GE IC660BBS103 Product Specification
Product Overview
The GE IC660BBS103 is a high-reliability 8-circuit isolated I/O block engineered for GE Fanuc’s Genius I/O system, designed to interface with field devices in industrial automation, power generation, and process control applications. As a core component of the Genius distributed architecture, this module processes discrete signals—such as switch inputs, valve commands, and motor control signals—with precision and robustness, ensuring seamless integration with GE Fanuc PLCs and other automation controllers.
Integrated into the Genius I/O platform, the GE IC660BBS103 features 250 VAC/VDC continuous isolation between circuit groups, protecting against electrical noise and surges in high-interference environments like manufacturing floors or power plants 14. Its 8 configurable I/O channels support both 2-wire and 3-wire switches, with selectable input filtering (10–100 ms) to minimize false triggers from transient signals 14. The module’s compact form factor (7.6 cm × 20.3 cm × 10.2 cm) and rugged construction—IP20-rated enclosure and conformal coating—enable reliable operation in temperatures ranging from 0°C to 60°C, making it suitable for harsh industrial settings 48.
Designed for flexibility, the GE IC660BBS103 allows independent AC/DC powering of its internal electronics and field circuits, accommodating a wide range of voltage inputs (93–132 VAC or 105–132 VDC) 14. Its front-panel LEDs provide real-time status monitoring for power, I/O enablement, and individual circuit activity, simplifying troubleshooting. The module’s hot-swappable design—combined with GE Fanuc’s Proficy software for configuration—reduces downtime during maintenance or system expansion, ensuring continuous operation in mission-critical applications 7.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC660BBS103 |
| Manufacturer | General Electric (GE) |
| Product Type | Isolated Discrete I/O Block |
| Series | Genius I/O System |
| I/O Channels | 8 configurable (mixed inputs/outputs) |
| Signal Types Supported | Dry contact switches, 24–125 VDC/AC signals |
| Physical Dimensions | 7.6 cm (H) × 20.3 cm (W) × 10.2 cm (D) |
| Weight | 1.8 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Power Supply | 93–132 VAC (47–63 Hz) or 105–132 VDC |
| Isolation | 250 VAC/VDC continuous (between groups), 2000 V peak transient (10 sec) 14 |
| Input Filter | 10–100 ms selectable |
| Output Current | 2 A per channel (resistive load) |
| Mounting Type | DIN rail or panel mount with M4 screws (torque: 0.678 N·m) 4 |
| Certifications | CE, UL 508 (pending detailed verification) |
Main Features and Advantages
Rugged Isolation and Protection:
The GE IC660BBS103’s triple-layer isolation safeguards against voltage spikes and electromagnetic interference, critical in environments with welding equipment, motors, or high-voltage machinery. Its transient rating of 2000 V peak ensures immunity to surges caused by lightning strikes or equipment startup 14. This resilience reduces the risk of signal corruption and equipment damage, minimizing unplanned downtime.
The GE IC660BBS103’s triple-layer isolation safeguards against voltage spikes and electromagnetic interference, critical in environments with welding equipment, motors, or high-voltage machinery. Its transient rating of 2000 V peak ensures immunity to surges caused by lightning strikes or equipment startup 14. This resilience reduces the risk of signal corruption and equipment damage, minimizing unplanned downtime.
Flexible Configuration:
With 8 configurable I/O channels, the module adapts to diverse applications, from monitoring limit switches in conveyor systems to controlling solenoid valves in chemical processing. Engineers can customize input filtering to reject noise and set output defaults (e.g., hold last state or reset to zero) via GE Fanuc’s Proficy software or the IC660HHM501 handheld monitor 17. This flexibility eliminates the need for multiple specialized modules, simplifying system design and reducing costs.
With 8 configurable I/O channels, the module adapts to diverse applications, from monitoring limit switches in conveyor systems to controlling solenoid valves in chemical processing. Engineers can customize input filtering to reject noise and set output defaults (e.g., hold last state or reset to zero) via GE Fanuc’s Proficy software or the IC660HHM501 handheld monitor 17. This flexibility eliminates the need for multiple specialized modules, simplifying system design and reducing costs.
