GE IC200ALG620 Product Specification
Product Overview :GE IC200ALG620
The GE IC200ALG620 is a high-performance 16-bit analog input module designed for the GE PACSystems RX3i series, a leading platform in industrial automation. Engineered to deliver precise and reliable data acquisition, this module plays a critical role in monitoring and controlling analog signals in diverse industrial environments. The GE IC200ALG620 supports multiple input signal types, including voltage (±10 VDC) and current (4–20 mA), making it ideal for applications requiring high-resolution measurements in process control systems, power generation, and manufacturing.
As part of GE’s PACSystems RX3i architecture, the GE IC200ALG620 integrates seamlessly with PLCs, HMIs, and other modules to form a comprehensive automation solution. Its modular design allows for easy expansion, with support for up to 8 channels of isolated analog inputs. The module’s 16-bit resolution ensures accurate signal conversion, minimizing errors in critical applications such as temperature monitoring, pressure regulation, and flow control. With a compact form factor (127 mm × 127 mm × 76 mm) and lightweight construction (0.5 kg), the GE IC200ALG620 is suitable for space-constrained environments while maintaining robust performance.
In automation systems, the GE IC200ALG620 acts as a vital interface between field devices and control systems, converting analog signals into digital data for processing. Its galvanic isolation protects against ground loops and electromagnetic interference (EMI), ensuring stable operation in harsh industrial settings. By providing real-time insights into process variables, the module enables predictive maintenance strategies and optimizes system efficiency. With its combination of high precision, reliability, and scalability, the GE IC200ALG620 is a cornerstone of modern industrial asset management.
Technical Specifications :GE IC200ALG620
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC200ALG620 |
| Manufacturer | General Electric (GE) |
| Product Type | 16-Bit Analog Input Module |
| Input Signal Types | Voltage (±10 VDC), Current (4–20 mA) |
| Number of Channels | 8 isolated channels |
| Resolution | 16 bits |
| Input Impedance | ≥1 MΩ (voltage), 250 Ω (current) |
| Power Supply | 24 VDC ±10% |
| Communication Protocol | Proprietary (via PACSystems RX3i backplane) |
| Physical Dimensions | 127 mm (W) × 127 mm (H) × 76 mm (D) |
| Weight | 0.5 kg |
| Operating Temperature | 0°C to +55°C |
| Enclosure Rating | IP20 |
| Country of Origin | United States |
| Certifications | CE, UL |
IC200ALG620
Main Features and Advantages :GE IC200ALG620
High-Precision Signal Conversion: The GE IC200ALG620’s 16-bit resolution ensures accurate measurement of analog signals, reducing errors in critical applications. Its wide input range (±10 VDC for voltage, 4–20 mA for current) accommodates diverse sensor types, from pressure transmitters to temperature probes.
Isolated Channels: Each of the 8 input channels is galvanically isolated, protecting the module and connected devices from ground loops and voltage spikes. This feature enhances system reliability in environments with high electromagnetic interference (EMI).
Modular Scalability: As part of the GE PACSystems RX3i series, the GE IC200ALG620 can be easily integrated with other modules (e.g., digital I/O, communication gateways) to create customized automation solutions. This scalability allows for seamless system expansion as operational needs evolve.
Rugged Industrial Design: Constructed with a robust IP20-rated enclosure, the module resists dust and debris, ensuring reliable performance in industrial settings. Its wide operating temperature range (0°C to +55°C) makes it suitable for both indoor and outdoor applications.
Easy Configuration: The GE IC200ALG620 is configured using GE’s Proficy Machine Edition software, enabling users to set input ranges, filter settings, and alarm thresholds with minimal effort. This intuitive interface reduces setup time and enhances operational efficiency.
Application Areas :GE IC200ALG620
The GE IC200ALG620 is widely used in industries requiring precise analog signal monitoring and control:
-
Power Generation:
- Monitors temperature and pressure in steam turbines to optimize energy output and prevent equipment failure.
- Integrates with generator control systems to ensure stable voltage and frequency regulation.
-
Oil and Gas:
- Measures flow rates and pressure in pipelines, enabling real-time adjustments to maintain operational efficiency.
- Supports emergency shutdown systems (ESD) by providing critical sensor data for safe process termination.
-
Manufacturing:
- Controls conveyor belt speed and robotic arm positioning in automotive plants, ensuring precision and reducing downtime.
- Monitors humidity and temperature in pharmaceutical production to maintain compliance with quality standards.
-
Water/Wastewater Treatment:
- Regulates chemical dosing systems by analyzing pH and conductivity levels, ensuring efficient water purification.
- Monitors pump performance in wastewater treatment plants to detect early signs of mechanical degradation.
IC200ALG620
Related Products :GE IC200ALG620
- GE IC200ALG630: A 16-bit analog input module with 8 channels, offering higher noise immunity and enhanced filtering capabilities compared to the GE IC200ALG620.
- GE IC200ALG260: A 12-bit analog input module suitable for applications requiring lower resolution but higher speed.
- GE IC200MDL754: A digital output module that pairs with the GE IC200ALG620 to create a complete I/O solution for process control.
- GE IC200ETH021: An Ethernet communication module that enables remote monitoring and data exchange with the GE IC200ALG620.
- GE IC200PWR001: A power supply module that provides stable 24 VDC power to the GE IC200ALG620 and other PACSystems RX3i modules.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IC200ALG620, ensure the following:
Before installing the GE IC200ALG620, ensure the following:
- Verify the power supply matches the module’s requirements (24 VDC ±10%) and that the rack is properly grounded to prevent electrostatic discharge (ESD) damage.
- Use GE’s Proficy Machine Edition software to configure input signal types (voltage/current) and set calibration parameters.
- Secure the module in a 19″ rack using the provided mounting brackets, allowing at least 25 mm of clearance for airflow.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Health” indicators). Clean dust from vents quarterly to maintain optimal cooling.
- Signal Calibration: Perform annual calibration using certified test equipment to ensure accurate signal conversion.
- Firmware Updates: Periodically update the module’s firmware via GE’s dedicated software to access new features and security patches.
- Component Testing: Test isolation barriers biannually to ensure compliance with safety standards and operational requirements.
IC200ALG620
Product Warranty :GE IC200ALG620
Our company provides a one-year quality warranty for the GE IC200ALG620, covering hardware malfunctions not caused by human factors. During the warranty period, if the product exhibits abnormal performance or functional failure, we will provide replacement services. For discontinued models like the GE IC200ALG620, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on technical data derived from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE IC200ALG620 user manual or contact our technical support team for personalized assistance.
