Product Overview
The GE CK11CE300 is a high-reliability digital input module engineered by GE, a global leader in industrial automation and control solutions. Designed for use in demanding industrial environments, the GE CK11CE300 serves as a critical component in programmable logic controller (PLC) and distributed control system (DCS) setups, enabling precise acquisition and processing of discrete input signals from field devices.
As a digital input module, the GE CK11CE300 translates binary signals from switches, sensors, and contactors into digital data that can be interpreted by control systems. It features 16 isolated input channels, each capable of handling voltage signals within a wide range, making it compatible with various industrial sensors and actuators..E-mail :sales@ygplc.com. The module’s core functionality lies in its ability to provide reliable signal conditioning, noise suppression, and fault detection, ensuring that control systems receive accurate and timely data for decision-making.
In industrial automation, the GE CK11CE300 acts as a bridge between field – level devices and the control system, playing a pivotal role in monitoring machine status, process conditions, and safety interlocks. Its robust design and advanced diagnostic capabilities make it suitable for harsh environments characterized by high electrical noise, temperature fluctuations, and mechanical stress. By integrating the GE CK11CE300 into industrial control systems, users achieve enhanced system reliability, reduced downtime, and improved operational efficiency, making it an indispensable asset for industries where precise signal acquisition is non-negotiable.
CK11CE300
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CK11CE300 |
| Manufacturer | GE |
| Product Type | Digital Input Module |
| Input Channels | 16 isolated channels |
| Input Signal Range | 24 V DC (±10%) |
| Input Current per Channel | 5 mA (nominal) |
| Isolation Voltage | 2,500 Vrms (between input and logic circuits) |
| Signal Filtering | Software-configurable (1–100 ms debounce time) |
| Communication Interface | Proprietary backplane interface (compatible with GE 90-30/90-70 PLC systems) |
| Power Supply | 5 V DC (from backplane) |
| Power Consumption | ≤1.5 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Vibration Resistance | 2 g peak, 5–200 Hz (per IEC 60068-2-6) |
| Physical Dimensions | 100 mm (W) × 150 mm (H) × 80 mm (D) |
| Mounting Method | Rack-mounted (compatible with GE PLC chassis) |
Main Features and Advantages
The GE CK11CE300 stands out for its robust design, precise signal handling, and adaptability to complex industrial environments, making it a preferred choice for critical control applications..E-mail :sales@ygplc.com.
High-Density Signal Acquisition
With 16 isolated input channels, the GE CK11CE300 allows for simultaneous monitoring of multiple field devices, reducing the need for multiple modules and optimizing space in control panels. Each channel is galvanically isolated to prevent ground loops and electrical interference, ensuring signal integrity even in noisy industrial settings. This high-density design is ideal for applications requiring extensive data acquisition, such as large manufacturing lines or process control systems.
CK11CE300
Flexible Signal Conditioning
The module supports software-configurable signal filtering, enabling users to adjust debounce times to eliminate transient noise from mechanical switches or relay contacts. This flexibility ensures reliable detection of valid signals, minimizing false inputs and improving control system accuracy. Whether used with proximity sensors, limit switches, or safety interlocks, the GE CK11CE300 provides consistent and dependable signal processing.
Rugged Industrial Design
Engineered to withstand harsh conditions, the GE CK11CE300 features a durable enclosure that resists dust, moisture, and mechanical vibrations. Its wide operating temperature range ensures reliable performance in both indoor and outdoor installations, from factory floors to remote industrial sites. The module’s robust construction and high isolation ratings make it suitable for use in environments where equipment failure could lead to costly downtime or safety risks.
Seamless System Integration
Designed for compatibility with GE’s 90-30/90-70 PLC systems, the GE CK11CE300 integrates seamlessly into existing control architectures. Its proprietary backplane interface enables fast data transfer and easy configuration through GE’s programming software, reducing setup time and troubleshooting efforts. This compatibility extends to third-party systems via standard communication protocols, enhancing its utility in hybrid automation setups..E-mail :sales@ygplc.com.
Advanced Diagnostic Capabilities
Built-in diagnostics provide real-time feedback on channel status, power supply health, and signal integrity. LED indicators for each channel allow quick visual verification of input states, while fault detection features identify issues such as open circuits or overvoltage conditions. These diagnostics enable proactive maintenance, minimizing unplanned downtime and ensuring continuous system operation.
Application Areas
The GE CK11CE300 is purpose-built for industrial applications requiring reliable discrete signal acquisition and processing:
Manufacturing Automation
In automotive and electronics manufacturing, the GE CK11CE300 monitors the status of robotic arms, conveyor belts, and assembly line components. It captures signals from proximity sensors and limit switches to ensure synchronized operation, preventing collisions and optimizing production flow. The module’s noise suppression and signal filtering features are critical for maintaining accuracy in high-speed manufacturing environments.
CK11CE300
Power Generation
In thermal, nuclear, and renewable power plants, the GE CK11CE300 monitors circuit breaker status, generator interlocks, and safety switches. It provides real-time data to control systems, enabling precise regulation of power distribution and rapid response to abnormal conditions, such as overloads or equipment failures. Its rugged design is essential for withstand ing the harsh conditions of power plant environments, including high temperatures and electromagnetic interference.Whatsapp:+86 18859254943.
