GE IC670CHS101 Communication Processor Module

Product Overview

The GE IC670CHS101 is a high-performance Communication Processor Module designed for industrial automation systems, serving as a critical component of GE’s 90-70 Series PLC platform. Engineered to facilitate seamless data exchange between programmable logic controllers (PLCs) and various field devices, this module supports multiple communication protocols, enabling real-time monitoring and control in complex industrial environments. As part of the IC670 Series, the IC670CHS101 ensures compatibility with other 90-70 Series components, such as CPU modules and I/O interfaces, making it an essential asset for industries requiring reliable network integration and data transmission.

The GE IC670CHS101 features dual communication ports—typically including Ethernet and serial interfaces (RS-232/485)—to support diverse networking configurations. It enables protocol conversion between industrial standards like Modbus, DF1, and Ethernet/IP, allowing legacy systems to integrate with modern SCADA networks. The module’s robust design includes error-checking mechanisms and redundant power paths, ensuring continuous operation even in the face of transient faults. With a wide operating temperature range (-40°C to +70°C) and compliance with industrial standards (e.g., IEC 61131-2), the IC670CHS101 is suitable for harsh environments, such as offshore platforms, refineries, and heavy manufacturing facilities.

In automation ecosystems, the IC670CHS101 acts as a bridge between the PLC and higher-level control systems, enabling remote diagnostics, programming, and data logging. Its hot-swappable design allows for module replacement without system shutdown, minimizing downtime during maintenance. By combining high-speed data processing with advanced network management, this module enhances system efficiency and reduces the total cost of ownership, making it a cornerstone of reliable industrial communication strategies.

Technical Specifications

Parameter Name	Parameter Value
Product Model	IC670CHS101
Manufacturer	GE
Product Type	Communication Processor Module
Platform	90-70 Series PLC
Communication Ports	1x Ethernet (10/100 Mbps), 1x RS-232/485
Supported Protocols	Modbus RTU/TCP, DF1, Ethernet/IP, Profibus DP (with adapter)
Input Voltage	24 V DC ±10%
Data Transfer Rate	Up to 100 Mbps (Ethernet), 115.2 kbps (serial)
Physical Dimensions	177.8 mm (H) × 101.6 mm (W) × 127 mm (D)
Weight	1.2 kg
Operating Temperature	-40°C to +70°C
Mounting	DIN rail or panel-mounted
Certifications	CE, UL, cUL

Key Features and Advantages

Multi-Protocol Connectivity: The IC670CHS101 supports a wide range of industrial communication protocols, eliminating the need for multiple dedicated modules. This versatility simplifies system design and reduces hardware costs, making it ideal for mixed-protocol environments.

Redundant Design for Reliability: With dual communication ports and redundant power inputs, the module ensures continuous operation even if one port or power source fails. This redundancy is critical for mission-critical applications where network downtime is not an option.

High-Speed Data Processing: The module’s advanced processor enables real-time data translation and forwarding, minimizing latency in control loops. This speed is essential for applications requiring rapid response, such as remote equipment monitoring or emergency shutdown systems.

Hot-Swap Capability: Designed for easy maintenance, the IC670CHS101 can be replaced while the PLC is running, allowing scheduled maintenance without interrupting operations. This feature is particularly valuable in 24/7 industrial settings.

Wide Environmental Tolerance: The module’s rugged construction and wide temperature range make it suitable for harsh industrial environments. It withstands vibration, humidity, and electromagnetic interference, ensuring reliable performance in challenging locations.

Seamless System Integration: Compatible with GE’s 90-70 Series programming tools (e.g., Cimplicity), the IC670CHS101 simplifies network configuration and management. It supports remote firmware updates, enabling easy adoption of new features and security patches.

Application Areas

The GE IC670CHS101 is widely deployed in industries requiring robust and flexible communication solutions:

Power Generation: Connects turbines, generators, and auxiliary systems to SCADA networks, enabling real-time monitoring of power output and equipment health.
Oil & Gas: Facilitates data exchange between pipeline sensors, compressors, and control rooms, supporting remote operation and predictive maintenance in upstream and downstream facilities.
Manufacturing: Integrates production lines, robotic systems, and quality control devices into a unified network, enabling centralized process optimization and performance tracking.
Water/Wastewater Treatment: Links pumps, valves, and treatment tanks to control centers, ensuring efficient water distribution and compliance with environmental regulations.
Mining: Connects heavy machinery, conveyor systems, and safety sensors in underground and surface mines, enhancing operational safety and productivity.

Specific applications include:

Remote Monitoring Systems: Transmits real-time data from field devices to central control rooms, allowing operators to make informed decisions without physical presence.
Protocol Conversion: Bridges legacy equipment (e.g., older PLCs) with modern Ethernet-based networks, extending the lifespan of existing infrastructure.
Distributed Control Systems (DCS): Integrates localized control panels with plant-wide DCS, enabling seamless data aggregation and analysis.

Installation and Maintenance

Pre-installation Preparations:
Before installing the GE IC670CHS101, ensure the 90-70 Series rack is properly grounded and powered. Verify that the module’s communication ports match the network requirements (e.g., Ethernet or serial) and use shielded cables to minimize electromagnetic interference. Mount the module on a DIN rail or panel, leaving adequate space for heat dissipation. Configure the module using GE’s Cimplicity software, setting up network addresses, protocol parameters, and data mapping rules.

Maintenance Suggestions:

Routine Inspections: Monthly, check the module’s LED indicators to verify network connectivity and power status. Use diagnostic tools to monitor data transmission rates and error counts, addressing any anomalies promptly.
Cleaning and Cooling: Quarterly, remove dust from the module’s vents to prevent overheating. Ensure the control panel’s environmental conditions (temperature, humidity) fall within the specified range.
Firmware Updates: Periodically update the module’s firmware to incorporate bug fixes and new protocol support, following GE’s recommended procedures to avoid configuration loss.
Redundancy Testing: Annually, simulate port or power failures to verify the module’s failover capabilities, ensuring continuous operation during unexpected events.

Product Guarantee

Our company provides a 12-month quality warranty for the GE IC670CHS101, covering hardware defects under normal use. In the event of performance issues, such as network connectivity failures or protocol errors, we offer prompt replacement services to minimize downtime. For legacy or discontinued models like the IC670CHS101, our global supply chain network specializes in sourcing rare industrial components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, delivering reliable solutions to maintain your communication infrastructure’s integrity.

For sales inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
