GE IC660HHM501S1 Genius Hand-Held Monitor
Product Overview
The GE IC660HHM501S1 is a Genius series industrial-grade hand-held monitor (HHM) designed for advanced diagnostics, configuration, and real-time monitoring of GE’s Genius I/O systems. As a specialized variant of the IC660HHM501, the S1 designation signifies enhanced compatibility and performance, making it ideal for mission-critical applications in power generation, oil refining, and automotive manufacturing.
Engineered with a 4-line alphanumeric LCD display and 20-key sealed membrane keypad, the IC660HHM501S1 provides operators with direct access to Genius Bus data, including I/O status, diagnostic codes, and controller memory. It supports Genius Bus protocol (125 kbps) for seamless integration with modules like IC660BBA100 (analog I/O) and IC660BBD020 (digital I/O), enabling remote parameter adjustment and fault clearing. The device operates on 115–230V AC or 3 AA batteries (100-hour runtime), with an IP65-rated housing that resists dust, water splashes, and oil—critical for harsh industrial environments.
The IC660HHM501S1 features selectable language support (English, German, French, Italian) and a key switch for restricted function access, ensuring secure operation in regulated industries. Its hot-connect capability allows safe connection to live systems, minimizing downtime during troubleshooting. Compliance with UL 508 and IEC 61131-2 standards underscores its reliability in environments where precision and safety are paramount.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC660HHM501S1 |
| Manufacturer | GE |
| Product Type | Hand-Held Monitor (HHM) |
| Series | Genius |
| Display | 4-line alphanumeric LCD (16 characters/line) |
| Communication Protocol | Genius Bus (125 kbps) |
| Power Supply | 115–230V AC (47–63 Hz) or 3 AA batteries |
| Physical Dimensions | 10.85” (L) × 4.30” (W) × 2.25” (D) |
| Weight | 1.8 lbs (with protective case) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Protection Rating | IP65 (dust-tight, water-resistant) |
| Humidity | 5–95% non-condensing |
| Interface | 8-pin mini-DIN connector |
| Compliance | UL 508, IEC 61131-2, CE |
| Country of Origin | United States |
Note: Specifications are based on the IC660HHM501 series; the S1 variant may include firmware updates or minor hardware adjustments.
Main Features and Advantages
Rugged Portability for Industrial Use
The IC660HHM501S1’s IP65-rated design and 4-foot drop resistance ensure durability in challenging settings like power plant turbine halls or chemical processing facilities. Its compact size (10.85” × 4.30” × 2.25”) and 1.8 lbs weight allow operators to carry it effortlessly during on-site inspections, while the backlit LCD remains visible in low-light conditions.
Versatile Power and Connectivity
Dual power options (AC or batteries) provide flexibility: AC power supports continuous operation during extended troubleshooting, while batteries enable cordless use for routine checks. The Genius Bus interface allows direct interaction with controllers like IC697CPU780, eliminating the need for laptops or fixed HMIs.
Enhanced Diagnostic Capabilities
The HHM reads real-time data from Genius modules, including input/output status, fault codes, and configuration parameters. For example, it can reset tripped relays in IC660BPM100 power monitoring blocks or adjust setpoints for pressure sensors connected to IC660BBA100 analog modules. Its 125 kbps data rate ensures rapid response in high-speed applications like automotive assembly lines.
Secure and User-Friendly Interface
A key switch restricts access to sensitive functions, preventing unauthorized changes in regulated environments. The 4-line LCD and intuitive keypad simplify navigation, while multilingual support accommodates global workforces. Technicians can force discrete or analog I/O signals directly through the HHM, simulating inputs to diagnose sensor or actuator failures.
Application Fields
The GE IC660HHM501S1 excels in industries requiring reliable on-the-go system monitoring:
- Power Generation: Operators use it to monitor turbine vibration sensors (via IC660BBA100) and reset emergency stop relays, ensuring uninterrupted energy production. The IP65 rating protects it from steam and coolant splashes in turbine halls.
- Oil and Gas: Technicians troubleshoot wellhead control panels by reading pressure transmitter data (4–20mA signals) and adjusting valve positions. The HHM’s 115–230V AC compatibility suits offshore platforms with variable power supplies.
- Automotive Manufacturing: Maintenance teams diagnose robotic welders by checking input signals from proximity sensors (connected to IC660BBD020) and recalibrating weld timers. Its portability allows quick checks across multiple assembly stations.
- Water Treatment: Operators adjust pump pressure setpoints and diagnose flow meter faults in remote pump stations, using the HHM to access data without returning to the control room.
Related Products
- GE IC697CPU780: Genius series controller that communicates with the IC660HHM501S1, enabling remote logic adjustments and fault analysis.
- GE IC660BBA100: Analog I/O module whose temperature/pressure data is visualized and adjusted via the IC660HHM501S1.
- GE IC660BBD020: Digital I/O module that reports sensor status to the HHM, supporting quick diagnosis of conveyor belt malfunctions.
- GE IC660PWR101: 24V DC power supply that charges the HHM’s batteries during extended use, ensuring continuous operation.
- GE IC660CBL105: 5m shielded cable extending the HHM’s reach to remote Genius Bus devices.
- GE IC660HHM502: Graphical HHM with trend visualization, ideal for users requiring detailed data analysis beyond the IC660HHM501S1’s alphanumeric display.
Installation and Maintenance
Pre-installation preparations: Verify the Genius Bus network is powered and the 8-pin mini-DIN connector is undamaged. For AC operation, connect to a 115–230V AC source; for battery use, insert 3 AA batteries (alkaline recommended). Test communication by connecting to a live module (e.g., IC660BBD020) and verifying data display. Secure the HHM in its protective case for field use.
Maintenance suggestions: Replace batteries when the low-power indicator activates to avoid data loss. Clean the LCD with a dry microfiber cloth and inspect the keypad for debris. Quarterly, update firmware using GE’s configuration software to ensure compatibility with newer Genius modules. Store the HHM in a dry environment to prevent corrosion, and recalibrate sensor inputs annually using a precision voltage source.
Product Guarantee
Our company offers a one-year quality warranty service for the IC660HHM501S1, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems. As a leading import and export trade distribution company established in 2007 with 17 years of experience, we maintain a large stock of IC660HHM501S1 and other Genius series components, ensuring 48-hour delivery for urgent requirements. Our technical team provides user guides, firmware updates, and troubleshooting support to maximize device utility.
