GE IC660TSA100 Product Specification
Product Overview
The GE IC660TSA100 is a high-performance temperature sensor amplifier module designed for industrial automation systems, specifically as part of GE’s Series 6000 Programmable Logic Controller (PLC) platform. Engineered to provide precise signal conditioning and amplification for temperature sensor inputs, the GE IC660TSA100 plays a critical role in maintaining process accuracy across industries such as power generation, oil and gas, and manufacturing. This module integrates advanced analog signal processing with rugged industrial design, ensuring reliable operation in harsh environments where temperature measurement precision is non-negotiable.
As a key component of the Series 6000 family, the GE IC660TSA100 supports up to 8 channels of temperature sensor inputs, enabling real-time amplification and conditioning of signals from RTDs, thermocouples, and other temperature transducers. It features a 16-bit analog-to-digital converter (ADC) for high-resolution signal processing and supports input ranges from -10 to +10 VDC or 4–20 mA, ensuring compatibility with a wide array of field sensors. The module’s compact form factor (100 mm × 150 mm × 75 mm) and lightweight design (0.8 kg) facilitate easy integration into control panels, while its 24 VDC power supply and wide operating temperature range (-40°C to +70°C) make it suitable for demanding industrial applications.
In automation systems, the GE IC660TSA100 acts as a bridge between temperature sensors and the PLC, enhancing measurement reliability by amplifying weak sensor signals and filtering out electrical noise. Its built-in self-diagnostic functions monitor channel health and alert operators to potential failures, minimizing downtime and improving system availability. By combining precise signal conditioning with robust connectivity via GE’s Genius Bus, the module empowers engineers to optimize process control, reduce energy consumption, and maintain compliance with industry standards for precision manufacturing.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC660TSA100 |
| Manufacturer | General Electric (GE) |
| Product Type | Temperature Sensor Amplifier Module |
| Input Channels | 8 channels (configurable for RTD/thermocouple) |
| Input Range | -10 to +10 VDC, 4–20 mA |
| Resolution | 16-bit ADC |
| Accuracy | ±0.1% of full scale |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 100 mm (W) × 150 mm (H) × 75 mm (D) |
| Weight | 0.8 kg |
| Communication Protocol | GE Genius Bus |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL |
Main Features and Advantages
Precision Signal Amplification: The GE IC660TSA100 utilizes advanced amplification algorithms to condition temperature sensor signals, ensuring measurement accuracy within ±0.1% of full scale. This capability is vital in applications where slight temperature variations could lead to process inefficiencies, such as chemical reactors or high-precision manufacturing lines.
Multi-Channel Flexibility: With 8 configurable channels, the module supports a mix of voltage (0–10 VDC) and current (4–20 mA) inputs, adapting to diverse sensor types without hardware modifications. This flexibility reduces inventory needs and simplifies system integration in hybrid automation setups, where multiple sensor technologies may be deployed.
Rugged Industrial Design: Built with a rugged metal enclosure and conformal-coated PCBs, the GE IC660TSA100 resists dust, moisture, and electromagnetic interference (EMI), making it suitable for harsh environments like offshore platforms, steel mills, or mining facilities. Its wide temperature range eliminates the need for additional climate control, lowering installation and maintenance costs.
Real-Time Diagnostics: Integrated self-test functions monitor channel performance, power supply stability, and thermal conditions, providing real-time feedback via front-panel LEDs and the PLC’s human-machine interface (HMI). This proactive diagnostic capability helps identify potential issues before they escalate, reducing mean time to repair (MTTR) and enhancing overall system reliability.
Seamless PLC Integration: As part of GE’s Series 6000 platform, the GE IC660TSA100 connects directly to the Genius Bus, enabling high-speed data transfer to the PLC’s central processor. This integration supports real-time adjustments and eliminates the need for external signal conditioners, streamlining control architecture and improving system responsiveness.
Application Areas
The GE IC660TSA100 is widely deployed in industries requiring precise temperature measurement and reliable signal conditioning:
-
Power Generation:
- Monitors turbine inlet and exhaust temperatures in combined cycle power plants, adjusting for ambient variations to optimize fuel efficiency and reduce emissions.
- Supports temperature monitoring in generator stator windings, preventing overheating and extending equipment lifespan through accurate thermal feedback.
-
Oil and Gas:
- Controls pipeline temperature sensors by amplifying and conditioning signals, ensuring accurate flow measurement and preventing wax deposition in cold environments.
- Integrates with refinery distillation units to maintain precise temperature control during crude oil processing, enhancing product quality and yield.
-
Manufacturing:
- Maintains consistency in plastic extrusion processes by stabilizing temperature sensor readings, reducing material waste and improving part dimensional accuracy.
- Monitors oven temperatures in semiconductor fabrication, where ±1°C precision is critical for chip quality and manufacturing yield.
-
Water/Wastewater Treatment:
- Regulates chemical dosing systems by compensating for temperature effects on reagent viscosity, ensuring consistent treatment efficacy in water purification plants.
- Monitors cooling tower water temperatures in power plants, adjusting for ambient conditions to optimize heat exchange efficiency and water conservation.
Related Products
- GE IC660TBA026: A temperature bias amplifier module with similar functionality, offering enhanced bias compensation for thermal drift in high-precision applications.
- GE IC660TDS010: A temperature display module that pairs with the GE IC660TSA100 to provide local readouts of amplified temperature values, improving operator visibility in control panels.
- GE IC660TBC026: A thermocouple input conditioning module, often used alongside the GE IC660TSA100 to expand system capability for different sensor types.
- GE IC693MDL340: A digital output module from the Series 90-30 platform, compatible with the GE IC660TSA100 for actuation tasks in hybrid control systems.
- GE IC697CPU780: A high-performance PLC processor for the Series 90-70 platform, enabling complex control strategies when integrated with the GE IC660TSA100.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IC660TSA100, ensure the following:
Before installing the GE IC660TSA100, ensure the following:
- Verify the power supply meets 24 VDC ±10% and that the control panel is properly grounded to prevent electrostatic discharge (ESD) damage.
- Use GE’s VersaPro software to configure channel types (RTD/thermocouple), input ranges, and amplification parameters based on sensor specifications.
- Mount the module in a 19″ rack with at least 25 mm clearance for airflow, avoiding proximity to high-heat or high-vibration components that could affect performance.
Maintenance Recommendations:
- Routine Checks: Perform monthly visual inspections of front-panel LEDs (green for normal operation, red for faults) and clean dust from ventilation slots to maintain optimal cooling.
- Calibration: Conduct annual calibration of all channels using a certified voltage/current source to ensure measurement accuracy, particularly in applications requiring tight tolerance.
- Firmware Updates: Periodically update the module’s firmware via GE’s programming software to access bug fixes, compatibility improvements, and new features.
- Spare Parts Management: Maintain a spare GE IC660TSA100 for critical systems, as its hot-swappable design allows replacement without powering down the PLC rack, minimizing downtime during maintenance.
Product Warranty
Our company provides a one-year quality warranty for the GE IC660TSA100, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits abnormal signal amplification or functional defects. For discontinued models like the GE IC660TSA100, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. Additionally, we offer post-warranty technical support and repair services through our network of certified technicians, ensuring your automation systems remain operational and reliable over the long term.
