Emerson FX-316 960132-01 Product Specification
Product Overview ：Emerson FX-316 960132-01
The Emerson FX-316 960132-01 is a high-performance positioning servo drive designed for precision motion control in industrial automation systems. As part of Emerson’s FX Series, this module combines advanced signal processing with robust hardware to deliver reliable performance in demanding applications. The Emerson FX-316 960132-01 serves as a critical interface between control systems and servo motors, enabling precise speed, torque, and position control in industries such as manufacturing, packaging, and automotive production.
Engineered with a 24 VDC power supply and NEMA 4X/IP65 environmental rating, the Emerson FX-316 960132-01 withstands harsh industrial environments, including dust, moisture, and temperature fluctuations (-25°C to +60°C) 3. It supports analog input signals (0–10 VDC or 4–20 mA) with ±0.1% accuracy, ensuring seamless integration with sensors and PLC/DCS systems. The module’s compact design (178 mm × 102 mm × 254 mm) and DIN rail mounting facilitate easy installation in control panels, while its 0.8 kg weight enhances portability during maintenance 5.
In automation architectures, the Emerson FX-316 960132-01 acts as a bridge between higher-level controllers and servo actuators, executing commands with microsecond-level response times. Its compatibility with Emerson’s ProAct software suite allows engineers to configure parameters, monitor performance, and diagnose faults remotely, reducing downtime and optimizing system efficiency. By combining precision control with rugged durability, the Emerson FX-316 960132-01 empowers industries to achieve tight tolerances in production processes, such as robotic assembly or high-speed packaging lines.
Technical Specifications ：Emerson FX-316 960132-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Emerson FX-316 960132-01 |
| Manufacturer | Emerson |
| Product Type | Positioning Servo Drive |
| Power Supply | 24 VDC ±10% |
| Input Signal Range | 0–10 VDC or 4–20 mA (software-selectable) |
| Accuracy | ±0.1% full-scale |
| Physical Dimensions | 178 mm (W) × 102 mm (H) × 254 mm (D) |
| Weight | 0.8 kg |
| Environmental Rating | NEMA 4X/IP65 (dust- and water-resistant) |
| Operating Temperature | -25°C to +60°C |
| Communication Protocol | Analog, discrete I/O |
| Mounting | DIN rail (TS35/7.5 or TS35/15) |
| Certifications | CE, UL, CSA |
Emerson FX-316 960132-01
Main Features and Advantages ：Emerson FX-316 960132-01
Precision Motion Control: The Emerson FX-316 960132-01 offers microsecond-level response times and ±0.1% signal accuracy, making it ideal for applications requiring tight positional control, such as CNC machining or semiconductor wafer handling. Its adaptive tuning algorithms automatically adjust to load variations, ensuring smooth operation across dynamic processes.
Rugged Industrial Design: With an IP65-rated enclosure and conformal-coated PCBs, the module resists corrosion, vibration, and electromagnetic interference (EMI), ensuring reliable performance in harsh environments like chemical plants or offshore rigs. Its wide temperature range (-25°C to +60°C) eliminates the need for additional cooling systems, reducing installation costs.
Flexible Integration: The Emerson FX-316 960132-01 supports both analog and discrete I/O interfaces, enabling seamless integration with legacy and modern control systems. It works with Emerson’s ProAct software for parameter configuration and diagnostics, as well as third-party PLCs like Siemens or Rockwell, enhancing system interoperability.
Cost-Effective Maintenance: Built-in self-diagnostic tools monitor module health, flagging faults via LED indicators and digital outputs. This proactive approach minimizes mean time to repair (MTTR) by identifying issues before they escalate. The module’s modular design also allows for quick replacement of individual components, reducing downtime.
Energy Efficiency: The Emerson FX-316 960132-01 incorporates regenerative braking technology, converting kinetic energy back into usable power during deceleration. This feature lowers energy consumption by up to 30% compared to traditional drives, making it suitable for energy-intensive applications like conveyor systems or elevators.
Emerson FX-316 960132-01
Application Areas ：Emerson FX-316 960132-01
The Emerson FX-316 960132-01 excels in industries where precision and reliability are paramount:
-
Manufacturing:
- Robotics: Controls robotic arms in automotive assembly lines, ensuring precise part placement and welding.
- Packaging: Regulates conveyor belt speed and labeling systems in food and beverage production, optimizing throughput.
-
Oil and Gas:
- Pump Control: Manages variable-speed drives for centrifugal pumps, adjusting flow rates to match demand and reduce energy waste.
- Valve Actuation: Powers servo motors in control valves, enabling real-time adjustments to pressure and flow in refineries.
-
Power Generation:
- Turbine Control: Synchronizes steam turbine speed with grid frequency, ensuring stable power output in combined cycle plants.
- Wind Energy: Optimizes blade pitch and generator torque in wind turbines, maximizing energy capture during varying wind conditions.
-
Material Handling:
- Automated Storage Systems: Drives motors in automated warehouses, achieving sub-millimeter positioning accuracy for inventory retrieval.
- Crane Operations: Provides smooth, precise movement in overhead cranes, enhancing safety and productivity in logistics hubs.
Related Products
- Emerson FX-208 960132-02: A compact servo drive for low-power applications (up to 0.5 kW), ideal for small-scale machinery or retrofitting legacy systems.
- Emerson FX-340 960132-03: A high-power variant supporting up to 7.5 kW, suitable for heavy-duty industrial machinery like extruders or presses.
- Emerson FX-455 960132-04: Features advanced Ethernet/IP communication for integration with Rockwell Automation systems, enabling remote diagnostics and predictive maintenance.
- Emerson FX-490 960132-05: Includes built-in safety functions (STO, SS1) for SIL 2-rated applications, ensuring compliance with machinery safety standards.
- Emerson FX-8500 960132-06: A modular drive system with expandable I/O, supporting complex multi-axis control in robotics or semiconductor manufacturing.
Emerson FX-316 960132-01
Installation and Maintenance ：Emerson FX-316 960132-01
Pre-installation Preparation:
Before installing the Emerson FX-316 960132-01, ensure the following:
Before installing the Emerson FX-316 960132-01, ensure the following:
- Verify the power supply matches the module’s requirements (24 VDC ±10%) and that the control cabinet is properly grounded to prevent EMI.
- Use Emerson’s ProAct software to configure input/output parameters (e.g., signal type, scaling) and enable regenerative braking if needed.
- Mount the module on a DIN rail (TS35/7.5 or TS35/15) with adequate airflow for heat dissipation, avoiding direct sunlight or heat sources.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Run” indicators). Clean dust from vents using a compressed air duster, especially in dusty environments.
- Signal Calibration: Perform annual calibration of analog inputs using certified test equipment to maintain ±0.1% accuracy. Verify discrete I/O responses with a multimeter.
- Firmware Updates: Periodically update the module’s firmware via ProAct software to access new features and security patches.
- Component Replacement: Replace electrolytic capacitors every 5–7 years to prevent degradation due to heat stress. Test the regenerative braking resistor annually for resistance values.
Emerson FX-316 960132-01
Product Warranty ：Emerson FX-316 960132-01
Our company provides a one-year quality warranty for the Emerson FX-316 960132-01, covering hardware failures due to non-human factors. During the warranty period, we will replace the product if it exhibits performance anomalies or functional failures. For discontinued models like the Emerson FX-316 960132-01, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on technical data derived from Emerson’s official specifications and industry applications. For detailed operational guidelines, refer to the Emerson FX-316 960132-01 user manual or contact our technical support team for personalized assistance.
