Emerson KJ3242X1-BK1 12P4711X042 Product Specification
Product Overview：Emerson KJ3242X1-BK1 12P4711X042
The Emerson KJ3242X1-BK1 12P4711X042 is a high-performance Fieldbus Communication Module designed for industrial automation systems, specifically engineered for Emerson’s DeltaV Distributed Control System (DCS). As part of the DeltaV Series 2 platform, this module serves as a critical interface between the DeltaV controller and field devices, enabling seamless integration of Fieldbus H1 protocols into process control architectures. The Emerson KJ3242X1-BK1 12P4711X042 is widely used in industries such as oil and gas, power generation, and chemical processing, where reliable communication and real-time data exchange are essential for operational efficiency and safety.
At its core, the Emerson KJ3242X1-BK1 12P4711X042 supports Fieldbus H1 communication, providing a robust link between the DeltaV system and intelligent field devices like transmitters, valves, and actuators. It features dual Fieldbus ports for redundant communication, ensuring continuous operation even in the event of a network failure. The module is compatible with DeltaV’s System 14 and later versions, offering backward compatibility with legacy systems while supporting advanced diagnostic capabilities for predictive maintenance. With its compact design (5.1 cm x 12.7 cm x 12.7 cm) and lightweight construction (0.1 kg), the Emerson KJ3242X1-BK1 12P4711X042 is ideal for space-constrained environments, such as offshore platforms or industrial control cabinets.
In automation systems, the Emerson KJ3242X1-BK1 12P4711X042 acts as a bridge between the control room and the plant floor, facilitating bidirectional data flow for process monitoring and control. Its support for standardized protocols like FOUNDATION Fieldbus ensures interoperability with a wide range of third-party devices, reducing dependency on single-vendor solutions. By combining high-speed communication with advanced signal conditioning, the module enhances system accuracy and responsiveness, making it suitable for applications requiring precise control, such as turbine speed regulation or chemical reactor monitoring.
Technical Specifications：Emerson KJ3242X1-BK1 12P4711X042
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Emerson KJ3242X1-BK1 12P4711X042 |
| Manufacturer | Emerson |
| Product Type | Fieldbus Communication Module (DeltaV Series 2) |
| Communication Protocol | Fieldbus H1 (1 Mbps) |
| Power Supply | 24 VDC ±10% (local bus power: 12 VDC at 150 mA; fieldbus power: 12 mA per port) |
| Physical Dimensions | 5.1 cm (width) × 12.7 cm (height) × 12.7 cm (depth) |
| Weight | 0.1 kg |
| Compatibility | DeltaV System 14 and later, Fieldbus H1 devices |
| Redundancy Support | Dual Fieldbus ports for redundant network configurations |
| Signal Channels | 2 x Fieldbus H1 ports (expandable via DeltaV I/O modules) |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Installation | DeltaV carrier slot (e.g., KJ4001X1-CH1 for serial communication) |
Emerson KJ3242X1-BK1 12P4711X042
Main Features and Advantages：Emerson KJ3242X1-BK1 12P4711X042
Fieldbus H1 Connectivity: The Emerson KJ3242X1-BK1 12P4711X042 supports Fieldbus H1 communication, enabling direct integration of FOUNDATION Fieldbus devices into the DeltaV system. This allows for advanced diagnostics, device configuration, and real-time data exchange, enhancing process visibility and reducing maintenance efforts.
Redundant Network Architecture: With dual Fieldbus ports, the module supports redundant communication paths, minimizing downtime in mission-critical applications. This feature is particularly valuable in industries like oil and gas, where continuous operation is essential to avoid production losses.
Compact and Lightweight Design: Weighing just 0.1 kg and measuring 5.1 cm x 12.7 cm x 12.7 cm, the Emerson KJ3242X1-BK1 12P4711X042 is easy to install in crowded control cabinets or remote locations. Its rugged construction ensures reliable performance in harsh industrial environments, including extreme temperatures and high vibration.
Advanced Diagnostics: The module provides comprehensive diagnostic capabilities, including device health monitoring, signal quality analysis, and fault detection. This proactive approach to maintenance helps identify potential issues before they escalate, reducing mean time to repair (MTTR) and optimizing system availability.
Scalable Integration: As part of the DeltaV Series 2 platform, the Emerson KJ3242X1-BK1 12P4711X042 can be combined with other DeltaV I/O modules (e.g., KJ3201X1-BA1 for analog inputs) to create a flexible and scalable control system. This modular design allows for easy expansion as process requirements evolve.
