GE IC670ALG310 Analog Input Module
Product Overview
The GE IC670ALG310 is a high-precision Analog Input Module designed as a critical component of GE’s 90-70 Series PLC platform, catering to advanced industrial automation and process control applications. Engineered to convert continuous analog signals from field instruments (e.g., pressure transducers, temperature transmitters, flow meters) into digital data for processing by the PLC, this module ensures accurate and reliable data acquisition in harsh industrial environments. As part of the IC670 Series, the IC670ALG310 offers seamless integration with other 90-70 Series components, such as CPU modules and digital I/O modules, enabling robust and scalable control solutions for power generation, oil & gas, and manufacturing sectors.
Featuring a rugged industrial design, the GE IC670ALG310 supports 8 isolated analog input channels, each configurable to accept multiple signal types including 4–20 mA current loops, 0–10 V DC voltage inputs, and resistance temperature detector (RTD) signals. Its 16-bit resolution and ±0.1% full-scale accuracy ensure precise measurement of process variables, while advanced signal conditioning circuitry with anti-aliasing filters and galvanic isolation minimizes noise interference. The module’s LED indicators provide real-time status feedback for each channel, simplifying troubleshooting and maintenance. With a wide operating temperature range (-40°C to +70°C) and compliance with industry standards like IEC 61131-2, the IC670ALG310 is ideal for mission-critical applications requiring continuous operation in challenging environments, such as offshore platforms, refineries, and heavy manufacturing facilities.
In automation ecosystems, the IC670ALG310 serves as the interface between analog field devices and the PLC, facilitating real-time data flow for process optimization and control. Its hot-swappable design allows for module replacement without powering down the system, minimizing downtime during maintenance. By combining high-density input channels with advanced diagnostic capabilities, this module enhances system efficiency and reduces overall cost of ownership, making it a cornerstone of reliable industrial control strategies.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC670ALG310 |
| Manufacturer | GE |
| Product Type | Analog Input Module |
| Platform | 90-70 Series PLC |
| Input Channels | 8 isolated channels |
| Signal Types | 4–20 mA, 0–10 V DC, 0–5 V DC, RTD (Pt100, Ni100), thermocouples (J, K, T types) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | 500 V RMS between channels and ground |
| Power Supply | 24 V DC ±10% (from PLC rack) |
| Physical Dimensions | 177.8 mm (H) × 101.6 mm (W) × 127 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, cUL |
Key Features and Advantages
Multi-Signal Compatibility: The IC670ALG310 accommodates a diverse range of analog signals, eliminating the need for dedicated modules for different sensor types. This versatility reduces hardware complexity and lowers installation costs, making it suitable for mixed-signal industrial setups where multiple process variables need monitoring.
High Precision and Noise Immunity: With 16-bit resolution and advanced filtering, the module delivers highly accurate measurements even in high-noise environments affected by electromagnetic interference (EMI) from motors or power lines. Galvanic isolation between channels prevents ground loops, ensuring signal integrity and measurement reliability.
Real-Time Diagnostics: Built-in diagnostic features continuously monitor each channel for signal loss, overrange conditions, and module health. LED indicators provide instant visual feedback on channel status, while the module’s diagnostic interface within GE’s programming software enables detailed fault tracking, reducing troubleshooting time and enhancing system availability.
Hot-Swap Capability: Designed for maintenance flexibility, the IC670ALG310 can be replaced while the PLC is running, allowing for scheduled maintenance without interrupting operations. This feature is critical for 24/7 industrial processes where downtime translates to lost productivity and increased costs.
Robust Environmental Tolerance: The module’s rugged enclosure and conformal-coated circuitry protect against dust, moisture, and corrosive elements, ensuring reliable performance in harsh environments. Its ability to withstand extreme temperatures and vibration makes it suitable for both indoor and outdoor installations.
Seamless System Integration: Compatible with GE’s 90-70 Series PLCs and programming tools (e.g., Cimplicity), the IC670ALG310 simplifies system configuration and integration. It supports daisy-chaining with other IC670 modules, enabling scalable solutions for small to large-scale control systems.
Application Areas
The GE IC670ALG310 is widely deployed in industries requiring precise analog data acquisition and process control:
- Power Generation: Monitors temperature, pressure, and flow rates in steam turbines, gas generators, and boiler systems, enabling real-time adjustments to optimize fuel efficiency and prevent overloading. It supports critical applications like turbine blade temperature monitoring and condenser vacuum pressure control.
