × 152.4 mm (W) × 76.2 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (GE 90-70 Series) |
| Country of Origin | United States |
Main Features and Advantages: GE IC670MDL930
Wide-Range Input Compatibility: The IC670MDL930 supports a broad voltage range (24–240V AC/DC), eliminating the need for multiple modules to accommodate different field devices. This versatility simplifies inventory management and reduces installation complexity.
Robust Electrical Isolation: With 2500V rms opto-isolation per channel, the module protects the PLC from electrical interference, ground loops, and voltage spikes. This feature is critical in noisy industrial environments, such as manufacturing plants or power stations.
Hot-Swappable Design: The module’s hot-swappable capability allows replacement while the system is running, minimizing downtime during maintenance or component failure. This is essential for continuous processes where production interruptions are costly.
Real-Time Status Monitoring: Built-in LED indicators for each channel provide instant visibility into input states, enabling quick troubleshooting and reducing diagnostic time. This feature enhances operational efficiency by allowing operators to identify issues without specialized tools.
Industrial-Grade Durability: Designed to withstand harsh conditions, the IC670MDL930 operates reliably from 0°C to +60°C and resists humidity, vibration, and electromagnetic interference. Its rugged construction ensures long-term performance in challenging environments.
Application Areas: GE IC670MDL930
The GE IC670MDL930 digital input module is widely used in industries that require reliable monitoring of digital signals:
- Manufacturing: Monitors limit switches, proximity sensors, and safety interlocks in automotive assembly lines, robotic cells, and packaging machinery, ensuring precise control and safety.
- Power Generation: Tracks the status of circuit breakers, valves, and relays in power plants, supporting real-time monitoring of generator control systems and grid infrastructure.
- Oil and Gas: Deployed in refineries and offshore platforms to monitor flow switches, pressure sensors, and emergency shutdown (ESD) signals, enhancing safety and process efficiency.
- Water Treatment: Manages input signals from level sensors, flow meters, and control valves in water/wastewater plants, ensuring continuous operation and regulatory compliance.
- Aerospace and Defense: Used in ground support equipment and military automation systems to monitor equipment status and safety protocols, where reliable data acquisition is non-negotiable.
Related Products: GE IC670MDL930
- GE IC670MDL940 Digital Output Module: Complements the IC670MDL930 by providing digital output channels for controlling actuators and relays in the same PLC system.
- GE IC670CHS721 Rack Chassis: Houses the IC670MDL930 and other 90-70 Series modules, providing mechanical support and power distribution.
- GE IC670ALG222 Analog Input Module: Expands the system’s capabilities by adding analog signal processing alongside the IC670MDL930’s digital inputs.
- GE IC670PWR711 Power Supply Module: Provides reliable power to the rack housing the IC670MDL930, ensuring stable operation.
- GE IC670CPU780 Processor Module: The central processing unit for the 90-70 Series, integrating with the IC670MDL930 to execute control logic.
- GE IC670CMM731 Communication Module: Enables Ethernet/IP communication for the IC670MDL930, facilitating remote monitoring and data integration.
Installation and Maintenance: GE IC670MDL930
Pre-installation Preparations:
Before installing the IC670MDL930, ensure the GE 90-70 Series rack is properly grounded and powered off. Verify that the input voltage of field devices matches the module’s specifications (24–240V AC/DC). Clean the rack slot and insert the module into the designated position, securing it with the provided brackets. Connect field wires to the screw terminals, following the wiring diagram in the user manual, and ensure proper strain relief for cables.
Before installing the IC670MDL930, ensure the GE 90-70 Series rack is properly grounded and powered off. Verify that the input voltage of field devices matches the module’s specifications (24–240V AC/DC). Clean the rack slot and insert the module into the designated position, securing it with the provided brackets. Connect field wires to the screw terminals, following the wiring diagram in the user manual, and ensure proper strain relief for cables.
Maintenance Recommendations:
- Routine Inspections: Monthly checks should include verifying LED indicators, tightening cable connections, and cleaning the module’s surface to prevent dust accumulation.
- Functional Testing: Quarterly testing of input channels using a known signal source ensures each channel responds correctly. Replace any faulty channels promptly to maintain system reliability.
- Environmental Monitoring: Monitor ambient temperature and humidity to ensure they stay within the module’s operating range. Install additional cooling if necessary for high-temperature environments.
- Spare Parts Management: Keep a spare IC670MDL930 on hand for rapid replacement, leveraging our global supply chain to minimize downtime in case of failure.
Product Guarantee: GE IC670MDL930
Our company provides a 12-month quality warranty for the GE IC670MDL930 digital input module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with faulty inputs, isolation failures, or physical damage at no cost. For discontinued models or urgent needs, our extensive inventory and global logistics network ensure prompt fulfillment, supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable solutions and exceptional service. The IC670MDL930 exemplifies our dedication to quality, offering the durability and performance required for critical automation systems. Contact us today to optimize your data acquisition with this robust module.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for GE’s official technical documentation.