Real-Time Diagnostics:
Front-panel LEDs provide instant visibility into power status, I/O enablement, and individual circuit health. For example, a solid green “Unit OK” LED confirms proper operation, while a red “Fault” LED indicates overcurrent or short-circuit conditions 14. The module’s electronic fusing—activating within 5 µs of a fault—protects outputs from damage, and faults can be cleared remotely via the PLC or handheld tool 4.
Front-panel LEDs provide instant visibility into power status, I/O enablement, and individual circuit health. For example, a solid green “Unit OK” LED confirms proper operation, while a red “Fault” LED indicates overcurrent or short-circuit conditions 14. The module’s electronic fusing—activating within 5 µs of a fault—protects outputs from damage, and faults can be cleared remotely via the PLC or handheld tool 4.
Seamless Integration:
The GE IC660BBS103 interfaces directly with GE Fanuc’s IC693BEM331 Genius bus controller and IC693CHS397 rack, enabling plug-and-play connectivity in distributed control systems 7. Its compatibility with the Genius protocol ensures high-speed data exchange (up to 1 Mbps) with PLCs like the IC693CPU374, supporting real-time control in applications such as turbine monitoring or assembly line automation 7.
The GE IC660BBS103 interfaces directly with GE Fanuc’s IC693BEM331 Genius bus controller and IC693CHS397 rack, enabling plug-and-play connectivity in distributed control systems 7. Its compatibility with the Genius protocol ensures high-speed data exchange (up to 1 Mbps) with PLCs like the IC693CPU374, supporting real-time control in applications such as turbine monitoring or assembly line automation 7.
Hot-Swappable Design:
The module supports hot swapping, allowing replacement without powering down the system—a critical feature in continuous processes like oil refining or power generation. This capability reduces mean time to repair (MTTR) to under 15 minutes, maintaining productivity during maintenance 47.
The module supports hot swapping, allowing replacement without powering down the system—a critical feature in continuous processes like oil refining or power generation. This capability reduces mean time to repair (MTTR) to under 15 minutes, maintaining productivity during maintenance 47.
Application Areas
-
Manufacturing:
- Monitors conveyor belt alignment using 2-wire proximity sensors, triggering alarms or stopping belts if misalignment occurs.
- Controls pneumatic actuators in robotic assembly lines, using discrete outputs to open/close valves and synchronize movements.
-
Power Generation:
- Processes breaker status signals from generators, activating protective relays during grid faults.
- Manages cooling fan motors in turbine enclosures, adjusting speeds based on temperature inputs.
-
Oil and Gas:
- Monitors wellhead pressure switches, initiating emergency shutdowns (ESDs) if thresholds are exceeded.
- Controls solenoid valves in subsea manifolds, regulating fluid flow in offshore production systems.
-
Water/Wastewater:
- Supervises pump status (on/off) and level sensors in treatment plants, automating valve operations to maintain optimal flow.
- Manages chemical dosing systems by activating pumps based on pH or turbidity sensor inputs.
-
HVAC:
- Controls damper actuators in large facilities, adjusting airflow based on occupancy or temperature readings.
- Monitors smoke detectors in fire alarm systems, triggering sprinklers or evacuation protocols.
Related Products
- GE IC660HHM501: Handheld monitor for configuring GE IC660BBS103 parameters, such as input filtering and output defaults 7.
- GE IC693BEM331: Genius bus controller that enables communication between GE IC660BBS103 and PLCs like the IC693CPU374 7.
- GE IC693CHS397: 5-slot rack for housing GE IC660BBS103 and other Genius modules, ensuring mechanical stability and thermal management 7.
- GE IC693PWR330: Power supply module that delivers stable 24 VDC to GE IC660BBS103 and other rack-mounted components 7.
- GE IC660BBS102: Similar 8-circuit I/O block with failed switch diagnostics, suitable for applications requiring enhanced fault detection.
- ABB 6246BP10811: Alternative I/O block compatible with GE IC660BBS103 in hybrid automation systems 8.
