GE IC200PWR012D Product Specification
Product Overview
The GE IC200PWR012D is a high-performance AC power supply module designed for industrial automation systems, specifically engineered to deliver stable and reliable power to GE’s IC200 series PLC platforms. As a critical component in control systems, this module ensures uninterrupted operation of programmable logic controllers (PLCs), input/output (I/O) modules, and other peripherals in demanding industrial environments. The GE IC200PWR012D is part of GE’s legacy IC200 series, renowned for its rugged durability and compatibility with a wide range of automation applications.
With a nominal input voltage of 120 VAC and support for frequencies between 50–60 Hz, the GE IC200PWR012D offers robust power regulation, ensuring consistent output even under fluctuating line conditions. Its compact design and lightweight construction facilitate easy integration into 19″ racks, while the IP23-rated enclosure protects against dust and moisture. The module is certified for CE, UL, and RoHS compliance, meeting international standards for safety and environmental sustainability.
In automation systems, the GE IC200PWR012D acts as the backbone of power distribution, providing clean and stable DC power to downstream components. Its fail-safe design includes overcurrent and thermal protection, minimizing downtime and extending system lifespan. By integrating with GE’s IC200 series, the module supports scalable control solutions for industries such as manufacturing, oil and gas, and power generation, where reliability and precision are paramount.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200PWR012D |
| Manufacturer | General Electric (GE) |
| Product Type | AC Power Supply Module |
| Input Voltage | 120 VAC ±10% |
| Input Frequency | 50–60 Hz |
| Output Voltage | 24 VDC (nominal) |
| Power Capacity | 100 W |
| Physical Dimensions | 178 mm (W) × 127 mm (H) × 102 mm (D) |
| Weight | 1.2 kg |
| Enclosure Protection | IP23 |
| Operating Temperature | -25°C to +60°C |
| Humidity Resistance | 95% non-condensing |
| Country of Origin | United States |
| Certifications | CE, UL, RoHS |
Main Features and Advantages
Wide Voltage Compatibility: The GE IC200PWR012D supports a broad input voltage range (108–132 VAC), making it suitable for diverse power supply environments. This adaptability reduces the need for additional voltage converters, simplifying system design and lowering installation costs.
Reliable Power Regulation: The module ensures stable 24 VDC output with ±10% tolerance, critical for maintaining accurate control signals in PLC systems. Its built-in overcurrent and thermal protection mechanisms safeguard against damage from short circuits or excessive heat, enhancing system longevity.
Compact and Rugged Design: The module’s IP23-rated enclosure and conformal-coated PCBs protect against environmental contaminants, ensuring reliable performance in high-dust or humid industrial settings. Its lightweight construction (1.2 kg) and standardized 19″ rack-mount form factor streamline installation and maintenance.
Certified Compliance: With CE, UL, and RoHS certifications, the GE IC200PWR012D meets strict international standards for safety and environmental sustainability, making it suitable for global industrial applications.
Modular System Integration: As part of GE’s IC200 series, the GE IC200PWR012D seamlessly integrates with other modules (e.g., CPU, I/O, communication cards) to form a cohesive control system. This modularity allows for easy scalability and customization based on operational requirements.
Application Areas
The GE IC200PWR012D is widely used in industries requiring stable power supply for critical automation systems:
-
Manufacturing:
- Powers PLCs and robotic controllers in automotive assembly lines, ensuring precise motion control and reducing downtime.
- Supports quality control systems by providing stable power to vision inspection cameras and sensors.
-
Oil and Gas:
- Maintains reliable power supply to control valves and monitoring systems in offshore platforms and refineries.
- Integrates with emergency shutdown systems (ESD) to ensure safe operation during voltage fluctuations.
-
Power Generation:
- Provides power to steam turbine control systems, enabling real-time monitoring of rotor speed and vibration.
- Supports generator protection relays by delivering consistent DC power to protective devices.
-
Water/Wastewater Treatment:
- Regulates power to pump stations and chemical dosing systems, ensuring continuous water flow and treatment efficiency.
- Integrates with SCADA systems for remote monitoring of distributed water treatment facilities.
Related Products
- GE IC200CPU001: A central processing unit (CPU) module for the IC200 series, which relies on the GE IC200PWR012D for power to execute control logic and data processing.
- GE IC200MDL650: A digital input/output module that interfaces with the GE IC200PWR012D to connect field devices (e.g., switches, solenoids) to the PLC system.
- GE IC200ALG220: An analog input module used for monitoring process variables (e.g., temperature, pressure), requiring stable power from the GE IC200PWR012D for accurate signal conditioning.
- GE IC200PWR010B: A 120 VAC power supply module with lower power capacity (75 W), serving as a cost-effective alternative for less demanding applications.
- GE IC200PWR011B: A 240 VAC power supply module compatible with the IC200 series, offering higher voltage input for global installations.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IC200PWR012D, ensure the following:
Before installing the GE IC200PWR012D, ensure the following:
- Verify the input voltage matches the module’s requirements (120 VAC) and that the rack is properly grounded to prevent electrostatic discharge (ESD) damage.
- Clean the mounting surface and secure the module in a 19″ rack using the provided brackets, allowing at least 50 mm of clearance for airflow.
- Inspect the module for physical damage and confirm all connectors are free of debris.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” indicator). Clean dust from vents quarterly to maintain optimal cooling.
- Output Voltage Check: Measure the output voltage annually using a multimeter to ensure it remains within the specified tolerance (24 VDC ±10%).
- Component Testing: Test overcurrent protection mechanisms biannually by simulating a short circuit and verifying the module trips safely.
- Firmware Updates: Periodically update the module’s firmware via GE’s programming software to access new features and security patches.
Product Warranty
Our company provides a one-year quality warranty for the GE IC200PWR012D, covering hardware malfunctions not caused by human factors. During the warranty period, if the product exhibits abnormal performance or functional failure, we will provide replacement services. For discontinued models like the GE IC200PWR012D, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on technical data derived from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE IC200PWR012D user manual or contact our technical support team for personalized assistance.