Process Control
Within chemical and petrochemical plants, the module acquires signals from valves, pumps, and safety interlocks in reaction vessels and distillation columns. It ensures accurate monitoring of process conditions, such as pressure and flow status, to maintain safety and efficiency. The GE CK11CE300’s isolation capabilities are vital in these environments, where electrical noise from motors and drives could otherwise compromise signal quality.
Material Handling
In logistics and warehousing, the GE CK11CE300 controls automated storage and retrieval systems by monitoring the position of palletizers, conveyors, and lift mechanisms. Its high-density input channels and reliable signal processing enable seamless integration into complex material handling networks, ensuring smooth operations and reducing downtime caused by sensor malfunctions.
Safety Systems
As part of safety instrumented systems (SIS), the GE CK11CE300 captures signals from emergency stop buttons, gas detectors, and fire alarms. It provides the critical link between safety devices and control systems, enabling immediate shutdowns or protective actions in high-risk scenarios. The module’s fault detection and isolation features are essential for maintaining safety system integrity.
CK11CE300
Related Products
The GE CK11CE300 is part of GE’s comprehensive portfolio of industrial control modules, designed for seamless integration and scalability:Whatsapp:+86 18859254943.
- GE CK12CE300: A digital output module with 16 channels, complementary to the GE CK11CE300, enabling complete input/output (I/O) solutions for control systems.
- GE AI100CE300: An analog input module that works alongside the GE CK11CE300 to process continuous process variables, such as temperature and pressure.
- GE DI160CE300: A high-density digital input module with 32 channels, suitable for applications requiring greater input capacity while maintaining GE’s reliability standards.
- GE 90-30 PLC Processor: The central processing unit that interfaces with the GE CK11CE300, executing control logic and coordinating data from multiple I/O modules.
- GE FTA300: A field termination assembly that provides a secure interface between the GE CK11CE300 and field wiring, simplifying installation and maintenance.
- GE Communication Module IC693CMM301: Enables the GE CK11CE300 to connect with external systems via protocols like Modbus or Ethernet/IP, enhancing interoperability in complex networks.
Installation and Maintenance
Installation Preparations:
Before installing the GE CK11CE300, ensure the PLC chassis is powered off and properly grounded to prevent electrostatic discharge (ESD) damage. Verify compatibility with your GE PLC model (e.g., 90-30/90-70 series) and confirm that the backplane power supply is within the specified voltage range. Mount the module in an available slot of the PLC chassis, aligning it with the guide rails and securing it with the provided retaining clips. Connect field device wires to the terminal blocks, ensuring correct polarity and tight connections to prevent signal loss. Finally, power on the system and configure the module using GE’s programming software, setting the appropriate address and signal filtering parameters for your application.
Before installing the GE CK11CE300, ensure the PLC chassis is powered off and properly grounded to prevent electrostatic discharge (ESD) damage. Verify compatibility with your GE PLC model (e.g., 90-30/90-70 series) and confirm that the backplane power supply is within the specified voltage range. Mount the module in an available slot of the PLC chassis, aligning it with the guide rails and securing it with the provided retaining clips. Connect field device wires to the terminal blocks, ensuring correct polarity and tight connections to prevent signal loss. Finally, power on the system and configure the module using GE’s programming software, setting the appropriate address and signal filtering parameters for your application.
Maintenance Recommendations:
Regularly inspect the GE CK11CE300 for loose connections, damaged terminals, or physical wear. Clean the module’s exterior with a dry, static-free cloth to remove dust and debris that could affect heat dissipation. Monitor the LED indicators for each channel to ensure they reflect the correct input states; a lack of illumination or inconsistent signaling may indicate a faulty sensor or wiring issue. Whatsapp:+86 18859254943.Use the PLC’s diagnostic interface to check for module errors, such as communication faults or channel failures. In the event of a fault, disconnect power and replace the module if necessary, ensuring compatibility with the existing system configuration. Periodically review the module’s firmware version and update it as recommended by GE to benefit from the latest features and reliability improvements.
Regularly inspect the GE CK11CE300 for loose connections, damaged terminals, or physical wear. Clean the module’s exterior with a dry, static-free cloth to remove dust and debris that could affect heat dissipation. Monitor the LED indicators for each channel to ensure they reflect the correct input states; a lack of illumination or inconsistent signaling may indicate a faulty sensor or wiring issue. Whatsapp:+86 18859254943.Use the PLC’s diagnostic interface to check for module errors, such as communication faults or channel failures. In the event of a fault, disconnect power and replace the module if necessary, ensuring compatibility with the existing system configuration. Periodically review the module’s firmware version and update it as recommended by GE to benefit from the latest features and reliability improvements.
CK11CE300
Product Assurance
Our company provides a one-year quality warranty for the GE CK11CE300, covering hardware failures due to non-human factors. During the warranty period, we will promptly replace any module that exhibits performance anomalies or functional failures, ensuring minimal disruption to your operations. For discontinued models or urgent requirements, our global supply chain network is equipped to source and deliver scarce spare parts quickly, leveraging our 17 years of expertise in industrial control distribution. We are committed to supporting your automation needs with reliable products and dedicated service, ensuring the GE CK11CE300 continues to deliver exceptional performance in even the most challenging industrial environments. Trust us to be your partner in maintaining efficient, safe, and reliable control systems.E-mail :sales@ygplc.com.
