GE IC670ALG310 Analog Input Module
Product Overview
The GE IC670ALG310 is a high-precision Analog Input Module designed for industrial automation systems, serving as a key component of GE’s 90-70 Series PLC platform. Engineered to convert continuous analog signals from field instruments (e.g., temperature transmitters, pressure transducers) into digital data for processing by the PLC, this module ensures accurate and reliable data acquisition in harsh industrial environments. As part of the IC670 Series, the IC670ALG310 offers seamless integration with other 90-70 Series components, such as CPU modules and digital I/O modules, enabling robust control solutions for power generation, oil & gas, and manufacturing industries.
Featuring a rugged industrial design, the GE IC670ALG310 supports 8 isolated analog input channels, each configurable to accept multiple signal types including 4–20 mA current loops, 0–10 V DC voltage inputs, and resistance temperature detector (RTD) signals. Its advanced signal conditioning circuitry includes anti-aliasing filters and galvanic isolation (250 V RMS), minimizing noise interference and ensuring measurement accuracy within ±0.1% of full scale. The module’s LED indicators provide real-time status feedback for each channel, simplifying troubleshooting and maintenance. With a wide operating temperature range (-40°C to +70°C) and compliance with industry standards like IEC 61131-2, the IC670ALG310 is ideal for applications requiring continuous operation in challenging environments, such as offshore platforms, refineries, and heavy manufacturing facilities.
In automation ecosystems, the IC670ALG310 acts as the interface between analog field devices and the PLC, translating real-world process variables into digital commands for control logic. Its hot-swappable design allows for module replacement without powering down the system, minimizing downtime during maintenance. By combining high-density input channels with advanced diagnostic capabilities, this module enhances system efficiency and reduces overall cost of ownership, making it a cornerstone of reliable industrial control strategies.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC670ALG310 |
| Manufacturer | GE |
| Product Type | Analog Input Module |
| Platform | 90-70 Series PLC |
| Input Channels | 8 isolated channels |
| Signal Types | 4–20 mA, 0–10 V DC, RTD (Pt100, Ni100), thermocouples (J, K, T types) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | 250 V RMS between channels and ground |
| Power Supply | 24 V DC ±10% (from PLC rack) |
| Physical Dimensions | 177.8 mm (H) × 101.6 mm (W) × 127 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, cUL |
Key Features and Advantages
Multi-Signal Compatibility: The IC670ALG310 accommodates a wide range of analog signals, eliminating the need for dedicated modules for different sensor types. This versatility reduces hardware complexity and lowers installation costs, making it suitable for mixed-signal industrial setups.
High Precision and Noise Immunity: With 16-bit resolution and advanced filtering, the module delivers highly accurate measurements even in high-noise environments, such as those with electromagnetic interference (EMI) from motors or power lines. Galvanic isolation between channels prevents ground loops and ensures signal integrity.
Real-Time Diagnostics: Built-in diagnostic features monitor input signal quality, power supply stability, and module health. LED indicators and digital feedback enable quick fault identification, reducing troubleshooting time and enhancing system availability.
Hot-Swap Capability: The module can be replaced while the PLC is running, allowing maintenance without interrupting operations. This feature is critical for 24/7 industrial processes where downtime translates to lost productivity.
Rugged Industrial Design: Designed to withstand extreme temperatures, vibration, and humidity, the IC670ALG310 ensures reliable performance in harsh environments. Its rugged enclosure and conformal-coated circuitry protect against dust, moisture, and corrosive elements.
Seamless System Integration: Compatible with GE’s 90-70 Series PLCs and programming software (e.g., Cimplicity), the module simplifies system configuration and integration. It supports daisy-chaining with other IC670 modules, enabling scalable solutions for small to large control systems.
Application Areas
The GE IC670ALG310 is widely deployed in industries requiring precise analog data acquisition and control:
- Power Generation: Monitors temperature, pressure, and flow rates in steam turbines, gas generators, and boiler systems, enabling real-time adjustments to optimize fuel efficiency and prevent overloading.
