EMERSON KJ3001X1-CA1 | 8‑slot I/O carrier for compact DeltaV cabinet builds

EMERSON VE3008 – 8‑slot I/O carrier for compact DeltaV cabinet builds

The EMERSON VE3008 is commonly used as an 8‑wide I/O carrier within DeltaV I/O architectures, giving you a tidy, DIN‑rail mounted base to land field wiring and mount up to eight I/O positions. From my experience, it’s a straightforward way to expand a cabinet without reworking the whole backplane—ideal for brownfield upgrades and quick spares replacement.

You might notice that teams choose the VE3008 when they want consistent wiring practices across cabinets and clean separation between the field side and the system side. It typically supports a mix of AI, AO, DI, and DO through the cards you select, so you can standardize the carrier and vary the I/O as needed.

Key Features

• 8‑slot capacity – Accommodates up to eight I/O positions on a compact 35 mm DIN rail footprint for dense cabinet layouts.
• Passive, robust carrier design – Power and communications are handled by the system architecture; the carrier focuses on clean wiring and reliable terminations.
• Modular I/O mix – Supports a variety of DeltaV I/O cards (AI, AO, DI, DO), so one carrier can serve multiple signal strategies.
• Field‑friendly terminations – Clearly labeled channels and guided wire entries cut wiring errors and speed FAT/SAT work.
• DIN‑rail mounting – Quick installation in standard control cabinets; easy to reconfigure during expansions.
• Serviceability in mind – Card access from the front helps during troubleshooting; typically no special tools required for routine handling.

Technical Specifications

EMERSON VE3008

Application Fields

In most cases, you’ll see the VE3008 used where cabinet density and standardization matter:

• Refining and petrochemicals – mixed analog/relay cabinets for process units.
• Power & utilities – turbine/boiler I/O marshaling in compact enclosures.
• Water & wastewater – distributed RTU/PLC panels standardized on DeltaV I/O.
• Pharma & life sciences – validated skids with repeatable wiring layouts.
• Mining & metals – rugged field junction panels where fast swap‑outs help uptime.

Feedback from a maintenance supervisor: “We keep a VE3008 on the shelf. When we add a few signals in a crowded panel, it drops in cleanly and keeps the wiring consistent across skids.”

Advantages & Value

• Reliability – Simple, passive carrier means fewer active failure points and predictable lifecycle behavior.
• Compatibility – Aligns with DeltaV I/O card families, so spares stocking stays lean and consistent.
• Panel space efficiency – Eight I/O positions per carrier helps reduce rail length and cabinet footprint.
• Lower installed cost – Faster wiring and repeatable mounting typically reduce panel build time.
• Lifecycle support – Broad deployment base makes procurement and technical support straightforward in most regions.


  EMERSON VE3008

Installation & Maintenance

• Cabinet environment – Install on 35 mm DIN rail in a ventilated enclosure; target cabinet ambient within 0–55 °C and 5–95% RH non‑condensing.
• Grounding & shielding – Bond DIN rail to the cabinet PE; route shield drains per site standard to avoid ground loops.
• Wiring practice – Use ferrules where specified; maintain bend radius and segregate high‑energy and low‑level signal bundles.
• Torque & retention – Tighten terminal screws to the card manufacturer’s spec; verify card latches are fully seated before energizing.
• Service routine – Periodically check terminal tightness, clean dust with dry air, and verify labeling; firmware updates apply to controllers/I/O cards, not the passive carrier.

Quality & Certifications

• Certifications – Typically CE and UL/cUL for control equipment; RoHS alignment on most current revisions.
• Warranty – Standard Emerson hardware warranty applies (commonly one year from shipment; varies by region and program).

If you’re matching an existing installation, it’s best to confirm your system revision and I/O card family. That way the VE3008 drops right in—no surprises at FAT or during turnaround.