Emerson KJ3242X1-BK1 12P4711X042
Application Areas：Emerson KJ3242X1-BK1 12P4711X042
The Emerson KJ3242X1-BK1 12P4711X042 is widely used in industries where Fieldbus communication is critical for process control and optimization:
-
Oil and Gas:
- Integrates with offshore platforms and refineries to manage distributed control systems, ensuring real-time monitoring of pressure, temperature, and flow rates.
- Supports emergency shutdown systems by providing reliable communication between safety valves and the DeltaV controller.
-
Power Generation:
- Connects turbines, generators, and auxiliary systems to the control room, enabling remote monitoring and optimization of power production.
- Facilitates predictive maintenance by analyzing sensor data from vibration monitors and temperature transmitters.
-
Chemical Processing:
- Manages reactor processes by exchanging data with intelligent field devices, such as pH sensors and control valves.
- Ensures regulatory compliance by providing accurate and timely data for environmental monitoring systems.
-
Water and Wastewater Treatment:
- Controls pump stations and treatment processes by integrating with flow meters and level sensors.
- Enables remote access for diagnostic and configuration tasks, reducing on-site maintenance needs.
Related Products：Emerson KJ3242X1-BK1 12P4711X042
- Emerson KJ3242X1-BA1 12P2471X042: A Fieldbus communication module with similar functionality to the Emerson KJ3242X1-BK1 12P4711X042, but with different power specifications (9–32 VDC input).
- Emerson KJ3201X1-BA1 12P2535X092: An analog input module for handling 4–20 mA signals, often used alongside the Emerson KJ3242X1-BK1 12P4711X042 in hybrid control systems.
- Emerson KJ4001X1-CH1 12P1811X052: A serial communication module that complements the Emerson KJ3242X1-BK1 12P4711X042 by providing additional connectivity options for legacy devices.
- Emerson KJ3225X1-BA1 12P4174X052: A DC-DC power supply module that ensures stable power delivery to the Emerson KJ3242X1-BK1 12P4711X042 and other DeltaV components.
- Emerson KJ3203X1-BA1 12P3270X042: A discrete input module for handling dry contact signals, often used in conjunction with the Emerson KJ3242X1-BK1 12P4711X042 for event-triggered control applications.
Emerson KJ3242X1-BK1 12P4711X042
Installation and Maintenance：Emerson KJ3242X1-BK1 12P4711X042
Pre-installation Preparation:
Before installing the Emerson KJ3242X1-BK1 12P4711X042, ensure the following:
Before installing the Emerson KJ3242X1-BK1 12P4711X042, ensure the following:
- Verify the power supply meets the module’s requirements (24 VDC ±10%) and that the DeltaV carrier slot is compatible (e.g., KJ4001X1-CH1).
- Use Emerson’s DeltaV Workbench software to configure the module’s parameters, including Fieldbus network settings and device addressing.
- Inspect the module for physical damage and ensure all connectors are clean and free of debris.
Maintenance Recommendations:
- Routine Inspections: Check the module’s status LEDs monthly to confirm normal operation (e.g., green “Power” and “Communication” indicators). Replace faulty modules immediately to avoid system disruptions.
- Firmware Updates: Periodically update the module’s firmware using DeltaV Workbench to access the latest features and security patches.
- Signal Quality Monitoring: Use Emerson’s AMS Device Manager to monitor Fieldbus network health, including signal strength and noise levels. Adjust cabling or terminators as needed to maintain optimal performance.
- Environmental Checks: Clean dust and debris from the module’s vents quarterly, particularly in dusty environments, to prevent overheating. Monitor ambient temperature and humidity levels to ensure they remain within specified ranges.
Emerson KJ3242X1-BK1 12P4711X042
Product Warranty：Emerson KJ3242X1-BK1 12P4711X042
Our company provides a one-year quality warranty for the Emerson KJ3242X1-BK1 12P4711X042, covering hardware failures due to non-human factors. During the warranty period, we will replace the product if it exhibits performance anomalies or functional failures. For discontinued models or urgent needs, our global supply chain network ensures rapid response to scarce spare parts requests, supporting the continuous and stable operation of industrial systems.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on publicly available technical data and industry applications. For detailed specifications, consult the official Emerson datasheet or contact our technical support team.
