Product Overview: GE IC2812B207AC21C Motor Field Contactor
The GE IC2812B207AC21C motor field contactor is part of GE’s industrial automation product line, designed to meet the precise control requirements of motor field circuits. As a critical component of motor control systems, it plays a vital role in industrial automation systems. The GE IC2812B207AC21C adopts a 3NO/3NC contact configuration and features a coil voltage of 115/125VDC. Its compact size and robust performance make it suitable for various industrial environments. It can reliably control the flow of electricity to motors, ensuring stable motor operation and enhancing the efficiency and reliability of automation systems. The GE IC2812B207AC21C is widely used in motor control systems across industries such as power generation, manufacturing, and oil and gas. It helps users achieve precise motor control, reduce operational risks, and improve production efficiency. Its excellent performance and stable quality make it a preferred choice for industrial users.
Technical Specifications：GE IC2812B207AC21C
| Product Models | GE IC2812B207AC21C |
|---|---|
| Manufacturer | GE |
| Product Type | Motor Field Contactor |
| Coil Voltage | 115/125VDC |
| Contact Configuration | 3NO/3NC |
| Power Consumption | 3.5VA |
| Contact Material | Silver Alloy |
| Insulation Resistance | 1000MΩ (500V DC) |
| Dielectric Strength | 2000V AC, 50/60Hz, 1 minute |
| Ambient Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | 10g (10Hz to 500Hz) |
| Shock Resistance | 50g (11ms) |
| Installation Method | Rail mounting |
| Dimensions (L × W × H) | 118mm × 88mm × 140mm |
| Weight | Approximately 0.7kg |
Main Features and Advantages：GE IC2812B207AC21C
The GE IC2812B207AC21C motor field contactor boasts numerous outstanding features. First, its 3NO/3NC contact configuration provides strong control capabilities, enabling precise control of motor field circuits. Second, with a coil voltage of 115/125VDC, it offers stable performance and high reliability, ensuring smooth operation even in harsh industrial environments. Third, it features a compact and lightweight design, making it easy to install and integrate into existing systems while saving space. Fourth, its contact material is made of silver alloy, which offers excellent conductivity and wear resistance, extending the service life of the contactor. Fifth, it provides robust insulation and dielectric strength, effectively preventing electrical leakage and short circuits to ensure operational safety. Additionally, it has strong resistance to vibration and shock, making it suitable for industrial environments with frequent vibrations and impacts. Finally, its wide operating temperature range allows it to adapt to various climatic conditions.
Application Fields：GE IC2812B207AC21C
The GE IC2812B207AC21C motor field contactor is widely applicable across multiple industries. In the power generation sector, it is used to control the field circuits of generators, ensuring stable generator operation and reliable power supply. In manufacturing, it is employed in motor control systems for various production equipment, enabling precise motor start/stop and speed regulation to improve production efficiency and product quality. In the oil and gas industry, it is applied to motor control systems in oil extraction, transportation, and refining equipment, ensuring stable motor operation and safe production. In the chemical industry, it is used in motor control systems for chemical production equipment, providing reliable motor control to ensure safe and stable chemical production. In the mining sector, it is utilized in motor control systems for mining equipment, ensuring stable motor operation and production safety. In the building materials industry, it is applied to motor control systems for production equipment such as cement kilns and glass furnaces, enabling precise motor control to improve production efficiency and product quality.
Related Products：GE IC2812B207AC21C
-
GE IC2812B207AC21C: Motor field contactor, same model as this product.
-
GE IC2KFCB03A: Motor field circuit breaker, used for overload and short-circuit protection of motor field circuits. It works in conjunction with the GE IC2812B207AC21C motor field contactor to provide comprehensive motor field circuit protection.
-
GE IC693ACC390: Accessory module, used to expand the functionality of motor field contactors. It can enhance the performance of the GE IC2812B207AC21C motor field contactor and meet diverse user needs.
-
GE IC693CPU360: Central processing unit module, as the core of the control system, it sends control signals to the GE IC2812B207AC21C motor field contactor to achieve precise motor field circuit control.
-
GE IC693MDL770: I/O module, used to collect motor field circuit signals and transmit control signals to the GE IC2812B207AC21C motor field contactor. It enables effective communication between the control system and the motor field contactor.
-
GE IC693PWR325: Power supply module, provides stable power to the control system and the GE IC2812B207AC21C motor field contactor, ensuring reliable system operation.
-
GE IC693PRG405: Programming module, used to program and configure the control system. It enables precise control of the GE IC2812B207AC21C motor field contactor through programming.
-
GE IC693COM350: Communication module, facilitates communication between the control system and external devices. It allows remote monitoring and control of the GE IC2812B207AC21C motor field contactor.
Installation and Maintenance：GE IC2812B207AC21C
Pre-Installation Preparations
Before installing the GE IC2812B207AC21C motor field contactor, ensure the installation site meets the following conditions: ambient temperature within -25°C to +70°C, relative humidity between 5% and 95% (non-condensing), and no corrosive gases or conductive dust in the environment. Prepare the necessary tools and materials, such as a rail mounting bracket, screws, and wires. Inspect the contactor’s appearance to ensure there is no damage or deformation. Verify that its model and specifications match the design requirements.
Maintenance Suggestions
During the use of the GE IC2812B207AC21C motor field contactor, regular maintenance is essential. Periodically clean the contactor to remove dust and dirt from its surface and contacts to prevent poor contact. Inspect the tightness of screws and other fasteners to ensure secure connections. Check the insulation resistance of the contactor to ensure it meets the required standards. Test its dielectric strength to ensure it can withstand the specified voltage without breakdown. Monitor the contactor’s temperature during operation to prevent overheating. If any abnormalities are detected, promptly identify the cause and address the issue. Regularly lubricate moving parts of the contactor to ensure smooth operation and extend its service life.
Product Guarantee：GE IC2812B207AC21C
Our company provides a one-year quality warranty service for the GE IC2812B207AC21C motor field contactor, covering hardware malfunctions not caused by human error. During the warranty period, if the product exhibits abnormal performance or functional failure, we will offer replacement services. Additionally, for discontinued models or urgent demands, leveraging our global supply chain network, we can swiftly respond to customers’ procurement needs for scarce spare parts. We will provide reliable services to support the continuous and stable operation of industrial systems. Our company, a leading enterprise in the industrial control industry since 2007, boasts extensive experience and expertise. We are committed to delivering high-quality products and services to meet customers’ diverse needs. For inquiries about our products, please visit our official website or contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