- Oil & Gas: Supports process control in upstream production (e.g., wellhead pressure monitoring), midstream pipelines (e.g., flow rate validation), and downstream refineries (e.g., distillation column optimization).
- Manufacturing: Used in automotive, chemical, and food processing plants to monitor conveyor speeds, mixing ratios, and environmental conditions, ensuring consistent product quality and regulatory compliance.
- Water/Wastewater Treatment: Measures parameters such as pH, conductivity, and liquid level in treatment facilities, enabling automated control of pumps, valves, and filtration systems.
- Mining: Monitors pressure and temperature in crushing and milling equipment, supporting safe and efficient mineral extraction operations.
Specific applications include:
- Turbine Health Monitoring: Integrates with RTDs and thermocouples to track rotor and stator temperatures in generators, providing early warnings of overheating.
- Process Optimization: Uses 4–20 mA signals from flow meters and pressure transmitters to adjust control valves and maintain optimal process conditions, reducing energy consumption.
- Safety Systems: Feeds analog data into safety instrumented systems (SIS) to trigger alarms or shutdowns when process variables exceed thresholds, ensuring compliance with safety standards.
Related Products
- IC670ALG222 Analog Input Module: A 16-channel variant of the IC670ALG310, offering higher input density for large-scale control applications.
- IC670ALG320 Analog Input Module: Supports thermocouple inputs with enhanced noise rejection, ideal for high-temperature monitoring in furnace applications.
- IC670BBD010 Power Supply Module: Provides redundant 24 V DC power for 90-70 Series racks, ensuring uninterrupted operation of the IC670ALG310.
- IC670CPU780 CPU Module: High-performance processor for 90-70 Series PLCs, coordinating control logic for the IC670ALG310 and other I/O modules.
- IC670ACC700 Communication Module: Enables Ethernet connectivity for the IC670ALG310, supporting remote monitoring via SCADA systems.
- IC670TBD024 Transistor Output Module: Complements the IC670ALG310 by providing digital output channels for actuator control in closed-loop systems.
- IC670CBL001 Rack Cable: Connects the IC670ALG310 to the CPU module, ensuring reliable data transmission within the PLC rack.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IC670ALG310, ensure the 90-70 Series rack is properly grounded and powered. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA for transmitters, RTD for temperature sensors). Use shielded cables to connect field devices to the module’s terminal blocks, routing cables separately from high-voltage lines to avoid EMI. Mount the module on a DIN rail or panel using the provided hardware, ensuring adequate spacing for heat dissipation. Configure the module in GE’s Cimplicity software, assigning channel addresses and enabling appropriate signal conditioning parameters.
Before installing the GE IC670ALG310, ensure the 90-70 Series rack is properly grounded and powered. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA for transmitters, RTD for temperature sensors). Use shielded cables to connect field devices to the module’s terminal blocks, routing cables separately from high-voltage lines to avoid EMI. Mount the module on a DIN rail or panel using the provided hardware, ensuring adequate spacing for heat dissipation. Configure the module in GE’s Cimplicity software, assigning channel addresses and enabling appropriate signal conditioning parameters.
Maintenance Suggestions:
- Routine Inspections: Perform monthly checks to verify LED status indicators and ensure all connections are secure. Use Cimplicity to review channel diagnostics for any signals outside expected ranges.
- Calibration: Annually calibrate the module using a precision signal source to verify accuracy. Compare measured values against the source output, adjusting offsets or gains as needed, and document results for compliance.
- Cleaning and Cooling: Quarterly, clean the module’s vents and enclosure to prevent dust accumulation, which can lead to overheating. Ensure the control panel’s ventilation system is functioning properly.
- Firmware Updates: Periodically update the PLC’s firmware to incorporate bug fixes and compatibility improvements, following GE’s recommended procedures to avoid configuration errors.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IC670ALG310, covering hardware defects under normal use. In the event of performance issues, such as signal inaccuracies or module failures, we offer prompt replacement services to minimize downtime. For legacy or discontinued models like the IC670ALG310, our global supply chain network specializes in sourcing rare industrial control components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, calibration, and troubleshooting, delivering reliable solutions to maintain your control system’s integrity.
For sales inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
