GE IC200PWB001A Power Supply Module
Product Overview
The GE IC200PWB001A is a high-reliability Power Supply Module designed for GE’s 90-30 Series programmable logic controllers (PLCs), serving as the primary power source for industrial automation systems. Engineered to convert incoming AC power into stable DC voltage for PLC components, this module ensures consistent operation of CPU modules, I/O cards, and communication interfaces in manufacturing, power generation, and process control environments. As an integral part of the IC200 Series, the IC200PWB001A combines robust design with advanced fault protection, making it ideal for applications where uninterrupted power supply is critical to system reliability.
Featuring a compact form factor and rugged construction, the GE IC200PWB001A supports a wide input voltage range (85–264 V AC) and delivers a regulated 24 V DC output with up to 1.5 A current capacity. Its built-in overvoltage, overcurrent, and thermal protection mechanisms safeguard connected equipment from power fluctuations and transient spikes, while diagnostic LEDs provide real-time status feedback. The module’s compatibility with GE’s 90-30 PLC framework allows seamless integration into existing control systems, reducing downtime during upgrades or maintenance.
In automation ecosystems, the IC200PWB001A serves as the power backbone for 90-30 Series PLCs, ensuring stable operation of control logic and field device interfaces. Its hot-swappable design enables replacement without powering down the system, a critical feature for 24/7 industrial operations. By combining energy efficiency with reliable performance, this module supports the continuous operation of critical processes, from conveyor systems in manufacturing to pump control in water treatment plants.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC200PWB001A |
| Manufacturer | GE |
| Product Type | Power Supply Module |
| Input Voltage | 85–264 V AC, 50/60 Hz |
| Output Voltage | 24 V DC ±0.5 V |
| Output Current | 1.5 A max |
| Power Output | 36 W max |
| Efficiency | 85% typical |
| Physical Dimensions | 101.6 mm (H) × 127 mm (W) × 76.2 mm (D) |
| Weight | 0.9 kg |
| Operating Temperature | 0°C to +60°C (with derating above 40°C) |
| Mounting | DIN rail or panel-mounted |
| Certifications | CE, UL, cUL |
Key Features and Advantages
Wide Input Voltage Range: The IC200PWB001A accommodates input voltages from 85 to 264 V AC, eliminating the need for voltage converters in global applications. This flexibility ensures reliable operation in regions with varying power grids, reducing installation complexity.
Robust Fault Protection: Integrated overvoltage, overcurrent, and thermal protection circuits prevent damage to the module and connected PLC components. The module automatically shuts down or limits current during faults, minimizing the risk of system-wide failures.
High Efficiency Design: With 85% energy conversion efficiency, the IC200PWB001A reduces power loss and heat generation, contributing to lower operational costs and a smaller environmental footprint. This efficiency is critical for maintaining cool operating temperatures in enclosed control panels.
Hot-Swap Capability: The module can be replaced while the system is running, allowing maintenance without interrupting operations. This feature is essential for industries requiring continuous uptime, such as food processing or oil refining.
Compact and Versatile Mounting: Measuring 101.6 × 127 × 76.2 mm, the module fits into tight control panel spaces. It supports both DIN rail and panel mounting, adapting to diverse installation requirements.
Clear Status Indicators: Front-panel LEDs display power status, fault conditions, and output voltage stability, enabling quick visual diagnostics and reducing troubleshooting time.
Application Areas
The GE IC200PWB001A is widely used in industries that rely on stable power for PLC-driven automation:
- Manufacturing: Powers PLCs controlling assembly lines, robotic systems, and material handling equipment in automotive, electronics, and pharmaceutical facilities.
- Power Generation: Supports PLCs managing generator controls, switchgear, and auxiliary systems in thermal and renewable energy plants.
- Oil & Gas: Powers control systems for pumps, compressors, and valves in pipelines, refineries, and offshore platforms, ensuring reliable operation in harsh environments.
- Water/Wastewater: Controls pumps, filters, and treatment processes in water distribution and sewage treatment plants, maintaining regulatory compliance.
- Food & Beverage: Drives PLCs in packaging lines, mixers, and sterilization systems, where consistent power is essential for product quality and safety.
Specific applications include:
- Continuous Process Control: Maintains stable power for PLCs managing chemical reactions or batch processes, preventing disruptions that could lead to product loss.
- Building Automation: Powers PLCs controlling HVAC systems, lighting, and security in commercial buildings, optimizing energy use.
- Material Handling: Supports PLCs in conveyor systems and automated storage/retrieval systems, ensuring smooth logistics in warehouses and distribution centers.
Related Products
- IC200PWR001 (Redundant Power Supply): Offers dual-power input redundancy for the IC200PWB001A, enhancing system reliability in critical applications.
- IC200CPU001 (90-30 CPU Module): The primary processor module for the 90-30 Series, directly powered by the IC200PWB001A.
- IC200ALG326 (Analog Input Module): An I/O module compatible with the 90-30 Series, relying on the IC200PWB001A for power.
- IC200MDL640 (Digital Output Module): A high-density output module for controlling relays and solenoids, powered by the IC200PWB001A.
- IC200ACC001 (Accessory Module): Extends the 90-30 Series framework, requiring the IC200PWB001A for operation.
- IC200PWB002 (High-Capacity Power Supply): A variant with higher output current (3 A) for systems requiring more power.
- IC200CBL001 (Communication Cable): Connects the power module to other 90-30 Series components, ensuring stable power distribution.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IC200PWB001A, verify the input voltage matches the module’s specifications (85–264 V AC). Ensure the DIN rail or mounting surface is securely fastened and grounded. Connect the input power cable to the module’s terminal block, using stranded wire with appropriate gauging (14–22 AWG). Route power cables separately from signal cables to minimize interference. Power on the system and check that the green power LED illuminates, indicating proper operation.
Before installing the GE IC200PWB001A, verify the input voltage matches the module’s specifications (85–264 V AC). Ensure the DIN rail or mounting surface is securely fastened and grounded. Connect the input power cable to the module’s terminal block, using stranded wire with appropriate gauging (14–22 AWG). Route power cables separately from signal cables to minimize interference. Power on the system and check that the green power LED illuminates, indicating proper operation.
Maintenance Suggestions:
- Routine Checks: Monthly visual inspections should confirm the power LED is active and no fault indicators are lit. Use a multimeter to verify output voltage (24 V DC ±0.5 V) and inspect terminals for loose connections.
- Cleaning: Quarterly, remove dust and debris from the module’s vents using compressed air to maintain optimal thermal performance.
- Spare Parts Management: Keep a spare IC200PWB001A on hand for rapid replacement in case of failure. Store spares in a dry, cool environment (10–30°C) to prevent component degradation.
- Load Monitoring: Periodically assess the module’s load current using the PLC’s diagnostic tools, ensuring it does not exceed 1.5 A to avoid overheating.