- Oil & Gas: Facilitates process control in upstream wellheads, midstream pipelines, and downstream refineries by measuring parameters such as pressure, flow, and temperature. It supports safety systems by feeding analog data into emergency shutdown (ESD) systems.
- Manufacturing: Used in automotive, chemical, and food processing plants to monitor conveyor speeds, mixing ratios, and environmental conditions (e.g., humidity, temperature), ensuring consistent product quality and compliance with regulatory standards.
- Water/Wastewater Treatment: Measures parameters like pH, conductivity, and liquid level in treatment facilities, enabling automated control of pumps, valves, and filtration systems to maintain water quality and flow efficiency.
- Mining and Metals: Monitors process variables in mineral extraction and refining, such as slurry density, furnace temperature, and conveyor load, optimizing production efficiency and equipment health.
Specific applications include:
- Turbine Health Monitoring: Integrates with RTDs and thermocouples to track rotor and stator temperatures in generators, providing early warnings of overheating.
- Process Optimization: Uses 4–20 mA signals from flow meters and pressure transmitters to adjust control valves, maintaining optimal process conditions and reducing energy consumption.
- Safety System Integration: Feeds analog data into safety instrumented systems (SIS) to trigger alarms or shutdowns when process variables exceed thresholds, ensuring compliance with IEC 61511 standards.
Related Products
- IC670ALG222 Analog Input Module: A 16-channel variant of the IC670ALG310, offering higher input density for large-scale process control applications.
- IC670ALG320 Analog Input Module: Supports thermocouple inputs with enhanced noise immunity, ideal for high-temperature monitoring in furnaces and boilers.
- IC670ALG440 High-Speed Analog Input Module: Designed for rapid data acquisition in dynamic systems, such as rotating machinery vibration analysis.
- IC670CPU780 CPU Module: High-performance processor for 90-70 Series PLCs, coordinating control logic for the IC670ALG310 and other I/O modules.
- IC670ACC700 Communication Module: Enables Ethernet connectivity for the IC670ALG310, supporting remote monitoring via SCADA systems or cloud platforms.
- IC670BBD100 Power Supply Module: Provides redundant 24 V DC power for 90-70 Series racks, ensuring uninterrupted operation of the IC670ALG310.
- IC670ALG330 RTD Input Module: Specialized for resistance temperature detection, complementing the IC670ALG310 in temperature-intensive applications.
- IC670CBL701 Rack Cable: Connects the IC670ALG310 to the CPU module, ensuring reliable data transmission within the PLC rack.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IC670ALG310, ensure the 90-70 Series rack is properly grounded and powered. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA for transmitters, RTD for temperature sensors). Use shielded cables to connect field devices to the module’s terminal blocks, routing cables separately from high-voltage lines to avoid EMI. Mount the module on a DIN rail or panel using the provided hardware, leaving sufficient space for heat dissipation. Configure the module in GE’s Cimplicity software, assigning channel addresses and enabling appropriate signal conditioning parameters (e.g., filter constants, linearization tables).
Before installing the GE IC670ALG310, ensure the 90-70 Series rack is properly grounded and powered. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA for transmitters, RTD for temperature sensors). Use shielded cables to connect field devices to the module’s terminal blocks, routing cables separately from high-voltage lines to avoid EMI. Mount the module on a DIN rail or panel using the provided hardware, leaving sufficient space for heat dissipation. Configure the module in GE’s Cimplicity software, assigning channel addresses and enabling appropriate signal conditioning parameters (e.g., filter constants, linearization tables).
Maintenance Suggestions:
- Routine Inspections: Perform monthly checks to ensure all terminal connections are secure and LED status indicators show normal operation. Use Cimplicity to review channel diagnostics and identify any signals outside expected ranges.
- Calibration: Annually calibrate the module using a precision signal source to verify accuracy. Compare measured values against the source output, adjusting offsets or gains as needed, and document results for compliance.
- Firmware Updates: Periodically update the PLC’s firmware to incorporate bug fixes and compatibility improvements, following GE’s recommended procedures to avoid system disruptions.
- Environmental Maintenance: Quarterly, clean the module’s vents and enclosure to prevent dust accumulation, which can lead to overheating. Ensure the control panel’s ventilation system is functioning properly to maintain optimal operating temperatures.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IC670ALG310, covering hardware defects under normal use. In the event of performance issues—such as signal inaccuracies, channel failures, or diagnostic errors—we offer prompt replacement services to minimize downtime. For legacy or discontinued models like the IC670ALG310, our global supply chain network specializes in sourcing rare industrial control components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, calibration, and troubleshooting, delivering reliable solutions to keep your automation systems operating at peak performance.
